Finishing Packages
GRACO SPRAYER, 390, PC, STAND
GG 17C310
GRACO SPRAYER, 390, PC, STAND
Graco 17C310 390 PC Electric Airless Sprayer, Stand
The 390 PC Stand is a solid workhorse built for the professional just &Prime, starting out.&Prime, Lightweight and portable, it&prime, s easy to lift and carry. The 390 PC is the ideal sprayer for residential jobs, and is the best value in small electric sprayers.
Application: The ideal sprayer for residential jobs and the best value in small electric sprayers.- Durable Endurance Chromex Piston Pump
Lasts 2X longer than the next leading brand
Long Life V-Max Blue Packings, Chromex rod and hardened stainless steel cylinder
Faster cleaning with the QuikAccess intake valve
- Advantage Drive
The longest lasting drive
Hardened steel gears provide extremely quiet operation and a Lifetime Warranty
- ProConnect One-Part Pump Replacement System
Eliminate costly downtime
Pump swaps in minutes – no tools, pins or parts to lose
- Rugged Steel Frame
Thick chrome over steel withstands rugged environments
4 leg stand provides greater stability
- Variable Pressure Control
Position indicator allows repeatable setting
- Swivel Inlet Suction Hose
Easily reaches paint buckets
- Contractor FTx Airless Spray Gun
Standard features
Economic choice for everyday use
- Series: 390 PC
- Amperage (A): 13
- Compatible Material: Acrylics, Enamel, Lacquer, Latex, Stains
- Compatible Replacement Pump: 17C487
- Cycles Per Gallon: 700
- Engine Size (HP): 0.625
- Features: Endurance Chromex Pump, Advantage Drive, ProConnect, Easy Out Filter
- Fluid Outlet Size (in): 1/4
- Fluid Outlet Size (mm): 6.35
- Fluid Outlet Thread Type: NPSM
- Frame Configuration: Stand
- Includes: FTx Gun, RAC X LP 515 Spray Tip, RAC X Guard, 1/4 in x 50 ft BlueMax II Airless Hose, TSL 4 oz
- Maximum Flow Rate (GPM): 0.47
- Maximum Flow Rate (L/min): 1.8
- Maximum Sound Pressure Level (dB(A)): 90
- Maximum Tip Size (in): 0.021
- Maximum Working Pressure (bar): 228
- Maximum Working Pressure (kPa): 22800
- Maximum Working Pressure (MPa): 22.8
- Maximum Working Pressure (psi): 3300
- Minimum Generator Power (W): 3000
- Motor Type: DC
- Number of Guns: 1
- Outlet Paint Filter: 60 Mesh Stainless Steel Screen
- Overall Height (cm): 47
- Overall Height (in): 18.5
- Overall Height (mm): 470
- Overall Length (cm): 40.6
- Overall Length (in): 16
FINISHPRO II SPRAYER, 395, NA
GG 17C417
FINISHPRO II SPRAYER, 395, NA
FinishPro II 395 PC Electric Air-Assisted Airless Sprayer With features that make a great sprayer even better, the FinishPro II 395 PC is Graco’s premier solution to fine finishing. It delivers a high quality finish at a high production rate, and can handle the most challenging materials. Includes the features and output to quickly deliver high-quality finishes. SmartControl 1.0 with Digital Display- Increased spray performance
- Consistent spray fan without pressure fluctuations at all spraying pressures
- Digital display accurately shows spraying pressure
- Compressor is activated by the gun trigger—if you’re not spraying, it’s not running!
- Reduces jobsite noise, resulting in less fatigue
- Automatic shut-off reduces moisture entering the system and extends compressor life
- Pulling trigger delivers instant air to the gun with zero lag
- Release the trigger and SmartComp shuts off the compressor after 5 seconds
- Extends compressor life
- The most reliable pump on the market—lasts 2 times longer than the next leading brand
- Long-life V-Max Blue packings, Chromex rod and hardened stainless steel cylinder
- QuikAccess intake valve for fast cleaning or debris clearing
- Fast and easy on-the-job Pump Replacement System
- 1-minute jobsite replacement in 3 simple steps
- Pinless design eliminates the chance of losing parts during the change-out process
- Ideal for on-site finish jobs
- Delivers 3.2 ft³/min at 35 psi (0.1 m³/min at 2.4 bar)—enough air to break up the heaviest of materials
- Exclusive Pressure Unloader results in quieter operation
- Cooling coil reduces air temperature, extending the life of the critical components and providing safer operator handling
- Less overspray and increased pump life
- Sprays at lower pressures with less overspray
- Pre-orifice design produces a perfect airless finish
- Finer atomization and soft edges for easier overlapping
- Reduces prep and cleanup
- Includes solvent seal for hot solvents
- An industrial quality air-assisted spray gun that delivers superior finishing results
- Integrated air valve improves gun handling
- RAC X guard included
- Flat tip conversion kit included
- The flexibility to get into tight spaces—focus on the task, not the tool!
- Extremely lightweight in hand, which reduces fatigue
- Connects directly to the gun for maximum flexibility
- Flex Wrap hose skin protects from paint build up and increases hose durability
- Select air-assisted or airless modes, depending on what’s best for the application
- Simple, color-coded labels easily identify airless and air-assisted airless modes with a single selector switch
- One plug runs the entire unit, simplifying jobsite operation
ULTRAMAX SPRAYER, 695, HI, STANDARD
GG 17E574
ULTRAMAX SPRAYER, 695, HI, STANDARD
Graco 17E574 Ultra Max II 695 Standard Series Electric Airless Sprayer, Hi-Boy
The Ultra Max II 695 Standard Series Hi-Boy electric airless sprayer provides dependable performance with features that include a 2.0 hp brushless DC motor, industry-proven Chromex pump with 2X life, SmartControl 4.0, BlueLink Job & Sprayer Management System, the Contractor PC gun and much more.
Application: Everyday Reliability. Standard Series large electric airless sprayers are the industry standard for residential and commercial contractors looking for proven reliability to spray a wide variety of coatings with a variety of tip sizes on larger jobs.- Endurance Chromex Piston Pump
Lasts 2X Longer than competing pumps
Repack the pump in minutes with the new QuikPak Cartridge System
Faster cleaning with the QuikAccess intake foot valve
- SmartControl 4.0 with ProGuard Protection System
Precision pressure control
Lowest dead band at any pressure delivers a consistent spray fan without pressure fluctuation
ProGuard prevents electrical damage from extreme jobsite power conditions
WatchDog Pump Protection System automatically prevents pump damage if material supply is too low
- BlueLink Job & Sprayer Management App
Streamline Your Business
Track every sprayer: Exact location & hourly productivity
Know job progress: On demand productivity facts and reporting from anywhere
Maximize uptime: Set maintenance schedules, alerts, & jobsite notes
More info: graco.com/BlueLink
- Advantage Drive
The longest lasting drive
Hardened steel gears provide extremely quiet operation
Lifetime Drive Train Warranty
- FastFlush 2 System
Fast cleaning now even FASTER
Clean the pump 6X faster using ½ the water
High-velocity fluid flow delivered with 60% higher motor speed
- Easy Out Filter
Easy maintenance & less clogging
Exclusive inside-out filtering process ensures a quality finish
Vertical design for less mess
- Heavy-Duty Prime Valve
Maintenance-free high-pressure dumping capability
- Durable Cart Design with Kickstand
Withstands rugged environments
Design allows for easy, one-person bucket changes
Retractable handle doubles as hose storage
Kickstand for easy one person bucket changes
- Contractor PC Spray Gun
All-day comfort & control
Lightest weight gun in its class
Up to 50% lighter trigger pull force
E-Z Fit adjustable trigger length
Complete
ULTRAMAX SPRAYER, 1095, HI, STANDARD
GG 17E583
ULTRAMAX SPRAYER, 1095, HI, STANDARD
Graco 17E583 Ultra Max II 1095 Standard Series Electric Airless Sprayer
The Ultra Max II 1095 Standard Series electric airless sprayer has a 2.4 hp brushless DC motor to spray up to 1.2 gallons per minute and includes the industry-proven Chromex pump with 2X life, SmartControl 4.0, BlueLink Job & Sprayer Management System, the lightweight Contractor PC gun and more.
Application: Everyday Reliability. Standard Series large electric airless sprayers are the industry standard for residential and commercial contractors looking for proven reliability to spray a wide variety of coatings with a variety of tip sizes on larger jobs.- Endurance Chromex Piston Pump
Lasts 2X Longer than competing pumps
Repack the pump in minutes with the new QuikPak Cartridge System
Faster cleaning with the QuikAccess intake foot valve
- SmartControl 4.0 with ProGuard Protection System
Precision pressure control
Lowest dead band at any pressure delivers a consistent spray fan without pressure fluctuation
ProGuard prevents electrical damage from extreme jobsite power conditions
WatchDog Pump Protection System automatically prevents pump damage if material supply is too low
- BlueLink Job & Sprayer Management App
Streamline Your Business
Track every sprayer: Exact location & hourly productivity
Know job progress: On demand productivity facts and reporting from anywhere
Maximize uptime: Set maintenance schedules, alerts, & jobsite notes
More info: graco.com/BlueLink
- Advantage Drive
The longest lasting drive
Hardened steel gears provide extremely quiet operation
Lifetime Drive Train Warranty
- FastFlush 2 System
Fast cleaning now even FASTER
Clean the pump 6X faster using ½ the water
High-velocity fluid flow delivered with 60% higher motor speed
- Easy Out Filter
Easy maintenance & less clogging
Exclusive inside-out filtering process ensures a quality finish
Vertical design for less mess
- Heavy-Duty Prime Valve
Maintenance-free high-pressure dumping capability
- Durable Cart Design with Kickstand
Withstands rugged environments
Design allows for easy, one-person bucket changes
Retractable handle doubles as hose storage
Kickstand for easy one person bucket changes
- Contractor PC Spray Gun
All-day comfort & control
Lightest weight gun in its class
Up to 50% lighter trigger pull force
E-Z Fit adjustable trigger length
Complete gun rebuild in seconds with ProConnect cartridge
More info:
Mark V HD 3 In 1 Procontractor Series Electric Airless Sprayer
GG 17E606
Mark V HD 3 In 1 Procontractor Series Electric Airless Sprayer
MARK SPRAYER, X, STANDARD
GG 17E608
MARK SPRAYER, X, STANDARD
Graco 17E608 Mark X HD 3-in-1 Standard Series Electric Airless Sprayer
THE most powerful electric airless texture sprayer. The Mark X HD 240 volt is the sprayer of choice for serious professional contractors with nearly double the output of the Mark V HD. It easily sprays skim coat in a Level 5 finish, multiple texture finishes and the all primers and paints.
Application: Everyday Reliability. Mark HD Standard Series electric airless texture sprayers provide unmatched durability and performance, with the capability to handle the widest range of tip sizes, longer hose lengths and heavier coatings with ease.- Endurance Chromex Piston Pump
The most reliable pump
Lasts 2X Longer than the next leading brand
Long life ceramic and stainless steel balls included for maximum versatility
Faster cleaning with the QuikAccess intake foot valve
- MaxFlo 2 with Pack-Out Protection
Less pack-out, more productivity
Self-cleaning Vibra-Seal Technology eliminates material build-up
Continuous spraying with True Pack-Out Protection for more productivity
Optimized fluid passageways for the heaviest coatings
- BlueLink Job & Sprayer Management System
Streamline your business
Track every sprayer: Exact location & hourly productivity
Know job progress: On demand productivity facts and reporting from anywhere
Maximize uptime: Set maintenance schedules, alerts, & jobsite notes
- Worry-Free MaxPower Motor
Get more work done
Proven performance for all painting applications
High-torque brushless design with a Lifetime Warranty
Use longer cords, regardless of voltage fluctuations
- Precision Advantage Drive
The longest lasting drive
Improved jobsite conditions with extremely quiet operation
Lifetime Warranty
- WatchDog Pump Protection System
Prevents dry pumping damage
Automatically shuts pump down when if the material supply is too low
- Easy Out Pump Filter
Easy Pump Maintenance & Less Clogging
Inside-out design means less mess with fewer tip clogs
- Heavy-Duty Prime Valve
Maintenance-free high-pressure dumping capability
- Rugged, Durable Cart Design
Rugged and easy-to-move
Withstands tough jobsite conditions while absorbing impacts and vibrations
Easy hose storage with integrated hose wrap and telescoping handle
Easy loading with built-in lift handles
- Model: Mark HD
- Series: X
- Product Series: Standard
- Amperage (A): 16
- Compatible Replacement Pump: 17H831
- Convertible: Non-Convertible
- Engine Size (HP): 4
- Features: Endurance Chromex Pump, MaxFlo 2, BlueLink System, SmartControl 4.0, MaxPower Brushless, Advantage Drive, WatchDog, Easy Out Filter, Heavy-Duty Prime Valve
- Fluid Outlet Size (in): 1/2
- Fluid Outlet Size (mm): 12.7
- Fluid Outlet Thread Type: NPSM
GMAX 3400 SPRAYER, STANDARD
GG 17E825
GMAX 3400 SPRAYER, STANDARD
Graco 17E825 GMAX 3400 Standard Series Gas Airless Sprayer
The GMAX 3400 is the perfect sprayer for the entry-level contractor who is looking for maximum power in a lightweight, portable package.
Application: Everyday Reliability. Graco GMAX Standard Series gas-powered airless paint sprayers deliver unmatched durability and performance, with the capability to handle the widest range of tip sizes, longer hose lengths and heavier coatings with ease.- Endurance Chromex Piston Pump
The most reliable pump
Lasts 2X Longer than the next leading brand
QuikChange pump design allows you to swap the pump easily on the job
Faster cleaning with the QuikAccess intake foot valve
- SmartControl 3.0
Consistent spray fan & pressure control
Handles the widest range of coatings with the most consistent fan pattern
Lowest dead band at any pressure
- Precision Advantage Drive
The longest lasting drive
Hardened steel gears provide extremely quiet operation
Lifetime Warranty
- Heavy-Duty Prime Valve
Maintenance-free design withstands high-pressure dumping
- Durable Cart Design
Rugged and easy-to-maneuver
Thick chrome over steel and pneumatic wheels for tough jobsite conditions
Retractable handle doubles as coiled hose storage
- Honda® Engine
Reliable, powerful & easy-to-start
Oil Alert shuts down engine to prevent damage if oil level drops too low
Contractor preferred
- Contractor PC Spray Gun
All-day comfort & control
Lightest weight gun in its class
Up to 50% lighter trigger pull force
E-Z Fit adjustable trigger length
Complete gun rebuild in seconds with ProConnect cartridge
More info: graco.com/ContractorPC
- Jobsite Ready
Includes RAC X SwitchTip and 50 ft of BlueMax II hose
- Model: GMAX
- Series: 3400
- Product Series: Standard
- Convertible: Non-Convertible
- Engine Brand: Honda
- Engine Size (HP): 4
- Features: Endurance Chromex Pump, SmartControl 3.0, Honda Engine, Advantage Drive, Easy Out Filter, Heavy-Duty Prime Valve, Contractor PC Gun
- Fluid Inlet Size (in): 1-1/4
- Fluid Inlet Size (mm): 31.75
- Fluid Inlet Thread Type: UNF-2A
- Fluid Outlet Size (in): 1/4
- Fluid Outlet Size (mm): 6.35
- Fluid Outlet Thread Type: NPSM
- Hose Inlet Diameter (cm): 0.635
- Hose Inlet Diameter (in): 1/4
- Hose Inlet Diameter (mm): 6.35
- Includes: Contractor PC Gun, RAC X LP 517 Spray Tip, RAC X Guard, 1/4 in x 50 ft BlueMax II Airless Hose, TSL 4 oz
- Inlet Paint Strainer: 12 Mesh Stainless Steel Screen
- Maximum Flow Rate (GPM): 0.75
- Maximum Flow Rate (L/min): 2.8
- Maximum Sound Pressure Level (dB(A)): 86
- Maximum Tip Size (in): 0.027
- Maximum Tip Size Gu
GMAX II 3900 SPRAYER, STANDARD
GG 17E827
GMAX II 3900 SPRAYER, STANDARD
GMAX II 3900 Standard Series Gas Airless Sprayer, Hi-Boy Producing 65% more performance than the GMAX 3400, the GMAX II 3900 has the power and flow to handle up to two guns and is ideal for the professional contractor who sprays a wide variety of coatings. Everyday Reliability. Graco GMAX Standard Series gas-powered airless paint sprayers deliver unmatched durability and performance, with the capability to handle the widest range of tip sizes, longer hose lengths and heavier coatings with ease. Endurance Chromex Piston Pump- The most reliable pump
- Lasts 2X longer than the next leading brand
- Repack the pump in minutes with the new QuikPak Cartridge System
- QuikChange pump design allows you to swap the pump easily on the job
- Faster cleaning with the QuikAccess intake foot valve
- Consistent spray fan & pressure control
- Handles the widest range of coatings with the most consistent fan pattern
- Lowest dead band at any pressure
- The longest lasting drive
- Hardened steel gears provide extremely quiet operation
- Lifetime Warranty
- Easy maintenance & less clogging
- Exclusive inside-out filtering won't collapse to ensure a quality finish
- Vertical design for less mess
- Maintenance-free design withstands high-pressure dumping
- Rugged and easy-to-maneuver
- Thick chrome over steel and pneumatic wheels for tough jobsite conditions
- Retractable handle doubles as coiled hose storage
- Reliable, powerful & easy-to-start
- Oil Alert shuts down engine to prevent damage if oil level drops too low
- Contractor Preferred
- All-day comfort & control
- Lightest weight gun in its class
- Up to 50% lighter trigger pull force
- E-Z Fit adjustable trigger length
- Complete gun rebuild in seconds with ProConnect cartridge
- More info: graco.com/ContractorPC
- Includes RAC X SwitchTip and 50 ft of BlueMax II hose
GMAX II 5900 SPRAYER, STANDARD
GG 17E831
GMAX II 5900 SPRAYER, STANDARD
GMAX II 5900 Standard Series Gas Airless Sprayer, Hi-Boy With the ability to spray up to 1.6 gallons per minute, the GMAX II 5900 is the industry standard for the professional contractor who sprays a wide variety of coatings on residential, commercial and industrial jobs. Everyday Reliability. Graco GMAX Standard Series gas-powered airless paint sprayers deliver unmatched durability and performance, with the capability to handle the widest range of tip sizes, longer hose lengths and heavier coatings with ease. Endurance Chromex Piston Pump- The most reliable pump
- Lasts 2X longer than the next leading brand
- Repack the pump in minutes with the new QuikPak Cartridge System
- QuikChange pump design allows you to swap the pump easily on the job
- Faster cleaning with the QuikAccess intake foot valve
- Consistent spray fan & pressure control
- Handles the widest range of coatings with the most consistent fan pattern
- Lowest dead band at any pressure
- The longest lasting drive
- Hardened steel gears provide extremely quiet operation
- Lifetime Warranty
- Easy maintenance & less clogging
- Exclusive inside-out filtering won't collapse to ensure a quality finish
- Vertical design for less mess
- Maintenance-free design withstands high-pressure dumping
- Rugged and easy-to-maneuver
- Thick chrome over steel and pneumatic wheels for tough jobsite conditions
- Retractable handle doubles as coiled hose storage
- Reliable, powerful & easy-to-start
- Oil Alert shuts down engine to prevent damage if oil level drops too low
- Contractor Preferred
- All-day comfort & control
- Lightest weight gun in its class
- Up to 50% lighter trigger pull force
- E-Z Fit adjustable trigger length
- Complete gun rebuild in seconds with ProConnect cartridge
- More info: graco.com/ContractorPC
- Includes RAC X SwitchTip and 50 ft of BlueMax II hose
GMAX II 7900 SPRAYER, HD, PRO
GG 17E842
GMAX II 7900 SPRAYER, HD, PRO
Graco 17E842 GMAX II 7900 HD 3-in-1 ProContractor Series Gas Airless Sprayer
The GMAX II 7900 HD airless texture sprayer delivers the highest performance for the biggest jobs. With maximum flow and extreme durability, this sprayer does it all — skim coat in a Level 5 finish, drywall mud in a variety of finishes, all paints and primers and other heavy coatings.
Application: Work Smarter, Finish More Jobs. GMAX II HD ProContractor Series airless texture sprayers are designed to deliver improved speed & performance so you can get to the next jobsite faster and increase your profits.- Endurance Vortex MaxLife Piston Pump
Superior pump life
Breakthrough vortex rotating rod technology
Lasts 6X longer between repacks with innovative MaxLife technology
Oversized passages for high velocity flow to rotate piston for even wear Longest life packings and piston rod Long life ceramic and stainless steel balls included for maximum versatility
- MaxFlo 2 with Pack-Out Protection
Less pack-out, more productivity
Self-cleaning Vibra-Seal Technology eliminates material build-up
Continuous spraying with True Pack-Out Protection for more productivity
Optimized fluid passageways for the heaviest coatings
- SmartControl 3.0
Consistent spray fan & pressure control
Ideal for low overspray applications with the lowest dead band at any pressure
- ProConnect 2 Pump Replacement System
Eliminate costly downtime
Exchange pump in minutes
No tools, pins or parts to lose
- QuikReel Hose Management System
Easy hose managementDeploy and rewind up to 300 feet (90 meters) of hose in secondsNo twisting, kinking, and coilingUse only the hose you need — the rest stays on the reel - LED Display
Easy-to-read display provides quick reference to show:
Pressure read-out
Job/lifetime/gallon counter
Self-diagnostics
- Honda® GX Engine
Reliable, powerful & easy-to-start
Oil Alert shuts down engine to prevent damage if oil level drops too low
- Crushproof Inlet Strainer
Durable filtration
Stands up to harsh impacts to maintain even flow through filter
- Additional Features:
Rugged, Durable Cart Design
Heavy-Duty Prime Valve
Easy Out Pump Filter
WatchDog Pump Protection System
- Model: GMAX II HD
- Series: 7900
- Product Series: ProContractor
- Compatible Material: Stains, Oil, Lacquer, Primers, Fillers, Acrylics, Interior Emulsions, Exterior Emulsions, Latex, Plaster, Anti-Corrosive Paints, Fire-Retardant Paint, Intumescent
- Compatible Replacement Pump: 17H835
- Convertible: Non-Convertible
- Engine Brand: Honda
- Engine Size (HP): 6.5
- Features: Endurance Vortex MaxLife Pump, SmartControl 3.0, QuikReel, Honda Engine, Advantage Drive, ProConnect 2, Easy Out Filter, Crushproof Inlet Strainer, Heavy-Duty Prime Valve, WatchDog, LED Display, Contractor PC Gun
- Filter Mesh Size:
LINELAZER SPRAYER, V, 130HS, STANDARD 1 GUN
GG 17H447
LINELAZER SPRAYER, V, 130HS, STANDARD 1 GUN
Graco 17H447 LineLazer 130HS Standard Series Gas Hydraulic Airless Line Striper, 1 Manual Gun
The LineLazer 130HS is the preferred hydraulic airless striping unit that consistently delivers everyday striping performance with proven power, day in and day out.
- EasyMark Gun Adjustment System
Easy Gun Adjustments
Perfect gun alignment every time with easy-to-use guide mark system
2-gun capability with QuikSelect gun selector
- EZ Align Wheel System
Perfect Striper Tracking
Simple front wheel alignment, no special tools needed
- DualComfort Handlebar System
Easy Handlebar Adjustment
- Honda® GX Engine
Reliable, Easy-to-Start Power
Contractor-preferred — excellent power and proven reliability
Oil Alert shuts down engine to prevent damage if oil level drops too low
- Endurance Chromex Pump
Reliable, Long-Life Pump
Industry-best pump performance — field-proven design
Handle the most demanding materials with long-life rod treatment
4X harder than ordinary chrome
- High-Efficiency Hydraulic Motor
Uninterrupted Performance
No-Stall design
- High-Capacity Cooling System
Reduced Downtime
Innovative design allows the pump to run cooler and more efficiently
Easier and more thorough fluid changes
Reservoir cooling fins deflect more heat
No special hydraulic fluid needed
- Easy Out Pump Filter
Easy Pump Maintenance & Less Clogging
Inside-out design means less mess with fewer tip clogs
- Storage Compartment
New compartment for tips, guards and miscellaneous items
- Model: LineLazer
- Series: 130HS
- Product Series: Standard
- Compatible Material: Road-Marking Paint
- Compatible Surfaces: Pavement, Turf
- Engine Brand: Honda
- Engine Model: GX120
- Fuel Tank Capacity (gal): 0.66
- Fuel Tank Capacity (L): 2.5
- Gun Activation: Manual
- Includes: Tips, Guard, Gun, Hose, Pump Filter, TSL
- Maximum Flow Rate (GPM): 1.3
- Maximum Flow Rate (L/min): 4.9
- Maximum Sound Pressure Level (dB(A)): 96
- Maximum Tip Size (cm): 0.0940
- Maximum Tip Size (in): 0.037
- Maximum Tip Size (mm): 0.9398
- Maximum Working Pressure (bar): 227
- Maximum Working Pressure (kPa): 2270
- Maximum Working Pressure (psi): 3300
- Number of Colors: One Color
- Number of Guns: 1
- Number of Hoppers: 1
- Number of Pumps: 1
- Overall Height (cm): 113.03
- Overall Height (in): 44.5
- Overall Height (mm): 1130.3
- Overall Length (cm): 173.36
- Overall Length (in): 68.25
- Overall Length (mm): 1733.55
- Overall Width (cm): 87.0
- Overall Wi
LINELAZER SPRAYER, V, 3900, AUTO, 1A 1M, LSR
GG 17H452
LINELAZER SPRAYER, V, 3900, AUTO, 1A 1M, LSR
Graco 17H452 LineLazer V 3900 HP Automatic Series Gas Airless Line Striper, 1 Auto Gun, 1 Manual Gun
For those advanced striping jobs that require layout work or skip lines, the LineLazer V 3900 HP Automatic Series line striper includes additional features to help you work smarter, finish jobs faster and increase your profitability.
Application: The HP Automatic Series adds enhanced features that provide contractors automatic line production capability, including skip-lines, as well as real-time job performance data for proof-of-job requirements.- Automatic Paint Gun System
Automatically Stripe Skip-Lines
Reduce operator fatigue — push button line production
Quality solenoid driven system
- Auto-Layout II
Simplify Parking Lot Layout
SmartControl measures while you walk and puts down pre-marks
No need for measuring tape, string lines or aerosol cans
Cuts your layout time in half
- LiveLook Display with SmartControl
Striping Information At-A-Glance
Track, measure and control every aspect of your job
Accessible proof-of-job data from the J-Log System with USB Download
Consistent spraying pressure for perfect lines
- Honda GX Engine
Reliable, Easy-to-Start Power
Contractor-preferred — excellent power and proven reliability
Oil Alert shuts down engine to prevent damage if oil level drops too low
- EasyMark Gun Adjustment System
Easy Gun Adjustments
Perfect gun alignment every time with easy-to-use guide mark system
2-gun capability with QuikSelect gun selector
- EZ Align Wheel System
Perfect Striper Tracking
Simple front wheel alignment, no special tools needed
- DualComfort Handlebar System
Easy Handlebar Adjustment
- Endurance Chromex Pump
Reliable, Long-Life Pump
Industry-best pump performance — field-proven design
Handle the most demanding materials with long-life rod treatment
4X harder than ordinary chrome
- Additional Features
QuikSelect Gun Selector
Easy Out Pump Filter
LazerGuide 1700 Start/Stop Laser
- Model: LineLazer V
- Series: 3900
- Product Series: HP Automatic
- Attachments: LazerGuide 1700
- Bead System: Optional
- Compatible Material: Road-Marking Paint
- Compatible Surfaces: Pavement, Turf
- Engine Brand: Honda
- Engine Model: GX120
- Features: Auto-Layout II, Automatic Gun, J-Log Data Loggin System, On-Board Power
- Fuel Tank Capacity (gal): 0.66
- Fuel Tank Capacity (L): 2.5
- Gun Activation: 1 Automatic & 1 Manual
- Includes: LazerGuide 1700, Flex Plus Gun (2), LineLazer RAC 5 319 Spray Tip (2), LineLazer RAC 5 421 Spray Tip (2), RAC 5 Tip Guard (2), 3/8 in x 50 ft BlueMax II Airless Hose, 3/8 in x 3 ft BlueMax II Airless Whip Hose, TSL, 4 oz
- Maxim
LINELAZER SPRAYER, V, 5900, STANDARD 2 GUN
GG 17H455
LINELAZER SPRAYER, V, 5900, STANDARD 2 GUN
Graco 17H455 LineLazer V 5900 Standard Series Gas Airless Line Striper, 2 Manual Guns
When it’s time for 1 or 2-gun airless line striping performance with extra power, the LineLazer V 5900 Standard Series striper is an excellent choice. These durable striping machines deliver consistent lines for all your basic striping needs.
Application: The LineLazer V Standard Series is ideal for the higher production re-striping contractor completing and considering larger re-striping jobs with basic pattern applications requiring a single-color, single or dual gun striping solution.- LiveLook Display with SmartControl
Striping Information At-A-Glance
Track, measure and control every aspect of your job
Accessible proof-of-job data from the J-Log System with USB Download
Consistent spraying pressure for perfect lines
- Honda® GX Engine
Reliable, Easy-to-Start Power
Contractor-preferred — excellent power and proven reliability
Oil Alert shuts down engine to prevent damage if oil level drops too low
- EasyMark Gun Adjustment System
Easy Gun Adjustments
Perfect gun alignment every time with easy-to-use guide mark system
2-gun capability with QuikSelect gun selector
- DualComfort Handlebar System
Easy Handlebar Adjustment
- QuikSelect Gun Selector
Simple Gun Control
Independently control of two guns with one lever — solid/skip
- Endurance Chromex Pump
Reliable, Long-Life Pump
Industry-best pump performance — field-proven design
Handle the most demanding materials with long-life rod treatment
4X harder than ordinary chrome
- Easy Out Pump Filter
Easy Pump Maintenance & Less Clogging
Inside-out design means less mess with fewer tip clogs
- Model: LineLazer V
- Series: 5900
- Product Series: Standard
- Attachments: None
- Compatible Material: Road-Marking Paint
- Compatible Surfaces: Pavement, Turf
- Engine Brand: Honda
- Engine Model: GX160
- Fuel Tank Capacity (gal): 0.95
- Fuel Tank Capacity (L): 3.6
- Gun Activation: 2 Manual
- Includes: Flex Plus Gun (2), LineLazer RAC 5 319 Spray Tip (2), LineLazer RAC 5 421 Spray Tip (2), RAC 5 Tip Guard (2), 3/8 in x 50 ft BlueMax II Airless Hose, 3/8 in x 3 ft BlueMax II Airless Whip Hose, TSL, 4 oz
- Maximum Flow Rate (GPM): 1.6
- Maximum Flow Rate (L/min): 6.0
- Maximum Sound Pressure Level (dB(A)): 87.1
- Maximum Tip Size (cm): 0.0737
- Maximum Tip Size (in): 0.029
- Maximum Tip Size (mm): 0.7366
- <
LINELAZER SPRAYER, V, 5900, AUTO, 1A 1M, LSR
GG 17H457
LINELAZER SPRAYER, V, 5900, AUTO, 1A 1M, LSR
LineLazer V 5900 HP Automatic Series Gas Airless Line Striper, 1 Auto Gun, 1 Manual Gun When it’s time for 1 or 2-gun airless line striping performance with extra power, the LineLazer V 5900 HP Automatic Series striper is an excellent choice. These durable striping machines deliver higher performance and consistent lines for all your basic striping needs. The HP Automatic Series adds enhanced features that provide contractors automatic line production capability, including skip-lines, as well as real-time job performance data for proof-of-job requirements. Automatic Paint Gun System- Automatically Stripe Skip-Lines
- Reduce operator fatigue — push button line production
- Quality solenoid driven system
- Simplify Parking Lot Layout
- SmartControl measures while you walk and puts down pre-marks
- No need for measuring tape, string lines or aerosol cans
- Cuts your layout time in half
- Striping Information At-A-Glance
- Track, measure and control every aspect of your job
- Accessible proof-of-job data from the J-Log System with USB Download
- Consistent spraying pressure for perfect lines
- Valuable Job Information
- Proof of job = More striping opportunities.
- USB download capability allows you to capture and save all job data
- Reliable, Easy-to-Start Power
- Contractor-preferred — excellent power and proven reliability
- Oil Alert shuts down engine to prevent damage if oil level drops too low
- Easy Gun Adjustments
- Perfect gun alignment every time with easy-to-use guide mark system
- 2-gun capability with QuikSelect gun selector
- Perfect Striper Tracking
- Simple front wheel alignment, no special tools needed
- Easy Handlebar Adjustment
- Reliable, Long-Life Pump
- Industry-best pump performance — field-proven design
- Handle the most demanding materials with long-life rod treatment
- 4X harder than ordinary chrome
- QuikSelect Gun Selector
- Easy Out Pump Filter
- LazerGuide 1700 Start/Stop Laser
LINELAZER SPRAYER, V, 200HS, STANDARD 2 GUN
GG 17H461
LINELAZER SPRAYER, V, 200HS, STANDARD 2 GUN
Graco 17H461 LineLazer V 200HS Standard Series Gas Hydraulic Airless Line Striper, 2 Manual Guns
The LineLazer V 200HS Standard Series is a true workhorse designed for high performance striping on demanding jobs like large parking lots, airports, and city jobs that require precise lines.
Application: The LineLazer V Standard Series is ideal for the higher production re-striping contractor completing and considering larger re-striping jobs with basic pattern applications requiring a single-color, single or dual gun striping solution.- LiveLook Display with SmartControl
Striping Information At-A-Glance
Track, measure and control every aspect of your job
Accessible proof-of-job data from the J-Log System with USB Download
Consistent spraying pressure for perfect lines
- Honda® GX Engine
Reliable, Easy-to-Start Power
Contractor-preferred — excellent power and proven reliability
Oil Alert shuts down engine to prevent damage if oil level drops too low
- EasyMark Gun Adjustment System
Easy Gun Adjustments
Perfect gun alignment every time with easy-to-use guide mark system
2-gun capability with QuikSelect gun selector
- DualComfort Handlebar System
Easy Handlebar Adjustment
- Endurance Chromex Pump
Reliable, Long-Life Pump
Industry-best pump performance — field-proven design
Handle the most demanding materials with long-life rod treatment
4X harder than ordinary chrome
- High-Efficiency Hydraulic Motor
Uninterrupted Performance
No-Stall design
- High-Capacity Cooling System
Reduced Downtime
Innovative design allows the pump to run cooler and more efficiently
Easier and more thorough fluid changes
Reservoir cooling fins deflect more heat
No special hydraulic fluid needed
- QuikSelect Gun Selector
Simple Gun Control
Independently control of two guns with one lever — solid/skip
- Easy Out Pump Filter
Easy Pump Maintenance & Less Clogging
Inside-out design means less mess with fewer tip clogs
- Model: LineLazer V
- Series: 200HS
- Product Series: Standard
- Attachments: None
- Compatible Material: Road-Marking Paint
- Compatible Surfaces: Pavement, Turf
- Engine Brand: Honda
- Engine Model: GX200
- Fuel Tank Capacity (gal): 0.95
- Fuel Tank Capacity (L): 3.6
- Gun Activation: 2 Manual
LINELAZER SPRAYER, V, 200HS, AUTO, 1A 1M, LSR
GG 17H463
LINELAZER SPRAYER, V, 200HS, AUTO, 1A 1M, LSR
LineLazer V 200HS HP Automatic Series Gas Hydraulic Airless Line Striper, 1 Auto Gun, 1 Manual Gun With high production features, the LineLazer V 200HS HP Automatic Series is a true workhorse designed for high performance striping on the most demanding jobs like large parking lots, airports, and city jobs that require precise lines. The HP Automatic Series adds enhanced features that provide contractors automatic line production capability, including skip-lines, as well as real-time job performance data for proof-of-job requirements. Automatic Paint Gun System- Automatically Stripe Skip-Lines
- Reduce operator fatigue — push button line production
- Quality solenoid driven system
- Simplify Parking Lot Layout
- SmartControl measures while you walk and puts down pre-marks
- No need for measuring tape, string lines or aerosol cans
- Cuts your layout time in half
- Striping Information At-A-Glance
- Track, measure and control every aspect of your job
- Accessible proof-of-job data from the J-Log System with USB Download
- Consistent spraying pressure for perfect lines
- Valuable Job Information
- Proof of job = More striping opportunities.
- USB download capability allows you to capture and save all job data
- Reliable, Easy-to-Start Power
- Contractor-preferred — excellent power and proven reliability
- Oil Alert shuts down engine to prevent damage if oil level drops too low
- Easy Gun Adjustments
- Perfect gun alignment every time with easy-to-use guide mark system
- 2-gun capability with QuikSelect gun selector
- Perfect Striper Tracking
- Simple front wheel alignment, no special tools needed
- Easy Handlebar Adjustment
- Reliable, Long-Life Pump
- Industry-best pump performance — field-proven design
- Handle the most demanding materials with long-life rod treatment
- 4X harder than ordinary chrome
- High-Efficiency Hydraulic Motor
- High-Capacity Cooling System
- QuikSelect Gun Selector
- Easy Out Pump Filter
- LazerGuide 1700 Start/Stop Laser
LINELAZER SPRAYER, LL V, 250SPS, 2 GUN
GG 17H467
LINELAZER SPRAYER, LL V, 250SPS, 2 GUN
LineLazer V 250SPS HP Automatic Series Self-Propelled Gas Hydraulic Airless Line Striper, 2 Auto Guns With exclusive automatic paint guns and hydraulic power, the LineLazer V 250SPS HP Automatic Series is a self-propelled system that is ideal for large, heavy-duty line striping jobs including parking lots and road jobs. The HP Automatic Series adds enhanced features that provide contractors automatic line production capability, including skip-lines, as well as real-time job performance data for proof-of-job requirements. Automatic Paint Gun System- Automatically Stripe Skip-Lines
- Reduce operator fatigue — push button line production
- Quality solenoid driven system
- Striping Information At-A-Glance
- Simple to use and easy to see in all conditions
- Less Refilling
- Extended striping time with large capacity hopper
- Reliable, Easy-to-Start Power
- Contractor-preferred — excellent power and proven reliability
- Oil Alert shuts down engine to prevent damage if oil level drops too low
- Fast starting
- Easy Gun Adjustments
- Perfect gun alignment every time with easy-to-use guide mark system
- 2-gun capability with QuikSelect gun selector
- Straighter long lines
- Use up to six guns
- Simple operation
- Foam-filled, three-wheel design for stability
- Endurance Chromex Pump
- High-Efficiency Hydraulic Motor
- High-Capacity Cooling System
- Easy Out Pump Filter
- Flex Plus Guns
RTX SPRAYER, 5000PX, NA
GG 17H579
RTX SPRAYER, 5000PX, NA
TexSpray RTX 5000PX Texture Sprayer The RTX 5000PX is ideal for the large residential and commercial contractor needing a compact yet powerful texture sprayer capable of handling a wide variety of materials, such as synthetic stuccos, deck coatings, stone paints and more. The RTX Pro Exterior Series is configured to tackle exterior jobs of all sizes. Ideal for the large residential and commercial contractor needing a compact yet powerful texture sprayer capable of handling a wide variety of materials, such as synthetic stuccos, deck coatings, stone paints and more. Jobsite-Proven RotoFlex HD Pump- Features an innovative braided sling that provides extra support to the RotoFlex pump tube
- 5.0 gpm (19 lpm) output to get the job done quickly
- Trigger-Activated Power
- Automatically start & stop the pump and compressor
- Soft-start eliminates material blasts to ensure a quality finish
- Reduces noise and vibration while extending pump and compressor life
- More Air for Demanding Finishes
- High-output, maintenance-free design runs at lower RPM for longer life
- Improved Power and Performance
- Optimized single-motor design operates air compressor and RotoFlex pump
- Added Air Capability
- Allows external air to be used for demanding finishes
- Improved Handling & Flexibility
- Both hoses are permanently bonded together for easy handling
- Eliminate Costly Downtime
- Swap your RotoFlex pump in seconds - no tools required
- Maximum Control
- Quickly adjust material flow up or down with easy-to-read gauge
- Total Spray Control
- Select prime mode at the gun with Integrated Prime Selector
- Spray more material longer with durable aluminum design & oversized passages
- Increase Productivity by Over 20%
- Spray uniform, repeatable patterns with less material and pressure adjustment
- 2X harder than Standard WideTex tips
ULTRA SPRAYER, AC HH, 120V
GG 17M359
ULTRA SPRAYER, AC HH, 120V
Ultra Corded Handheld Airless Sprayer Pros agree. Airless handheld sprayers are the essential tool for turning small jobs around fast. Industry-tested Graco Ultra handhelds are the most advanced in the world, delivering unbeatable speed, flawless finish, and unmatched reliability. Ultra airless handheld sprayers are designed specifically for small interior, exterior and specialty projects with extreme portability and the ability to spray in seconds. Easily spray those small jobs without having to start-up your larger airless sprayer. Triax II Triple Piston Pump- Pump 3X more gallons before service
- Clean up in minutes
- No inlet check valve to get stuck - prime and spray in seconds
- Fast, on-the-job pump replacement with ProConnect
- On-The-Job Pump Replacement System
- One Tool Replacement - Replace the pump in 3 steps using only a screwdriver
- Spray at any hand speed with professional finish every time
- Precision pressure control delivers a consistent spray fan without pressure fluctuations
- Adjust motor speed to spray at any speed the job demands
- More control to deliver a professional finish – every job, every time
- Provides superior finish at low pressure
- Reverse-A-Clean (RAC) SwitchTips make cleaning tip clogs simple
- Large range of sizes available to meet the job requirements
- Works on all Graco Airless Sprayers – handhelds to large airless
- Fast cleanup with disposable liners and no suction tube to clean
- Easy Setup
- Click and fill design for faster refills
- Automatically strains paint while pouring
ULTRA SPRAYER, DC, HH, 120V
GG 17M363
ULTRA SPRAYER, DC, HH, 120V
Ultra Cordless Handheld Airless Sprayer Proven By Pros, Ultra Cordless sprayers provide the fastest way to finish small jobs. Deliver a perfect airless finish in seconds with fast, easy setup and the easy-to-clean design reduces cleanup to just a few minutes so you get to the next job quicker. Triax II Triple Piston Pump- Pump 3X more gallons before service
- Clean up in minutes
- No inlet check valve to get stuck - prime and spray in seconds
- Fast, on-the-job pump replacement with ProConnect
- Spray up to 1 gallon with each charge
- Compatible with any DEWALT 20V MAX Lithium Ion battery
- Comes standard with 2 batteries and charger
- 3-LED fuel gauge system allows immediate feedback on state of charge
- Lightweight design and 30% faster charge time (35 minutes)
- On-The-Job Pump Replacement System
- One Tool Replacement - Replace the pump in 3 steps using only a screwdriver
- Spray at any hand speed with professional finish every time
- Precision pressure control delivers a consistent spray fan without pressure fluctuations
- Adjust motor speed to spray at any speed the job demands
- More control to deliver a professional finish – every job, every time
- Provides superior finish at low pressure
- Reverse-A-Clean (RAC) SwitchTips make cleaning tip clogs simple
- Large range of sizes available to meet the job requirements
- Works on all Graco Airless Sprayers – handhelds to large airless
- Fast cleanup with disposable liners and no suction tube to clean
- Easy Setup
- Click and fill design for faster refills
- Automatically strains paint while pouring
ULTRAMAX DCHH SPRAYER, 120V
GG 17M367
ULTRAMAX DCHH SPRAYER, 120V
Graco 17M367 UltraMAX Cordless Handheld Airless Sprayer
Tested by Pros, the UltraMAX Cordless is the ONLY Handheld sprayer capable of spraying water-based, solvent and flammable architectural coatings. SmartControl technology delivers a flawless finish with no thinning required.
- Triax II Triple Piston Pump
Pump 3X more gallons before service
Clean up in minutes
No inlet check valve to get stuck - prime and spray in seconds
Fast, on-the-job pump replacement with ProConnect
- DEWALT® 20V MAX Lithium Ion Battery System
Spray up to 1 gallon with each charge
Compatible with any DEWALT 20V MAX Lithium Ion battery
Comes standard with 2 batteries
Lightweight design and 30% faster charge time (35 minutes)
- ProConnect
On-The-Job Pump Replacement System
One Tool Replacement - Replace the pump in 3 steps using only a screwdriver
- ProControl II
Adjust motor speed to spray at any speed the job demands
More control to deliver a professional finish – every job, every time
- Hot Solvent Compatible
Sprays hot solvents such as solvent-based lacquer
Sprays water, solvent and flammable based materials
- RAC X FF LP Tips
Provides superior finish at low pressure
Reverse-A-Clean (RAC) SwitchTips make cleaning tip clogs simple
Large range of sizes available to meet the job requirements
Works on all Graco Airless Sprayers – handhelds to large airless
- 32 oz FlexLiner Paint Bags
Fast cleanup with disposable liners and no suction tube to clean
Easy Setup
- FlexLiner QuickFill Funnel
Click and fill design for faster refills
Automatically strains paint while pouring
- Model: UltraMAX
- Series: Cordless
- Battery Capacity (Ah): 2
- Battery Chemistry: Lithium-ion
- Battery Voltage (V): 20
- Charging Time (min): 35
- Compatible Replacement Pump: 17P187
- Frame Configuration: Handheld
- Includes: RAC X FF LP 210 Spray Tip, RAC X FF LP 514 Spray Tip, RAC X Guard, 6 - 32 oz FlexLiner Bags, 2 - DEWALT 20V MAX 2.0 Ah Lithium Ion Batteries, DEWALT 20V MAX Battery Charger, 60 Mesh Filter, 100 Mesh Filter, Storage Bag, Pump Armor 4 oz, QuickFill Funnel
- Maximum Tip Size (in): 0.016
- Maximum Working Pressure (bar): 138
- Maximum Working Pressure (kPa): 13800
- Maximum Working Pressure (MPa): 14
- Maximum Working Pressure (psi): 2000
- Minimum Working Pressure (bar): 35
- Minimum Working Pressure (kPa): 3500
- Minimum Working Pressure (psi): 500
- Overall Height (cm): 26.7
- Overall Height (in): 10.5
- Overall Height (mm): 266.7
- Overall Length (cm): 36
- Overall Length (in): 14
- Overall Length (mm): 356
- Overall Width (cm): 12.7
- Overall Width (in): 5
- Overall Width (mm): 127
- Power Source: Battery Powered
- Pressure Control Type: ProControl II
- Pump Type: Triax Triple Piston
FINISHPRO HVLP SPRAYER, 9.0, PRO CONTRACTOR
GG 17N266
FINISHPRO HVLP SPRAYER, 9.0, PRO CONTRACTOR
Graco 17N266 FinishPro HVLP 9.0 ProContractor Series Sprayer
The FinishPro HVLP 9.0 ProContractor Series sprayer is loaded with features that provide on-demand power control and easier operation with independent material, air and spray fan controls to increase productivity on small to medium-sized fine finish jobs.
Application: Work Smarter, Finish More Jobs. Graco HVLP ProContractor Series sprayers include all Standard Series features plus additional features that offer the longest life, more convenience and greater control to improve profitability and produce a superior spray finish.- TurboForce Technology
Exclusive, proprietary turbine design builds more pressure through each stage, resulting in more performance at the gun
More air flow and air pressure means higher production with less thinning of material
Generates less heat and provides longer turbine life
- SmartStart Turbine
Automatically shuts off when not in use— if you’re not spraying, it’s not running
Reduces jobsite noise, resulting in less fatigue
Automatic shut-off reduces heat and extends turbine life
- TurboControl System with LED Display
Adjust the TurboForce turbine speed to match the performance you require
Reduces heat build up
Runs quieter
Extends turbine system life
50% longer hoses
- EDGE II Plus Gun
Ultimate control with independent user controls for material volume, air flow, and spray fan size
4X more productivity
FlexLiner Bag System
Learn more: EDGE II Plus Gun
- FlexLiner Bag System
FlexLiner Paint Bag System replaces traditional material cups
Spray at any angle with no adjustment – even upside down!
- Super-Flex Air Hose
15% lighter weight than other leading brands for more control at the gun
30 ft length included
No tools needed to connect
- Stainless Steel &Prime, Tough Box&Prime, Design
Rugged, all steel enclosure protects the turbine on the job and during transport
Smaller and lighter than previous models
- Utility Toolbox
Separate tool storage for extra needles and nozzles
- On-Board Gun and Cup Holder
Holds gun when not in use
Allows for easy paint refills with less spills
- Model: FinishPro
- Series: 9.0
- Product Series: ProContractor
- Gun Included: 1
- Includes: EDGE II Plus Gun, 32 oz FlexLiner System, #3 Quick-Rele
Payment options
