ENERPAC S100272

EP PAM-1042K3

Repair Kit

EP RC5K71

RC5 TON PREMIUM REPAIR KIT, RC51, RC53, RC55, RC57
Single-Acting Cylinders (RC-Series and equivalent)

• Type: Service Kit

• SubTypes: Repair Kit

EP RSM100K

REPAIR KIT
Single-Acting Low-Height Flat-Jac Cylinders (RSM-Series and equivalent)

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP V2000K

Repair Kit

EP MVPM5

Sequence Valve, 366 in3/min Maximum Oil Flow

• Type: Valve
• Max Bar: 350
• Max PSI: 5000

• Product Group: Valves, Pumps
• Product Line: Work Holding Tools
• Series: MVP
• SubTypes: Sequence Valve

• Sequence valves block the oil to a secondary hydraulic circuit until pressure in the primary circuit reaches a preset level. The sequence valves have a built-in check system to allow the oil to flow back without external piping.
• Direct accurate pressure setting
• Pressure setting between 500-5000 psi for secondary circuit is secured with lock nut
• Manifold mounting ports on MVPM5
• Manifold O-rings included with MVPM5

EP NC2432

15 Ton Capacity, Hydraulic Nut Cutter, Hexagon up to 1.13 in

NC-Series Hydraulic Nut Splitters use a single blade configuration suited to general nut cutting applications across a wide range of industries.

The heat-treated steel blade with its optimized cutting head geometry cuts from one side, and the powerful internal spring brings it back to its starting position.

NC-Series Nut Cutters are compact, simple, and easy to use. The ergonomic design ensures comfortable use, thanks to the carefully considered angled head design and handle position.

Nuts are often difficult to remove, and while loosening them using tightening tools is possible, this generally requires larger equipment and takes more time.

Using a cutting torch or a hammer and chisel presents safety risks and can cause damage to the joint components. They also involve significantly longer setup and operational time.

Nut splitting with the Enerpac Hydraulic Nut Splitters is the safest and most efficient method - taking less time and avoiding costly damage to joint components.

Applications: Cut

• Type: Cutter
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cutters
• Product Line: Industrial Tools, Bolting Tools
• Series: NC
• SubTypes: Nut Cutter

• bundleSet_IDs: NCB2432
• Capacity Imperial Tons: 15
• Capacity KN: 147

• Compact and ergonomic design, easy to use
• Unique angled head design
• Single-acting, spring return cylinder
• Heavy duty chisels can be reground
• Nut Splitters include spare chisel, spare set screw and wrench used to secure the chisel. A CR-400 coupler is standard.
• For applications with bolt sizes that are common to two tool model sizes, we recommend to select the larger of the two tools for the best results.
• These are not suited for square, star, round or stainless steel nuts. Maximum allowable hardness of nuts to be split is HRc-44.
• For materials and sizes not specified, contact Enerpac Technical Services.

• Accessories: NCB2432

EP NC3241

20 Ton Capacity, Hydraulic Nut Cutter, Hexagon up to 1.56 in

NC-Series Hydraulic Nut Splitters use a single blade configuration suited to general nut cutting applications across a wide range of industries.

The heat-treated steel blade with its optimized cutting head geometry cuts from one side, and the powerful internal spring brings it back to its starting position.

NC-Series Nut Cutters are compact, simple, and easy to use. The ergonomic design ensures comfortable use, thanks to the carefully considered angled head design and handle position.

Nuts are often difficult to remove, and while loosening them using tightening tools is possible, this generally requires larger equipment and takes more time.

Using a cutting torch or a hammer and chisel presents safety risks and can cause damage to the joint components. They also involve significantly longer setup and operational time.

Nut splitting with the Enerpac Hydraulic Nut Splitters is the safest and most efficient method - taking less time and avoiding costly damage to joint components.

Applications: Cut

• Type: Cutter
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cutters
• Product Line: Industrial Tools, Bolting Tools
• Series: NC
• SubTypes: Nut Cutter

• Capacity Imperial Tons: 20
• Capacity KN: 196

• Compact and ergonomic design, easy to use
• Unique angled head design
• Single-acting, spring return cylinder
• Heavy duty chisels can be reground
• Nut Splitters include spare chisel, spare set screw and wrench used to secure the chisel. A CR-400 coupler is standard.
• For applications with bolt sizes that are common to two tool model sizes, we recommend to select the larger of the two tools for the best results.
• These are not suited for square, star, round or stainless steel nuts. Maximum allowable hardness of nuts to be split is HRc-44.
• For materials and sizes not specified, contact Enerpac Technical Services.

• Accessories: NCB3241

EP NC4150

35 Ton Capacity, Hydraulic Nut Cutter, Hexagon up to 2.00 in

NC-Series Hydraulic Nut Splitters use a single blade configuration suited to general nut cutting applications across a wide range of industries.

The heat-treated steel blade with its optimized cutting head geometry cuts from one side, and the powerful internal spring brings it back to its starting position.

NC-Series Nut Cutters are compact, simple, and easy to use. The ergonomic design ensures comfortable use, thanks to the carefully considered angled head design and handle position.

Nuts are often difficult to remove, and while loosening them using tightening tools is possible, this generally requires larger equipment and takes more time.

Using a cutting torch or a hammer and chisel presents safety risks and can cause damage to the joint components. They also involve significantly longer setup and operational time.

Nut splitting with the Enerpac Hydraulic Nut Splitters is the safest and most efficient method - taking less time and avoiding costly damage to joint components.

Applications: Cut

• Type: Cutter
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cutters
• Product Line: Industrial Tools, Bolting Tools
• Series: NC
• SubTypes: Nut Cutter

• bundleSet_IDs: NCB4150
• Capacity Imperial Tons: 35
• Capacity KN: 343

• Compact and ergonomic design, easy to use
• Unique angled head design
• Single-acting, spring return cylinder
• Heavy duty chisels can be reground
• Nut Splitters include spare chisel, spare set screw and wrench used to secure the chisel. A CR-400 coupler is standard.
• For applications with bolt sizes that are common to two tool model sizes, we recommend to select the larger of the two tools for the best results.
• These are not suited for square, star, round or stainless steel nuts. Maximum allowable hardness of nuts to be split is HRc-44.
• For materials and sizes not specified, contact Enerpac Technical Services.

• Accessories: NCB4150

EP NC6075

90 Ton Capacity, Hydraulic Nut Cutter, Hexagon up to 2.88 in

NC-Series Hydraulic Nut Splitters use a single blade configuration suited to general nut cutting applications across a wide range of industries.

The heat-treated steel blade with its optimized cutting head geometry cuts from one side, and the powerful internal spring brings it back to its starting position.

NC-Series Nut Cutters are compact, simple, and easy to use. The ergonomic design ensures comfortable use, thanks to the carefully considered angled head design and handle position.

Nuts are often difficult to remove, and while loosening them using tightening tools is possible, this generally requires larger equipment and takes more time.

Using a cutting torch or a hammer and chisel presents safety risks and can cause damage to the joint components. They also involve significantly longer setup and operational time.

Nut splitting with the Enerpac Hydraulic Nut Splitters is the safest and most efficient method - taking less time and avoiding costly damage to joint components.

Applications: Cut

• Type: Cutter
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cutters
• Product Line: Industrial Tools, Bolting Tools
• Series: NC
• SubTypes: Nut Cutter

• Capacity Imperial Tons: 90
• Capacity KN: 882

• Compact and ergonomic design, easy to use
• Unique angled head design
• Single-acting, spring return cylinder
• Heavy duty chisels can be reground
• Nut Splitters include spare chisel, spare set screw and wrench used to secure the chisel. A CR-400 coupler is standard.
• For applications with bolt sizes that are common to two tool model sizes, we recommend to select the larger of the two tools for the best results.
• These are not suited for square, star, round or stainless steel nuts. Maximum allowable hardness of nuts to be split is HRc-44.
• For materials and sizes not specified, contact Enerpac Technical Services.

• Accessories: NCB6075

EP NCB1924

NC1924 Nut Cutter Chisel Replacement
Replacement Chisel for NC Cutters

• Type: Cutter Accessory

• Product Group: Cutters
• Product Line: Industrial Tools, Bolting Tools
• Series: NCB
• SubTypes: Replacement Chisel

EP NCB2432

NC2432 Nut Cutter Chisel Replacement
Replacement Chisel for NC Cutters

• Type: Cutter Accessory

• Product Group: Cutters
• Product Line: Industrial Tools, Bolting Tools
• Series: NCB
• SubTypes: Replacement Chisel

EP NCB3241

NC3241 Nut Cutter Chisel Replacement
Replacement Chisel for NC Cutters

• Type: Cutter Accessory

• Product Group: Cutters
• Product Line: Industrial Tools, Bolting Tools
• Series: NCB
• SubTypes: Replacement Chisel

EP NCB4150

NC4150 Nut Cutter Chisel Replacement
Replacement Chisel for NC Cutters

• Type: Cutter Accessory

• Product Group: Cutters
• Product Line: Industrial Tools, Bolting Tools
• Series: NCB
• SubTypes: Replacement Chisel

EP NSH1927

12 Ton Capacity, Hydraulic Nut Splitter, Hexagon up to 1.06 in

NSH-Series Hydraulic Nut Splitters are suited to flange nut splitting jobs in the oil and gas industries.

The heat-treated steel blade with optimized cutting head geometry cuts from one side, and the powerful internal spring brings it back to its starting position.

NSH-Series Nut Cutters are simple and easy to use. They include an ergonomically designed revolving handle for comfortable working and to isolate shock and vibration. The supplied lanyard and revolving anchor point are drop tested to ensure safety.

Nut splitting with the Enerpac Hydraulic Nut Splitters is the safest and most efficient method - taking less time and avoiding costly damage to joint components.

Applications: Cut

• Type: Cutter
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cutters
• Product Line: Industrial Tools, Bolting Tools
• Series: NSH
• SubTypes: Nut Splitter

• Capacity Imperial Tons: 12
• Capacity KN: 120

• Quick and easy cutting tip replacement
• Drop-tested revolving anchor point and safety lanyard
• Revolving composite handle for vibration and shock isolation
• Nut Splitters include set of hexagon keys and following spare parts:
  - cutting tip
  - tip retention screw
  - spare alignment screw
• Standard Safety Lanyard with each nut splitter. Includes steel cable with carabiners.
• CR400 female half coupler is standard
• Maximum allowable hardness to split is ASTM A194 Gr 2H. Not to be used on square nuts or stainless steel.

• Set Includes: CR400, FSC1
• Accessories: NSH1927CTK

EP P141K2

REPAIR KIT
Lightweight Hand Pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP P142ALSS

Two Speed, Extreme Environment Hydraulic Hand Pump, 20 in3 Usable Oil

• Type: Hydraulic Pump
• Max Bar: 700
• Max PSI: 10000

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: P
• SubTypes: Hand Pump - Two Speed

• Corrosion resistant, nickel-plated valves and cylinders
• Stainless steel pump inserts will not corrode
• Viton Seals provide heat and chemical resistance
• Anodized aluminum pump reservoirs and plastic encapsulated pump bodies resist wet environments
• Two-speed operation reduces pump handle strokes 78% compared to single-speed pumps
• Pump handles lock for easy carrying

• Spare Part(s): DA8802900SR, P142ALSSK

EP P202K1

REPAIR KIT - REPLACES P202K
Repair part for lightweight hand pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP P181190W

RELIEF VALVE
Double-Acting Long-Stroke Cylinders (RR-Series and equivalent)

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Relief Valve

EP P20857

CROSSPIN
Repair part for lightweight hand pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Crosspin

EP P25

Single Speed, Low Pressure Hydraulic Hand Pump, 200 in3 Usable Oil

These Low-Pressure Hydraulic Hand Pumps are durable, portable, highly efficient, and easy to use. Each model in the series features an all-steel construction, a chrome plated plunger, and a wiper system for long-lasting performance.

These pumps are constructed to power a wide range of single acting cylinders and tools in space restricted areas. The range includes the P51 that can be operated in the horizontal orientation only, and others also capable of operating in the vertical orientations: P18 with the pump head facing down, P25, P50 with the pump head facing up. Each is protected by external load-release valves and internal overload pressure-relief valves.

With a choice of oil capacities up to 200 in3 (3,277 cm3), and operating pressures of 2,500 psi (175 bar) - 5,000 psi (350 bar) you will find an Enerpac Low Pressure Hydraulic Hand Pump to suit your needs.

• Type: Hydraulic Pump
• Max Bar: 175
• Max PSI: 2500

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: P
• SubTypes: Hand Pump - Single Speed

• P25 and P50 pumps oil in both forward and reverse handle movement improving overall efficiency, ideal when mounting space is restricted
• External load-release valve
• Internal pressure-relief valve for overload protection
• P25 and P50 vertical operation requires pump vent side facing up

• Spare Part(s): CA365024SR, P181190W, P50K1

EP P391K2

REPAIR KIT
Lightweight Hand Pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP P30718

SCREEN
Single-Acting Cylinders (RC-Series and equivalent)

• Type: Service Kit

• SubTypes: Repair Part

EP P301D

Two Speed, Heavy Duty Steel Hydraulic Hand Pump, 0.24 in3 (4 cm3) Oil Flow per Stroke at 10,000 psi (700 bar), 272 in3 (4450 cm3) Usable Oil, For use with Double-Acting Tools

• Heavy duty, metal construction for durability.
• High displacements of oil per stroke.
• Low, back saving handle effort.
• Large reservoir capacities.

• Type: Hydraulic Pump
• Max Bar: 700
• Max PSI: 10000

• Product Line: Hydraulic Tools
• Series: P Steel
• SubTypes: Hand Pump - Heavy Duty Steel

EP P392E024K

REPAIR KIT
Repair part for lightweight hand pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP P39K4

REPAIR PARTS KIT
Repair part for steel hand pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP P84K3

REPAIR KIT
Steel Hand Pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP P84HDK

REPAIR KIT, HANDLE, P84, ULTIMA
Steel Hand Pumps

• Type: Service Kit

• SubTypes: Handle

EP P39K5

REPAIR KIT, P39, ULTIMA
Steel Hand Pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP P45138

SCREW
Flow and Pressure Control Valves (V-Series)

• Type: Service Kit

• SubTypes: Screw

EP P77K1

REPAIR KIT, P77, ULTIMA
Steel Hand Pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP P39RVK

REPAIR KIT, RELEASE VALVE, ULTIMA
Steel Hand Pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Valve Assembly

EP P84VRK

ULTIMA P84 VALVE REPAIR KIT
Steel Hand Pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Valve Assembly

EP PA1065040

PLUNGER 12KN
Upper Flange Imperial

• Type: Component

EP P50K1

REPAIR KIT
Low Pressure Hand Pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: P (Service Kit)
• SubTypes: Repair Kit

EP P6012SR

RELEASE VALVE LEVER KIT
Lever Bar

• Type: Service Kit

• SubTypes: Repair Part

EP P6010

SPINDLE
Low Pressure Hand Pumps

• Type: Service Kit

• SubTypes: Spindle Repair Kit

EP P75181

NUT
Foot Operated Pumps

• Type: Service Kit

• SubTypes: Nut

EP P80K8

REPAIR KIT, P80, ULTIMA
Steel Hand Pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP P60234-1SR

REPAIR KIT
Low Pressure Hand Pumps

• Type: Service Kit

• SubTypes: Repair Part

EP P6012

LEVER
Flow and Pressure Control Valves (V-Series)

• Type: Service Kit

• SubTypes: Repair Part

EP P51K1

REPAIR KIT
Low Pressure Hand Pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: P (Service Kit)
• SubTypes: Repair Kit

EP P80K4

REP KIT UNIVERSAL SER# BC OR D
Repair part for steel hand pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP P45139

WASHER
Flow and Pressure Control Valves (V-Series)

• Type: Service Kit

• SubTypes: Washer

EP P51

Single Speed, Low Pressure Hydraulic Hand Pump, 50 in3 Usable Oil

These Low-Pressure Hydraulic Hand Pumps are durable, portable, highly efficient, and easy to use. Each model in the series features an all-steel construction, a chrome plated plunger, and a wiper system for long-lasting performance.

These pumps are constructed to power a wide range of single acting cylinders and tools in space restricted areas. The range includes the P51 that can be operated in the horizontal orientation only, and others also capable of operating in the vertical orientations: P18 with the pump head facing down, P25, P50 with the pump head facing up. Each is protected by external load-release valves and internal overload pressure-relief valves.

With a choice of oil capacities up to 200 in3 (3,277 cm3), and operating pressures of 2,500 psi (175 bar) - 5,000 psi (350 bar) you will find an Enerpac Low Pressure Hydraulic Hand Pump to suit your needs.

• Type: Hydraulic Pump
• Max Bar: 200
• Max PSI: 3000

• Product Group: Pumps
• Product Line: Industrial Tools, Work Holding Tools
• Series: P
• SubTypes: Hand Pump - Single Speed

• External load-release valve
• Internal pressure-relief valve for overload protection
• P51 for horizontal operation only

• Spare Part(s): CJ589950W, P181190W, P51K1

EP P6011

NUT
Low Pressure Hand Pumps

• Type: Service Kit

• SubTypes: Nut

EP P80SFK

REPAIR KIT, SAFETY RELIEF VALVE, ULTIMA
Repair part for steel hand pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Valve Repair Kit

EP P75266-1

RESERVOIR CAP
Foot Operated Pumps

• Type: Service Kit

• SubTypes: Reservoir Assembly

EP P464

Two Speed, ULTIMA Steel Hydraulic Hand Pump, 453 in3 Usable Oil, For use with Double-Acting Cylinders

Ultima Steel Hand Pumps are durable, portable, and highly efficient. Each model in the series features an all-steel construction, a chrome plated plunger, and a wiper system for long-lasting performance.

All except the P39 are 2 stage pumps, which reduces the number of handle strokes by as much as 78% compared to a single speed pump. This is ideal for applications when high flow is needed at the first stage, (such as when advancing a cylinder to the point of load contact). The pump switches automatically to the second stage which is the low flow high-pressure stage.

With a choice of oil capacities up to 453 in3 (7423 cm3), you will find Ultima Steel Hand Pumps that can handle multiple cylinder hook-ups, including models to suit either single-acting and double-acting cylinders.

• Type: Hydraulic Pump
• Max Bar: 700
• Max PSI: 10000

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: P
• SubTypes: Hand Pump - Two Speed

• Reduced handle effort and ergonomic grip for less operator fatigue
• Vent free reservoir eliminates spills
• Quick grip handle allows for easy transport
• Integral reservoir over-pressurization protection

• Spare Part(s): P462K2, P462K3

EP P462K3

REPAIR KIT
Repair part for steel hand pumps

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: P (Service Kit)
• SubTypes: Repair Kit

EP PA133K3

REPAIR KIT
PA-Series

• Type: Service Kit

• Product Group: Pumps
• SubTypes: Repair Kit

EP PACG30S8SWM10

Turbo II Air Hydraulic Pump, Mount for 1-8 VP Valves, 180 in3/min Oil Flow at 100 psi

Enerpac PACG Air Hydraulic Pumps are for designed for intermittent to medium duty workholding applications up to 5,000 psi. Valve mount options include, remote, and mountings for DO3 and VP valves.

Enerpac Turbo II Air Over Hydraulic Pumps generate the hydraulic pressure you need using the air pressure you have available. The Air Saver Piston reduces air consumption, and the pump can start at low pressures from 50-125 psi.

Turbo II Air-Hydraulic Pumps are best suited to medium or lower cycle applications. They provide the power and speed needed for simple clamping circuits and mostly single acting tools. At only 75 dBA, the Turbo II Series helps to keep the noise level to a minimum.

Choose from a range with maximum working pressure of either 5,000 or 10,000psi, and various reservoir capacities from 116 - 462 in3 (2100 - 7500 cm3).

Turbo II Air Over Hydraulic Pump Series :

• PATG - Treadle for foot or hand operation
• PARG - Pendant Operation
• PAMG - Manual lever operated. For double-acting applications
• PACG - For remote valve mount. For workholding, 5000 psi (350 bar).
• PASG - Includes mount for a single DO3 Valve. For workholding, 5000 psi (350 bar).

• Type: Hydraulic Pump
• Max Bar: 350
• Max PSI: 5000

• Product Group: Pumps
• Product Line: Work Holding Tools
• Series: PACG
• SubTypes: Air Pump

• On-demand stall-restart operation maintains system pressure, providing clamping security
• External adjustable pressure relief valve (behind sight glass)
• Internal pressure relief valve provides overload protection
• Reduced noise level to 75 dBA
• Operating air pressure: 50-125 psi - enables pump to start at low air pressure**
• Hydraulic to air ratio: 45:1
• Reinforced heavy-duty lightweight reservoir for applications in tough environments
• Five valve mounting options provide flexibility in setup and operation
• Fully serviceable air motor assembly
• User supplied valves

** NOTE: From 50-125 psi air inlet pressure. Performance is significantly diminished below 50 psi. Performance may vary compared to listed values due to seal friction, internal pressure drops and manufacturing tolerances. Be sure to allow some flexibility on air inlet pressure.

EP PACG5002SB

Turbo II Air Hydraulic Pump, Remote Valve Mount, 120 in3/min Oil Flow at 100 psi

Enerpac PACG Air Hydraulic Pumps are for designed for intermittent to medium duty workholding applications up to 5,000 psi. Valve mount options include, remote, and mountings for DO3 and VP valves.

Enerpac Turbo II Air Over Hydraulic Pumps generate the hydraulic pressure you need using the air pressure you have available. The Air Saver Piston reduces air consumption, and the pump can start at low pressures from 50-125 psi.

Turbo II Air-Hydraulic Pumps are best suited to medium or lower cycle applications. They provide the power and speed needed for simple clamping circuits and mostly single acting tools. At only 75 dBA, the Turbo II Series helps to keep the noise level to a minimum.

Choose from a range with maximum working pressure of either 5,000 or 10,000psi, and various reservoir capacities from 116 - 462 in3 (2100 - 7500 cm3).

Turbo II Air Over Hydraulic Pump Series :

• PATG - Treadle for foot or hand operation
• PARG - Pendant Operation
• PAMG - Manual lever operated. For double-acting applications
• PACG - For remote valve mount. For workholding, 5000 psi (350 bar).
• PASG - Includes mount for a single DO3 Valve. For workholding, 5000 psi (350 bar).

• Type: Hydraulic Pump
• Max Bar: 350
• Max PSI: 5000

• Product Group: Pumps
• Product Line: Work Holding Tools
• Series: PACG
• SubTypes: Air Pump

• On-demand stall-restart operation maintains system pressure, providing clamping security
• External adjustable pressure relief valve (behind sight glass)
• Internal pressure relief valve provides overload protection
• Reduced noise level to 75 dBA
• Operating air pressure: 50-125 psi - enables pump to start at low air pressure**
• Hydraulic to air ratio: 45:1
• Reinforced heavy-duty lightweight reservoir for applications in tough environments
• Five valve mounting options provide flexibility in setup and operation
• Fully serviceable air motor assembly
• User supplied valves

** NOTE: From 50-125 psi air inlet pressure. Performance is significantly diminished below 50 psi. Performance may vary compared to listed values due to seal friction, internal pressure drops and manufacturing tolerances. Be sure to allow some flexibility on air inlet pressure.

EP PAM1042K3

REPAIR KIT
PAM-Series Twin Air

• Type: Service Kit

• Product Group: Pumps
• SubTypes: Repair Kit

EP PAMG3400K

COMPLETE KIT
Turbo II

• Type: Service Kit

• SubTypes: Repair Part

EP PAMG5400K

COMPLETE KIT
Turbo II

• Type: Service Kit

EP PARG1102N

Turbo II Air Hydraulic Pump, 3/3 Manual Valve with Pendant, 127 in3 Usable Oil, For use with Single-Acting Cylinders

Enerpac Turbo II Air Over Hydraulic Pumps generate the hydraulic pressure you need using the air pressure you have available. The Air Saver Piston reduces air consumption, and the pump can start at low pressures from 50-125 psi.

Turbo II Air-Hydraulic Pumps are best suited to medium or lower cycle applications. They provide all the power and speed needed for simple clamping circuits and mostly single acting tools. At only 75 dBA, the Turbo II Series helps to keep the noise level to a minimum.

Choose from a range with maximum working pressure of either 5,000 or 10,000psi, and various reservoir capacities from 116 - 462 in3 (2100 - 7500 cm3).

Each PARG pump variant includes a 3-way, 3-position valve for Advance / Hold / Retract functions.

Turbo II Air Over Hydraulic Pump Series :

• PATG - Treadle for foot or hand operation
• PARG - Pendant Operation
• PAMG - Manual lever operated. For double-acting applications
• PACG - For remote valve mount. For work holding, 5000 psi (350 bar).
• PASG - Includes mount for a single DO3 Valve.

• Type: Hydraulic Pump
• Max Bar: 700
• Max PSI: 10000

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: PARG
• SubTypes: Air Pump

• High efficiency cast aluminum air motor for increased life and reduced air consumption
• Reinforced heavy-duty reservoir for applications in tough environments
• New generation air saver piston with rugged one-piece design reduces air consumption and operating costs
• Return-to-tank port for use in remote valve applications
• Quiet - only 76dBA with low air consumption of 12 scfm
• Operating air pressure: 40-125 psi, enables pump to start at extremely low pressure
• Internal pressure relief valve provides overload protection

EP PAMG1402N

Turbo II Air Hydraulic Pump, 4/3 Manual Valve, 127 in3 Usable Oil, For use with Double-Acting Cylinders

PAMG Series air over hydraulic pumps include a manual lever operated 3-way valve. As part of the Turbo II Air Hydraulic Series, they provide the power and speed needed for simple clamping circuits.

PAMG3402NB, PAMG34S8N, PAMG5402NB, PAMG54S8N are for single-acting applications with a maximum operation pressure of 5000 psi (350 bar).

The PAMG1405N and the PAMG1402N pumps are compatible with double acting tools and provide Advance / Hold / Retract functions. Maximum operating pressure of 10,000 psi (700 bar).

Enerpac Turbo II Air Over Hydraulic Pumps generate the hydraulic pressure you need using the air pressure available. The Air Saver Piston reduces air consumption, and the pump can start at low pressures from 50-125 psi.

Turbo II Air-Hydraulic Pumps are best suited to medium or lower cycle applications. They provide all the power and speed needed for simple clamping circuits and single acting tools. At only 75 dBA, the Turbo II Series helps to keep the noise level to a minimum.

Choose from a range with maximum working pressure of either 5,000 or 10,000psi, and various reservoir capacities from 116 - 462 in3 (2100 - 7500 cm3).

Turbo II Air Over Hydraulic Pump Series :

• PATG - Treadle for foot or hand operation
• PARG - Pendant Operation
• PAMG - Manual lever operated. For double-acting applications
• PACG - For remote valve mount. For work holding, 5000 psi (350 bar).
• PASG - Includes mount for a single DO3 Valve.

• Type: Hydraulic Pump
• Max Bar: 700
• Max PSI: 10000

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: PAMG
• SubTypes: Air Pump

• High efficiency cast aluminum air motor for increased life and reduced air consumption
• Reinforced heavy-duty reservoir for applications in tough environments
• New generation air saver piston with rugged one-piece design reduces air consumption and operating costs
• Return-to-tank port for use in remote valve applications
• Quiet - only 76dBA with low air consumption of 12 scfm
• Operating air pressure: 40-125 psi, enables pump to start at extremely low pressure
• Internal pressure relief valve provides overload protection

EP PATG1100K

COMPLETE KIT
Turbo II

• Type: Service Kit

• SubTypes: Repair Part

EP PARG1105N

Turbo II Air Hydraulic Pump, 3/3 Manual Valve with Pendant, 230 in3 Usable Oil, For use with Single-Acting Cylinders

Enerpac Turbo II Air Over Hydraulic Pumps generate the hydraulic pressure you need using the air pressure you have available. The Air Saver Piston reduces air consumption, and the pump can start at low pressures from 50-125 psi.

Turbo II Air-Hydraulic Pumps are best suited to medium or lower cycle applications. They provide all the power and speed needed for simple clamping circuits and mostly single acting tools. At only 75 dBA, the Turbo II Series helps to keep the noise level to a minimum.

Choose from a range with maximum working pressure of either 5,000 or 10,000psi, and various reservoir capacities from 116 - 462 in3 (2100 - 7500 cm3).

Each PARG pump variant includes a 3-way, 3-position valve for Advance / Hold / Retract functions.

Turbo II Air Over Hydraulic Pump Series :

• PATG - Treadle for foot or hand operation
• PARG - Pendant Operation
• PAMG - Manual lever operated. For double-acting applications
• PACG - For remote valve mount. For work holding, 5000 psi (350 bar).
• PASG - Includes mount for a single DO3 Valve.

• Type: Hydraulic Pump
• Max Bar: 700
• Max PSI: 10000

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: PARG
• SubTypes: Air Pump

• High efficiency cast aluminum air motor for increased life and reduced air consumption
• Reinforced heavy-duty reservoir for applications in tough environments
• New generation air saver piston with rugged one-piece design reduces air consumption and operating costs
• Return-to-tank port for use in remote valve applications
• Quiet - only 76dBA with low air consumption of 12 scfm
• Operating air pressure: 40-125 psi, enables pump to start at extremely low pressure
• Internal pressure relief valve provides overload protection

EP PE10000SR

UNLOADING BLOCK-10000PSI KIT

• Type: ERP

• SubTypes: Repair Part

EP PJ3P

Planer Jack, 6 ton (53,4 kN) Sustaining Capacity, 2.25 in (57,2 mm) Operable Rise

• Side locking screw keeps the jack extended and prevents lowering due to vibration.
• Screw operation provides countless adjustments for exact leveling.
• Ideal jack for leveling plane beds, millers and machinery.
• Ball and socket cap swivels to center load forces.
• Notched base fastens easily to machine beds.
• CE Compliant - Our Jack design specifications meet or exceed ANSI /ASME B30.1 Safety Standards.
• Slotted load cap prevents the load from possible slippage with inline applications.

• Type: Jack

• Product Line: Mechanical Tools
• Series: PJ
• Stroke Inches: 2.25
• Stroke MM: 57.2
• SubTypes: Planer Jack

• Capacity Imperial Tons: 6
• Capacity KN: 53,4

EP PMB2

Pump Mounting Bracket for Large Hand and Electric Pumps

• Type: Press Accessory

• Product Group: Presses
• Product Line: Industrial Tools
• Series: A
• SubTypes: Press Pump Mounting Bracket

• Heavy duty steel brackets to allow conversion to one of the Enerpac Power Sources to power your press.
• Both mounting brackets are pre-drilled to accept a number of different pump models

EP PME10427K

REPAIR KIT
PU/PMU/WU-Series

• Type: Service Kit

• Product Group: Pumps
• Series: PME repair kit
• SubTypes: Repair Kit

EP PP179017

RETAINING RING
PA-Series

• Type: Service Kit

• SubTypes: Retaining Ring

EP PRASA10016L

100 Ton, 16 in Stroke, Pneumatic POW'R-RISER Lifting Jack
Applications: Lift, Lower

• Type: Wheeled Jack
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: PR
• Stroke Inches: 16
• Stroke MM: 406
• SubTypes: POW'R-RISER Jack Pneumatic

• Capacity Imperial Tons: 100
• Capacity KN: 889

• 4-inch ground clearance for transport over rail and rough terrain
• Three-position handle provides easy tilt back and transport
• Complies with ASME/ANSI B30.1:2015 & CE specifications
• Easy-to-change external filter minimizes down time
• Rugged, fully enclosed 24-inch wide frame with no exposed fittings or hoses
• SUP-R-STACK™ Extension System allows lifting at all heights without blocking

• Accessories: PRTS60, PRU13, PRU14, PRU110, PRUS126, PRE5, PRE7, PRE9, PRE11, PRE14, PRE18, PRES6024, PRS1, PRS2, PRS3, PRS4

EP PRASA10027L

100 Ton, 27 in Stroke, Pneumatic POW'R-RISER Lifting Jack
Applications: Lift, Lower

• Type: Wheeled Jack
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: PR
• Stroke Inches: 27
• Stroke MM: 686
• SubTypes: POW'R-RISER Jack Pneumatic

• Capacity Imperial Tons: 100
• Capacity KN: 889

• 4-inch ground clearance for transport over rail and rough terrain
• Three-position handle provides easy tilt back and transport
• Complies with ASME/ANSI B30.1:2015 & CE specifications
• Easy-to-change external filter minimizes down time
• Rugged, fully enclosed 24-inch wide frame with no exposed fittings or hoses
• SUP-R-STACK™ Extension System allows lifting at all heights without blocking

• Accessories: PRTS60, PRU13, PRU14, PRU110, PRUS137, PRE5, PRE7, PRE9, PRE11, PRES6024, PRS1, PRS2, PRS3, PRS4

EP PRASA15027L

150 Ton, 26.5 in Stroke, Pneumatic POW'R-RISER Lifting Jack
Applications: Lift, Lower

• Type: Wheeled Jack
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: PR
• Stroke Inches: 26.5
• Stroke MM: 673
• SubTypes: POW'R-RISER Jack Pneumatic

• Capacity Imperial Tons: 150
• Capacity KN: 1333

• 4-inch ground clearance for transport over rail and rough terrain
• Three-position handle provides easy tilt back and transport
• Complies with ASME/ANSI B30.1:2015 & CE specifications
• Easy-to-change external filter minimizes down time
• Rugged, fully enclosed 24-inch wide frame with no exposed fittings or hoses
• SUP-R-STACK™ Extension System allows lifting at all heights without blocking

• Accessories: PRTS150, PRU151, PRU153, PRU155, PRU1510, PRUS1537, PRE5, PRE7, PRE9, PRE11, PRES6024, PRS1, PRS2, PRS3, PRS4

EP PTW1000C

Pneumatic Torque Wrench, FRL included, 1000 ft. lbs. Torque, 1 in. Square Drive
Applications: Torque

• Type: Torque Wrench

• Product Group: Torque Wrenches, Torque Wrench Pumps
• Product Line: Bolting Tools
• Series: PTW
• SubTypes: Pneumatic Torque Wrench with FRL

Productivity, Safety, Convenience

• High speed continuous rotation for constant torque output
• Low friction planetary gearbox design minimizes wear and extends uptime
• Ergonomic, low vibration design reduces fatigue and the risk of vibration related injuries for the operator
• Low noise air motor provides quiet, consistent performance for indoor and outdoor applications
• Provided with standard reaction arm; wide assortment of custom arms and accessories are available
• Available with or without Filter-Regulator-Lubricator (FRL)
• Unique calibration certificate provided with each tool

• Set Includes: RATWS, FRL120C
• Accessories: ED6TWS, ED12TWS, ED18TWS, RATWS, ERATWS, SLRATWS, DSATWS, SRATWS, BLTWS

EP PTW2000C

Pneumatic Torque Wrench, FRL included, 2000 ft. lbs. Torque, 1 in. Square Drive
Applications: Torque

• Type: Torque Wrench

• Product Group: Torque Wrenches, Torque Wrench Pumps
• Product Line: Bolting Tools
• Series: PTW
• SubTypes: Pneumatic Torque Wrench with FRL

Productivity, Safety, Convenience

• High speed continuous rotation for constant torque output
• Low friction planetary gearbox design minimizes wear and extends uptime
• Ergonomic, low vibration design reduces fatigue and the risk of vibration related injuries for the operator
• Low noise air motor provides quiet, consistent performance for indoor and outdoor applications
• Provided with standard reaction arm; wide assortment of custom arms and accessories are available
• Available with or without Filter-Regulator-Lubricator (FRL)
• Unique calibration certificate provided with each tool

• Set Includes: RATWS, FRL120C
• Accessories: ED6TWS, ED12TWS, ED18TWS, RATWS, ERATWS, SLRATWS, DSATWS, SRATWS, BLTWS

EP PUD1100B

Two Speed, Economy Electric Hydraulic Pump, Dump Valve, 115V, For use with Single-Acting Cylinders

PU Series electric over hydraulic pumps combine economy with high-performance - ideal for intermittent use when working with small to medium size cylinders and other hydraulic tools.

All models in the series are 2-speed for enhanced productivity, and each is supplied with a 10 ft (3 m) cord and control pendant for operator safety. The high-strength molded shroud with integral handle protects the motor from contamination and damage in industrial environments.

Within the PU Series is a selection of pumps that offer a choice of reservoir capacities, valve functions and voltage.

PUD1100 Series

• For advance and retract of single-acting cylinders
• For applications not requiring load holding
• Ideal for punching applications

PUD1300 Series

• Providing advance, hold, and retract of single-acting cylinders
• Ideal for applications requiring load holding
• For applications requiring solenoid valves

PUJ-Series

• Manual valves provide advance, hold, and retract operation
• 3 and 4-way valves for single or double-acting cylinders

• Type: Hydraulic Pump
• Max Bar: 700
• Max PSI: 10000

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: PU
• SubTypes: Electric Pump - Economy

• The economic choice for small to medium sized tools.
• Lightweight, compact, and portable.
• Two-speed operation reduces cycle times for improved productivity.
• Ideal for intermittent duty cycles.
• Works well with long extension cords or generator-driven electrical power supplies.
• 115 VAC 50/60-cycle universal motor will operate under poor voltage supply.
• 24 VAC remote motor control with 10 ft (3 m) cord for operator safety.
• Starts under full load.
• High-strength shroud with integral handle protects the motor from contamination and damage.

• Spare Part(s): PUD1100BK

EP PREMB10016L

100 Ton, 16 in Stroke, Electric, 115 VAC, POW'R-RISER Lifting Jack
Applications: Lift, Lower

• Type: Wheeled Jack
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: PR
• Stroke Inches: 16
• Stroke MM: 406
• SubTypes: POW'R-RISER Jack Electric

• Capacity Imperial Tons: 100
• Capacity KN: 889

• 4-inch ground clearance for transport over rail and rough terrain
• Three-position handle provides easy tilt back and transport
• Complies with ASME/ANSI B30.1:2015 & CE specifications
• Easy-to-change external filter minimizes down time
• Rugged, fully enclosed 24-inch wide frame with no exposed fittings or hoses
• SUP-R-STACK™ Extension System allows lifting at all heights without blocking

• Accessories: PRTS60, PRU13, PRU14, PRU110, PRUS126, PRE5, PRE7, PRE9, PRE11, PRE14, PRE18, PRES6024, PRS1, PRS2, PRS3, PRS4

EP PRAMA10016L

100 Ton, 16 in Stroke, Pneumatic POW'R-RISER Lifting Jack
Applications: Lift, Lower

• Type: Wheeled Jack
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: PR
• Stroke Inches: 16
• Stroke MM: 406
• SubTypes: POW'R-RISER Jack Pneumatic

• Capacity Imperial Tons: 100
• Capacity KN: 889

• 4-inch ground clearance for transport over rail and rough terrain
• Three-position handle provides easy tilt back and transport
• Complies with ASME/ANSI B30.1:2015 & CE specifications
• Easy-to-change external filter minimizes down time
• Rugged, fully enclosed 24-inch wide frame with no exposed fittings or hoses
• SUP-R-STACK™ Extension System allows lifting at all heights without blocking

• Accessories: PRTS60, PRU13, PRU14, PRU110, PRUS126, PRE5, PRE7, PRE9, PRE11, PRE14, PRE18, PRES6024, PRS1, PRS2, PRS3, PRS4

EP PUD1100BK

REPAIR KIT
PU/PMU/WU-Series

• Type: Service Kit

• Product Group: Pumps
• Series: PU (service kit)
• SubTypes: Repair Kit

EP PUD1300B

Two Speed, Economy Electric Hydraulic Pump, 3/2 Solenoid Valve, 115V, For use with Single-Acting Cylinders

PU Series electric over hydraulic pumps combine economy with high-performance - ideal for intermittent use when working with small to medium size cylinders and other hydraulic tools.

All models in the series are 2-speed for enhanced productivity, and each is supplied with a 10 ft (3 m) cord and control pendant for operator safety. The high-strength molded shroud with integral handle protects the motor from contamination and damage in industrial environments.

Within the PU Series is a selection of pumps that offer a choice of reservoir capacities, valve functions and voltage.

PUD1100 Series

• For advance and retract of single-acting cylinders
• For applications not requiring load holding
• Ideal for punching applications

PUD1300 Series

• Providing advance, hold, and retract of single-acting cylinders
• Ideal for applications requiring load holding
• For applications requiring solenoid valves

PUJ-Series

• Manual valves provide advance, hold, and retract operation
• 3 and 4-way valves for single or double-acting cylinders

• Type: Hydraulic Pump
• Max Bar: 700
• Max PSI: 10000

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: PU
• SubTypes: Electric Pump - Economy

• The economic choice for small to medium sized tools.
• Lightweight, compact, and portable.
• Two-speed operation reduces cycle times for improved productivity.
• Ideal for intermittent duty cycles.
• Works well with long extension cords or generator-driven electrical power supplies.
• 115 VAC 50/60-cycle universal motor will operate under poor voltage supply.
• 24 VAC remote motor control with 10 ft (3 m) cord for operator safety.
• Starts under full load.
• High-strength shroud with integral handle protects the motor from contamination and damage.

• Spare Part(s): PUD1100BK

EP PUJ1200BK1

REPAIR KIT
PU/PMU/WU-Series

• Type: Service Kit

• Product Group: Pumps
• Series: PU (service kit)
• SubTypes: Repair Kit

EP PUJ1400BK

REPAIR KIT BOM
PU/PMU/WU-Series

• Type: Service Kit

• Product Group: Pumps
• Series: PU (service kit)
• SubTypes: Repair Kit

EP PUJ1400B

Two Speed, Economy Electric Hydraulic Pump, 4/3 Manual Valve, 115V, For use with Double-Acting Cylinders

PU Series electric over hydraulic pumps combine economy with high-performance - ideal for intermittent use when working with small to medium size cylinders and other hydraulic tools.

All models in the series are 2-speed for enhanced productivity, and each is supplied with a 10 ft (3 m) cord and control pendant for operator safety. The high-strength molded shroud with integral handle protects the motor from contamination and damage in industrial environments.

Within the PU Series is a selection of pumps that offer a choice of reservoir capacities, valve functions and voltage.

PUD1100 Series

• For advance and retract of single-acting cylinders
• For applications not requiring load holding
• Ideal for punching applications

PUD1300 Series

• Providing advance, hold, and retract of single-acting cylinders
• Ideal for applications requiring load holding
• For applications requiring solenoid valves

PUJ-Series

• Manual valves provide advance, hold, and retract operation
• 3 and 4-way valves for single or double-acting cylinders

• Type: Hydraulic Pump
• Max Bar: 700
• Max PSI: 10000

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: PU
• SubTypes: Electric Pump - Economy

• The economic choice for small to medium sized tools.
• Lightweight, compact, and portable.
• Two-speed operation reduces cycle times for improved productivity.
• Ideal for intermittent duty cycles.
• Works well with long extension cords or generator-driven electrical power supplies.
• 115 VAC 50/60-cycle universal motor will operate under poor voltage supply.
• 24 VAC remote motor control with 10 ft (3 m) cord for operator safety.
• Starts under full load.
• High-strength shroud with integral handle protects the motor from contamination and damage.

• Spare Part(s): PUJ1400BK

EP R102

10 ton (89,0 kN) Capacity, 2.19 in (55,6 mm) Stroke, Single-Acting, General Purpose Hydraulic Cylinder

Simplex R-Series Single Acting Hydraulic Cylinders are the durable, reliable, and versatile choice for general purpose industrial use. With a vast range of cylinder tonnages and strokes available it's easy to find a cylinder perfectly matched to your application.

Threaded collars offer versatility in fixturing to give you many more application possibilities. Included inside R Series Cylinders is a positive stop to limit piston travel at the end of the stroke, adding extra strength and safety to your cylinder, and cylinder life is extended by the wiper seal.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Line: Hydraulic Tools
• Series: R
• Stroke Inches: 2.19
• Stroke MM: 55.6
• SubTypes: General Purpose Cylinder

• Capacity Imperial Tons: 10
• Capacity KN: 89,0

• Single acting with heavy-duty internal retraction spring
• Solid and plated piston resists scoring & corrosion
• Heat treated grooved saddles are provided as standard
• Stop ring limits piston travel at the end of the stroke to prevent blow-out
• High flow couplers are plated to resist corrosion
• Polyurethane wipers clean the piston surface during retraction - protecting the inner cylinder assembly from dirt, moisture, and other contaminants.
• Meets ANSI/ASME B30.1 Safety Standards
• Load tested under 125% of the nominal capacity
• For working pressures up to 10,000 psi (700 bar)

• Accessories: BA10, 18348, ATS10, BR10, BCR10, BC10

EP R515245-2

PLUG
Flow and Pressure Control Valves (V-Series)

• Type: Service Kit

• SubTypes: Plug

EP RA106

10 TON S/A CYLINDER
Single-Acting Cylinders (RC-Series and equivalent)

• Type: Hydraulic Cylinders

• Product Group: Cylinders and Jacks

EP R57

5 ton (44,5 kN) Capacity, 7.18 in (182,4 mm) Stroke, Single-Acting, General Purpose Hydraulic Cylinder

Simplex R-Series Single Acting Hydraulic Cylinders are the durable, reliable, and versatile choice for general purpose industrial use. With a vast range of cylinder tonnages and strokes available it's easy to find a cylinder perfectly matched to your application.

Threaded collars offer versatility in fixturing to give you many more application possibilities. Included inside R Series Cylinders is a positive stop to limit piston travel at the end of the stroke, adding extra strength and safety to your cylinder, and cylinder life is extended by the wiper seal.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Line: Hydraulic Tools
• Series: R
• Stroke Inches: 7.18
• Stroke MM: 182.4
• SubTypes: General Purpose Cylinder

• Capacity Imperial Tons: 5
• Capacity KN: 44,5

• Single acting with heavy-duty internal retraction spring
• Solid and plated piston resists scoring & corrosion
• Heat treated grooved saddles are provided as standard
• Stop ring limits piston travel at the end of the stroke to prevent blow-out
• High flow couplers are plated to resist corrosion
• Polyurethane wipers clean the piston surface during retraction - protecting the inner cylinder assembly from dirt, moisture, and other contaminants.
• Meets ANSI/ASME B30.1 Safety Standards
• Load tested under 125% of the nominal capacity
• For working pressures up to 10,000 psi (700 bar)

• Accessories: 18347, BCR5, BR5

EP RAC20K50

RAC20 SERIES REPAIR KIT
Single-Acting Cylinders (RAC-Series and equivalent)

• Type: Service Kit

• SubTypes: Repair Kit

EP RAC50K50

RAC50 SERIES REPAIR KIT
Single-Acting Cylinders (RAC-Series and equivalent)

• Type: Service Kit

• SubTypes: Repair Kit

EP QDH120

13800 lbs Capacity, 0.32 in Stroke, Hollow Plunger Hydraulic Cylinder
Applications: Push, Pull

• Type: Hydraulic Cylinders
• Max Bar: 350
• Max PSI: 5000

• Product Group: Cylinders and Jacks
• Product Line: Work Holding Tools
• Series: QDH
• Stroke Inches: 0.32
• Stroke MM: 8.1
• SubTypes: Workholding Hollow Plunger Cylinder

• Load can be attached to either end of the cylinder, providing a choice of push or pull actions - both realizing full cylinder capacity
• Very high cylinder capacities contained within small dimensions allow compact fixture designs
• Spring return operation allows for easy unloading of the workpiece
• Threaded collars and base mounting holes allow mounting flexibility, including table-top surfaces and T-slots
• Nickel-plated plungers, plunger wipers and internal venting prevent corrosion and support longer operation life on allHCS models

EP RACD3010

30 ton (266,9 kN) Capacity, 10 in (254 mm) Stroke, Double-Acting, Aluminum Center Hole Hydraulic Cylinder

• Technical coating reduces wear & corrosion.
• Steel piston for protection against load damage.
• Chrome plated sleeve for extra protection.
• Stop rings for piston blow-out protection.
• Rod wiper protects inner cylinder from dirt.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Line: Hydraulic Tools
• Series: RACD
• Stroke Inches: 10
• Stroke MM: 254
• SubTypes: Aluminum Center Hole Cylinder

• Capacity Imperial Tons: 30
• Capacity KN: 266,9

EP RACD10010

100 ton (889,6 kN) Capacity, 10 in (254 mm) Stroke, Double-Acting, Aluminum Center Hole Hydraulic Cylinder

• Technical coating reduces wear & corrosion.
• Steel piston for protection against load damage.
• Chrome plated sleeve for extra protection.
• Stop rings for piston blow-out protection.
• Rod wiper protects inner cylinder from dirt.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Line: Hydraulic Tools
• Series: RACD
• Stroke Inches: 10
• Stroke MM: 254
• SubTypes: Aluminum Center Hole Cylinder

• Capacity Imperial Tons: 100
• Capacity KN: 889,6

EP R59

5 ton (44,5 kN) Capacity, 9.18 in (233,2 mm) Stroke, Single-Acting, General Purpose Hydraulic Cylinder

Simplex R-Series Single Acting Hydraulic Cylinders are the durable, reliable, and versatile choice for general purpose industrial use. With a vast range of cylinder tonnages and strokes available it's easy to find a cylinder perfectly matched to your application.

Threaded collars offer versatility in fixturing to give you many more application possibilities. Included inside R Series Cylinders is a positive stop to limit piston travel at the end of the stroke, adding extra strength and safety to your cylinder, and cylinder life is extended by the wiper seal.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Line: Hydraulic Tools
• Series: R
• Stroke Inches: 9.18
• Stroke MM: 233.2
• SubTypes: General Purpose Cylinder

• Capacity Imperial Tons: 5
• Capacity KN: 44,5

• Single acting with heavy-duty internal retraction spring
• Solid and plated piston resists scoring & corrosion
• Heat treated grooved saddles are provided as standard
• Stop ring limits piston travel at the end of the stroke to prevent blow-out
• High flow couplers are plated to resist corrosion
• Polyurethane wipers clean the piston surface during retraction - protecting the inner cylinder assembly from dirt, moisture, and other contaminants.
• Meets ANSI/ASME B30.1 Safety Standards
• Load tested under 125% of the nominal capacity
• For working pressures up to 10,000 psi (700 bar)

• Accessories: 18347, BCR5, BR5

EP RACH1006005

CENTER TUBE 100 TON 150MM STROKE
Single-Acting Hollow Plunger Cylinders (RACH-Series and equivalent)

• Type: Service Kit

• SubTypes: Tube

EP RACH1006

127.5 ton Capacity, 5.91 in Stroke, Aluminum Hollow Plunger Hydraulic Cylinder

RACH-Series Hollow Plunger Hydraulic Cylinders (sometimes called center-hole cylinders) feature a hollow plunger with an internal thread to allow fixing to the component to be pulled. This makes them the ideal choice for when you need a lighter, more portable cylinder for applications such as tensioning, testing, pulling, and lifting. Each RACH Cylinder is rated for up to 10,000 psi (700 bar) and compliant with ASME B30.1.

Each RACH Cylinder is single-acting and uses a high-strength return spring for rapid retraction. All are equipped with bolt-on hardened steel saddles and a steel base plate for increased durability.

Aluminum is not only lightweight, but also inherently less corrosive than steel, which makes it a great material for use in many caustic environments. For enhanced protection, RACH Aluminum Cylinders are finished with an anodized hard coat finish to resist damage and extend cylinder life.

Applications: Lift, Push, Pull, Tension

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RACH
• Stroke Inches: 5.91
• Stroke MM: 150
• SubTypes: Aluminum Hollow Plunger Cylinder

• Hollow plunger design allows for both pull and push forces
• Composite bearings increase cylinder life and side load resistance
• Hard coat finish on all surfaces resists damage and extends cylinder life
• Handles included on all models
• Floating center tube increases seal life
• Steel baseplate and saddle for protection against load-induced damage
• Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacity
• High-strength return spring for rapid cylinder retraction
• CR400 coupler and dustcap included on all models
• All cylinders meet ASME B-30.1 standards

EP RACH1006040

PLUNGER 100 TON 150MM STROKE
Single-Acting Hollow Plunger Cylinders (RACH-Series and equivalent)

• Type: Service Kit

• SubTypes: Plunger Kit

EP RACD5010

50 ton (444,8 kN) Capacity, 10 in (254 mm) Stroke, Double-Acting, Aluminum Center Hole Hydraulic Cylinder

• Technical coating reduces wear & corrosion.
• Steel piston for protection against load damage.
• Chrome plated sleeve for extra protection.
• Stop rings for piston blow-out protection.
• Rod wiper protects inner cylinder from dirt.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Line: Hydraulic Tools
• Series: RACD
• Stroke Inches: 10
• Stroke MM: 254
• SubTypes: Aluminum Center Hole Cylinder

• Capacity Imperial Tons: 50
• Capacity KN: 444,8

EP RACH100K50

RACH100 SERIES REPAIR KIT
Single-Acting Hollow Plunger Cylinders (RACH-Series and equivalent)

• Type: Service Kit

• SubTypes: Repair Kit

EP RACH2010

25.4 ton Capacity, 9.84 in Stroke, Aluminum Hollow Plunger Hydraulic Cylinder

RACH-Series Hollow Plunger Hydraulic Cylinders (sometimes called center-hole cylinders) feature a hollow plunger with an internal thread to allow fixing to the component to be pulled. This makes them the ideal choice for when you need a lighter, more portable cylinder for applications such as tensioning, testing, pulling, and lifting. Each RACH Cylinder is rated for up to 10,000 psi (700 bar) and compliant with ASME B30.1.

Each RACH Cylinder is single-acting and uses a high-strength return spring for rapid retraction. All are equipped with bolt-on hardened steel saddles and a steel base plate for increased durability.

Aluminum is not only lightweight, but also inherently less corrosive than steel, which makes it a great material for use in many caustic environments. For enhanced protection, RACH Aluminum Cylinders are finished with an anodized hard coat finish to resist damage and extend cylinder life.

Applications: Lift, Push, Pull, Tension

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RACH
• Stroke Inches: 9.84
• Stroke MM: 250
• SubTypes: Aluminum Hollow Plunger Cylinder

• Hollow plunger design allows for both pull and push forces
• Composite bearings increase cylinder life and side load resistance
• Hard coat finish on all surfaces resists damage and extends cylinder life
• Handles included on all models
• Floating center tube increases seal life
• Steel baseplate and saddle for protection against load-induced damage
• Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacity
• High-strength return spring for rapid cylinder retraction
• CR400 coupler and dustcap included on all models
• All cylinders meet ASME B-30.1 standards

EP RACH20K50

RACH20 SERIES REPAIR KIT
Single-Acting Hollow Plunger Cylinders (RACH-Series and equivalent)

• Type: Service Kit

• SubTypes: Repair Kit

EP RACH602005

CENTER TUBE 60 TON 50MM STROKE
Single-Acting Hollow Plunger Cylinders (RACH-Series and equivalent)

• Type: Service Kit

• SubTypes: Tube

EP RACL504

54.9 ton Capacity, 3.94 in Stroke, Aluminum Lock Nut Hydraulic Cylinder

RACL-Series Aluminum Cylinders include a lock nut that gives the reassurance of safe mechanical load holding for extended periods. Each cylinder is single-acting with a high-strength return spring for rapid retraction. The integral stop ring prevents plunger over-travel. All are equipped with bolt-on hardened steel saddles and a steel base plate for increased durability.

Enerpac RACL Lock Nut Aluminum Hydraulic Cylinders can change the way you think about your cylinder applications. With approximately half of the weight of equivalent steel models, they combine an impressive power to weight ratio with the convenience of easier transport and positioning. RACL cylinders are rated for 10,000 psi (700 bar) and comply with ASME B30.1.

Aluminum is not only lightweight, but also inherently less corrosive than steel, which makes it a great material for use in many caustic environments. For enhanced protection, Enerpac RACL Aluminum Cylinders are finished with an anodized hard coat finish to resist damage and extend cylinder life.

Applications: Lift, Push, Hold

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RACL
• Stroke Inches: 3.94
• Stroke MM: 100
• SubTypes: Aluminum Lock Nut Cylinder

• Aluminum Lock Nut provides mechanical load holding for extended periods
• Hardened steel stop ring increases cylinder life and resistance to side-loads of up to 5%
• Hard coat finish on all surfaces resists damage and extends cylinder life
• Composite bearings increase cylinder life and side load resistance
• Handles included on all models
• Steel base plate and saddle for protection against load-induced damage
• Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacity
• High-strength return spring for rapid cylinder retraction
• CR400 coupler and dustcap included on all models
• All cylinders meet ASME B-30.1 standards

• Accessories: CATS50

EP RACL204

24.2 ton Capacity, 3.94 in Stroke, Aluminum Lock Nut Hydraulic Cylinder

RACL-Series Aluminum Cylinders include a lock nut that gives the reassurance of safe mechanical load holding for extended periods. Each cylinder is single-acting with a high-strength return spring for rapid retraction. The integral stop ring prevents plunger over-travel. All are equipped with bolt-on hardened steel saddles and a steel base plate for increased durability.

Enerpac RACL Lock Nut Aluminum Hydraulic Cylinders can change the way you think about your cylinder applications. With approximately half of the weight of equivalent steel models, they combine an impressive power to weight ratio with the convenience of easier transport and positioning. RACL cylinders are rated for 10,000 psi (700 bar) and comply with ASME B30.1.

Aluminum is not only lightweight, but also inherently less corrosive than steel, which makes it a great material for use in many caustic environments. For enhanced protection, Enerpac RACL Aluminum Cylinders are finished with an anodized hard coat finish to resist damage and extend cylinder life.

Applications: Lift, Push, Hold

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RACL
• Stroke Inches: 3.94
• Stroke MM: 100
• SubTypes: Aluminum Lock Nut Cylinder

• Aluminum Lock Nut provides mechanical load holding for extended periods
• Hardened steel stop ring increases cylinder life and resistance to side-loads of up to 5%
• Hard coat finish on all surfaces resists damage and extends cylinder life
• Composite bearings increase cylinder life and side load resistance
• Handles included on all models
• Steel base plate and saddle for protection against load-induced damage
• Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacity
• High-strength return spring for rapid cylinder retraction
• CR400 coupler and dustcap included on all models
• All cylinders meet ASME B-30.1 standards

EP RAR1004

100 ton Capacity, 3.94 in Stroke, Double-Acting, Aluminum Hydraulic Cylinder

RAR-Series Double Acting Hydraulic Cylinders provide a rapid and more controlled plunger retraction than spring return or load return types. The hydraulic return method continues to work effectively regardless of hose lengths and system losses, maintaining efficiency and productivity. Each RAR Cylinder is rated for up to 10,000 psi (700 bar) and compliant with ASME B30.1.

The aluminum construction of RAR Cylinders means they are not only lightweight, but also less corrosive than steel equivalents. This helps to maintain durability in many caustic environments. For enhanced protection, RAR Aluminum Cylinders are finished with an anodized hard coat finish to resist damage and extend cylinder life. Handles featured on all models enhance their portability.

Each RAR Cylinder is equipped with a bolt-on hardened steel saddle and a steel base plate for increased durability. Optional Tilt Saddles can help to support the load evenly and alleviate unwanted side-load.

Applications: Lift, Lower, Push

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RAR
• Stroke Inches: 3.94
• Stroke MM: 100
• SubTypes: Aluminum Cylinder

• Double-acting for rapid retraction, regardless of hose lengths and system losses
• Composite bearings increase cylinder life and side load resistance
• Hard coat finish on all surfaces resists damage and extends cylinder life
• Handles included on all models
• Steel base plate and saddle for protection against load- induced damage
• Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacity
• Built-in safety valve prevents accidental over-pressurization

• Accessories: CATS101

EP RAL502

50 ton (444,8 kN) Capacity, 2 in (50,8 mm) Stroke, Single-Acting, Aluminum Locknut Hydraulic Cylinder

Simplex RAL Series Aluminum Hydraulic Cylinders feature lock nut that provide the reassurance of safe mechanical load holding for extended periods. These are approximately half the weight of steel equivalents and are expertly engineered to withstand tough applications in harsh conditions.

Aluminum is not only lighter, but also inherently less corrosive than steel, which makes it a great material for use in many caustic environments. A carrying handle provided on all RAL cylinders also enhance portability.

Inside the cylinder is a high-strength return spring for plunger retraction and stop rings for protection against blow out. The cylinder exterior is finished with an anodized hard coat to extend cylinder life, and a wiper protects the inner cylinder assembly from dirt, moisture, and other contaminants.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Line: Hydraulic Tools
• Series: RAL
• Stroke Inches: 2
• Stroke MM: 50.8
• SubTypes: Aluminum Locknut Cylinder

• Capacity Imperial Tons: 50
• Capacity KN: 444,8

• Approximately half the weight of steel cylinders
• Lock nut for mechanical load holding for extended periods
• Heavy duty spring delivers fast and full retraction
• Hard anodized coating reduces wear and corrosion
• Stop rings prevent piston blow-out
• Wiper protects inner cylinder from dirt.
• Meets ANSI/ASME B30.1 Safety Standards
• Load tested under 125% of the nominal capacity
• For working pressures up to 10,000 psi (700 bar)

EP RAR1006040

PLUNGER 100 TON 150MM STROKE
Double-Acting Cylinders (RAR-Series)

• Type: Service Kit

• SubTypes: Plunger Kit
