Gasket, 6" Sanitary

GG 16D246

Gasket, 6" Sanitary

Call for pricing

SOLOTECH ST25 PUMP, H25-MPM-FG-SS-A1-A1-0

GG 19C726

SOLOTECH ST25 PUMP, H25-MPM-FG-SS-A1-A1-0

SoloTech™ h25 Peristaltic Pump, 1 hp BLDC motor with gear reducer, .142-5.22 gpm, FDA Nitrile Hose, SST Sanitary Clamp Barb With only the hose in contact with the fluid being pumped and no check valves in line, Graco's SoloTech peristaltic pumps are ideal for materials other pumps can't handle. For metering and dosing flavorants, colorants, solids, abrasives, and slurries for food, beverage, and personal care products. Single Roller Design

The single roller compresses an engineered hose through a full 360 degrees of rotation. This reduces compressions, temperature, and friction; improving hose life.

Hose Design

SoloTech customers routinely experience fewer failures and perform much less maintenance compared to other pump technology.

Hose Barb Assembly

Easy to install or remove – no special tools needed
316 SST sanitary clamp design for easy cleaning

Removable Cover

Powder-coated aluminum cover with large sight window makes it easy to access and see internal parts
Optional leak detector kit mounts on cover

Pump Construction

Powder-coated aluminum housing reduces pump weight
Improved mounting flexibility with adjustable feet

Pumps are reversible and can be used to empty lines or clear blockages

$10,210.00

SANIFORCE PISTON PUMP, 6:1 DB ST

GG 24E837

SANIFORCE PISTON PUMP, 6:1 DB ST

6:1 Ratio SaniForce Stubby Double Ball Piston Pump with PTFE Packings

Graco's SaniForce 6:1 quick knockdown piston pumps are constructed of 300 series stainless steel. The air motor improves serviceability, increases efficiency and offers a lower cost of ownership. Our sanitary piston pumps are ideal for most food-related, cosmetic and personal care applications.

Quick Knockdown Sanitary Piston Pumps for Food and Personal Care Applications Most advanced air motor on the market Available in double-ball and priming piston designs Fluid transfer and supply of low to medium viscosity fluids Suitable to pump products such as: cosmetics, fruit juice concentrates, creamy candy fillings, ice cream variegates, jams and jellies

FDA-Compliant Shroud:

Easily removable FDA-compliant shroud to clean and access modular air valve - reducing downtime
Quick knockdown lowers are made with 300 series stainless steel for long-lasting durability

$8,940.00

SANIFORCE PISTON PUMP, 6:1 DB DL

GG 24E840

SANIFORCE PISTON PUMP, 6:1 DB DL

Graco 24E840 6:1 Ratio SaniForce Drum Length Double Ball Piston Pump with Bun-N, Nylon, Nitrile & Polychloroprene Packings

Graco&prime, s SaniForce 6:1 quick knockdown piston pumps are constructed of 300 series stainless steel. The air motor improves serviceability, increases efficiency and offers a lower cost of ownership. Our sanitary piston pumps are ideal for most food-related, cosmetic and personal care applications.

Application: Quick Knockdown Sanitary Piston Pumps for Food and Personal Care Applications

Most advanced air motor on the market
Available in double-ball and priming piston designs
Fluid transfer and supply of low to medium viscosity fluids
FDA-Compliant Shroud:
Air Inlet Size (in): 0.5
Air Inlet Size (mm): 12.7
Air Inlet Thread Gender: Female
Air Inlet Thread Type: NPSM
Application: Sanitary
Compatible Material: Food, Personal Care
Fluid Outlet Size (in): 1-1/2
Fluid Outlet Size (mm): 38.1
For Use With: Food, Personal Care, & Pharmaceutical
Maximum Air Consumption (SCFM): 29
Maximum Air Inlet Pressure (bar): 6.9
Maximum Air Inlet Pressure (kPa): 690
Maximum Air Inlet Pressure (psi): 100
Maximum Continuous Cycle Rate (CPM): 60
Maximum Flow Rate (GPM): 4
Maximum Flow Rate (L/min): 15.14
Maximum Intermittent Cycle Rate (CPM): 60
Maximum Working Pressure (bar): 44.8
Maximum Working Pressure (kPa): 4480
Maximum Working Pressure (MPa): 4.5
Maximum Working Pressure (psi): 650
Portable: Non-Portable
Pump Ratio: 6:1

$10,560.00

SANIFORCE PISTON PUMP, 5:1 DB DL

GG 24F195

SANIFORCE PISTON PUMP, 5:1 DB DL

Graco 24F195 5:1 Ratio SaniForce Double Ball Stubby Piston Pump with 4 in Inlet

The SaniForce 5:1 transfer piston pump is constructed of 300 series stainless steel, with a 2 inch (50.8 mm) sanitary tube flange outlet and can be fitted into open-head drums or directly inserted into a 4.5 inch (114 mm) closed-head drum bung. Our sanitary piston pumps are ideal for most food-related, cosmetic and personal care applications.

Application: Quick Knockdown Sanitary Piston Pumps for Food and Personal Care Applications

Available in double-ball and priming piston designs
Fluid transfer and supply of low to medium viscosity fluids
Suitable to pump products such as: cosmetics, fruit juice concentrates, creamy candy fillings, ice cream variegates, jams and jellies

Model: SaniForce

Air Inlet Size (in): 0.5
Air Inlet Size (mm): 12.7
Air Inlet Thread Gender: Female
Air Inlet Thread Type: NPSM
Application: Sanitary
Compatible Material: Food, Personal Care
Fluid Outlet Size (in): 2
Fluid Outlet Size (mm): 50.8
For Use With: Food, Personal Care, & Pharmaceutical
Maximum Air Consumption (SCFM): 75
Maximum Air Inlet Pressure (bar): 5.5
Maximum Air Inlet Pressure (kPa): 550
Maximum Air Inlet Pressure (psi): 80
Maximum Continuous Cycle Rate (CPM): 60
Maximum Flow Rate (GPM): 14
Maximum Flow Rate (L/min): 53
Maximum Intermittent Cycle Rate (CPM): 60
Maximum Working Pressure (bar): 28.3
Maximum Working Pressure (kPa): 2830
Maximum Working Pressure (MPa): 2.8
Maximum Working Pressure (psi): 410
Pump Ratio: 5:1

$24,040.00

SANIFORCE PISTON PUMP, 12:1 PP ST

GG 24F625

SANIFORCE PISTON PUMP, 12:1 PP ST

Graco 24F625 SaniForce 12:1 Stubby Piston Pump

Graco&prime, s sanitary piston pumps are ideal for most food-related, cosmetic and personal care applications. The SaniForce 12:1 sanitary piston pump has flow rates up to 8.5 gpm (32 lpm) and maximum viscosity up to 1,000,000 cps when mounted on a drum or bin unloader.

Application: Quick Knockdown Sanitary Piston Pumps for Food and Personal Care Applications

Quick knockdown lower
Suitable to pump products such as: cosmetics, fruit juice concentrates, creamy candy fillings, ice cream variegates, jams and jellies
Product highlights:
Air Inlet Thread Gender: Female
Air Inlet Thread Type: NPSM
Application: Sanitary
Compatible Material: Food, Personal Care
Fluid Outlet Size (in): 2
Fluid Outlet Size (mm): 50.8
For Use With: Food, Personal Care, & Pharmaceutical
Material: Stainless Steel
Maximum Air Consumption (SCFM): 128
Maximum Air Inlet Pressure (bar): 6.9
Maximum Air Inlet Pressure (kPa): 690
Maximum Air Inlet Pressure (psi): 100
Maximum Continuous Cycle Rate (CPM): 60
Maximum Flow Rate (GPM): 8.5
Maximum Flow Rate (L/min): 32.18
Maximum Intermittent Cycle Rate (CPM): 60
Maximum Working Pressure (bar): 100.4
Maximum Working Pressure (kPa): 10040
Maximum Working Pressure (MPa): 10
Maximum Working Pressure (psi): 1450
Portable: Non-Portable
Pump Ratio: 12:1

$18,590.00

SANIFORCE PISTON PUMP, 12:1 PPC ST

GG 24F626

SANIFORCE PISTON PUMP, 12:1 PPC ST

Graco 24F626 SaniForce 12:1 Stubby Piston Pump for Sticky Viscous Material

Application: Quick Knockdown Sanitary Piston Pumps for Food and Personal Care Applications

Quick knockdown lower
Suitable to pump products such as: cosmetics, fruit juice concentrates, creamy candy fillings, ice cream variegates, jams and jellies
Product highlights:
Air Inlet Thread Gender: Female
Air Inlet Thread Type: NPSM
Application: Sanitary
Compatible Material: Food, Personal Care
Fluid Outlet Size (in): 2
Fluid Outlet Size (mm): 50.8
For Use With: Food, Personal Care, & Pharmaceutical
Material: Stainless Steel
Maximum Air Consumption (SCFM): 128
Maximum Air Inlet Pressure (bar): 6.9
Maximum Air Inlet Pressure (kPa): 690
Maximum Air Inlet Pressure (psi): 100
Maximum Continuous Cycle Rate (CPM): 60
Maximum Flow Rate (GPM): 8.5
Maximum Flow Rate (L/min): 32.18
Maximum Intermittent Cycle Rate (CPM): 60
Maximum Working Pressure (bar): 100
Maximum Working Pressure (kPa): 10000
Maximum Working Pressure (MPa): 10
Maximum Working Pressure (psi): 1450
Portable: Non-Portable
Pump Ratio: 12:1

$19,210.00

SANIFORCE PISTON PUMP, 6:1 DB BL

GG 24F942

SANIFORCE PISTON PUMP, 6:1 DB BL

Graco 24F942 6:1 Ratio SaniForce Bin Length Double Ball Piston Pump

Application: Quick Knockdown Sanitary Piston Pumps for Food and Personal Care Applications

Most advanced air motor on the market
Available in double-ball and priming piston designs
Fluid transfer and supply of low to medium viscosity fluids
FDA-Compliant Shroud:
Air Inlet Thread Gender: Female
Air Inlet Thread Type: NPSM
Application: Sanitary
Compatible Material: Food, Personal Care
Fluid Outlet Size (in): 1-1/2
Fluid Outlet Size (mm): 38.1
For Use With: Food, Personal Care, & Pharmaceutical
Material: Stainless Steel
Maximum Air Consumption (SCFM): 29
Maximum Air Inlet Pressure (bar): 6.9
Maximum Air Inlet Pressure (kPa): 690
Maximum Air Inlet Pressure (psi): 100
Maximum Continuous Cycle Rate (CPM): 60
Maximum Flow Rate (GPM): 4
Maximum Flow Rate (L/min): 15.14
Maximum Intermittent Cycle Rate (CPM): 60
Maximum Working Pressure (bar): 44.8
Maximum Working Pressure (kPa): 4480
Maximum Working Pressure (MPa): 4.5
Maximum Working Pressure (psi): 650
Portable: Non-Portable
Pump Ratio: 6:1

$13,240.00

SANIFORCE PISTON PUMP, 6:1 DB DLF

GG 24G740

SANIFORCE PISTON PUMP, 6:1 DB DLF

Graco 24G740 6:1 Ratio SaniForce Drum Length RAM Double Ball Piston Pump

Application: Quick Knockdown Sanitary Piston Pumps for Food and Personal Care Applications

Most advanced air motor on the market
Available in double-ball and priming piston designs
Fluid transfer and supply of low to medium viscosity fluids
FDA-Compliant Shroud:
Air Inlet Thread Gender: Female
Air Inlet Thread Type: NPSM
Application: Sanitary
Compatible Material: Food, Personal Care
Fluid Outlet Size (in): 1-1/2
Fluid Outlet Size (mm): 38.1
For Use With: Food, Personal Care, & Pharmaceutical
Material: Stainless Steel
Maximum Air Consumption (SCFM): 29
Maximum Air Inlet Pressure (bar): 6.9
Maximum Air Inlet Pressure (kPa): 690
Maximum Air Inlet Pressure (psi): 100
Maximum Continuous Cycle Rate (CPM): 60
Maximum Flow Rate (GPM): 4
Maximum Flow Rate (L/min): 15.14
Maximum Intermittent Cycle Rate (CPM): 60
Maximum Working Pressure (bar): 44.8
Maximum Working Pressure (kPa): 4480
Maximum Working Pressure (MPa): 4.5
Maximum Working Pressure (psi): 650
Portable: Non-Portable
Pump Ratio: 6:1

$10,450.00

SANIFORCE PISTON PUMP, 2:1, STD LGTH, UHMW

GG 24R046

SANIFORCE PISTON PUMP, 2:1, STD LGTH, UHMW

2:1 Ratio SaniForce Standard Drum Length Double Ball Piston Pump with UHMWPE & FKM Packings

Easily transfer low to medium viscosity food and personal care materials up to 50,000 cps out of drums and totes. Graco's SaniForce 2:1 piston pump utilizes proven Graco air motor technology and smart sanitary design. The pump is extremely portable, weighing between 24 lb (10.8 kg) for the standard drum length and 26 lb (11.7 kg) for the long length. Plus, it fits through a standard bung hole.

Quick Knockdown Sanitary Piston Pump for Food and Personal Care Applications

SaniForce 2:1 Sanitary Piston Pump:

Flow rates range from 1.5 gpm (5.7 lpm) at 60 cpm, up to 2.5 gpm (9.5 lpm) at 100 cpm
Quick disconnect clamps for easy disassembly
Fluid transfer and supply of materials up to 50,000 cps
Suitable to pump products such as: fruit juice concentrates, creamy candy fillings, ice cream variegates, and cosmetics

SaniForce 2:1 Air Motor:

Removable, wash down safe, FDA-compliant shroud lets you easily access the air valve
Simple knuckle joint design for easy removal of air motor from lower

Easy Mounting:

SaniForce 2:1 pump fits through standard bung hole
FDA-compliant bung adapter accessory available for easy mounting

$5,860.00

SANIFORCE PISTON PUMP, 2:1, STD LGTH, PTFE

GG 24R047

SANIFORCE PISTON PUMP, 2:1, STD LGTH, PTFE

2:1 Ratio SaniForce Standard Drum Length Double Ball Piston Pump with PTFE & FKM Packings

Quick Knockdown Sanitary Piston Pump for Food and Personal Care Applications

SaniForce 2:1 Sanitary Piston Pump:

Flow rates range from 1.5 gpm (5.7 lpm) at 60 cpm, up to 2.5 gpm (9.5 lpm) at 100 cpm
Quick disconnect clamps for easy disassembly
Fluid transfer and supply of materials up to 50,000 cps
Suitable to pump products such as: fruit juice concentrates, creamy candy fillings, ice cream variegates, and cosmetics

Easy Mounting:

SaniForce 2:1 pump fits through standard bung hole
FDA-compliant bung adapter accessory available for easy mounting

$6,130.00

ELEVATOR, SANITARY, MOBILE, 6:1

GG 24V312

ELEVATOR, SANITARY, MOBILE, 6:1

Graco 24V312 6:1 Ratio SaniForce Elevator with Cart & Handle

Still using hoists and chains to unload your drums or bins? Graco&prime, s SaniForce Elevator is ideal for small to medium size food and personal care companies who currently unload less than 2 containers per hour. Use with Graco&prime, s SaniForce 2:1, 5:1 or 6:1 Piston Pumps to transfer small batches of low to medium viscosity fluids.

Application: Ideal for small to medium size companies who currently unload containers by scooping or using chains/hoists

FDA-compliant
Use in sanitary applications to transfer low to medium viscosity fluids
Designed to lower pumps into and lift pumps out of drums, bins and totes
Mobile and stationary options available

Model: SaniForce

Air Inlet Size (in): 0.5
Air Inlet Size (mm): 12.7
Air Inlet Thread Gender: Female
Air Inlet Thread Type: NPT
Application: Sanitary
Compatible Material: Food, Personal Care
For Use With: Food, Personal Care, Pharmaceutical
Includes: Cart and Handle
Material: Stainless Steel
Maximum Air Inlet Pressure (bar): 6.9
Maximum Air Inlet Pressure (kPa): 690
Maximum Air Inlet Pressure (psi): 100
Maximum Continuous Cycle Rate (CPM): 60
Maximum Intermittent Cycle Rate (CPM): 60
Maximum Working Pressure (bar): 41
Maximum Working Pressure (kPa): 4100
Maximum Working Pressure (MPa): 4.1
Maximum Working Pressure (psi): 600
Portable: Portable
Pump Ratio: 6:1

$35,160.00

SANIFORCE DRUM PUMP, 3A, 47", 115V

GG 25C418

SANIFORCE DRUM PUMP, 3A, 47", 115V

Graco 25C418 Sanitary Progressive Cavity Drum Pump System with 115 Volt Variable Speed Motor and 47 inch Lower

Reduce maintenance and sanitization time at your facility with the SaniForce Drum Pump, designed for easy cleaning with quick tri-clamp connections, no moving parts and easy transferability.

Easy Cleaning and Product Changeover
- Operational Flexibility Throughout Your Facility
  - Easy Mobility
    - Certified to FDA standards
    - Simple design to facilitate easy cleaning and reduce maintenance and downtime
    - Flow rates up to 35 GPM (132 LPM) with a smooth output of material
    - Easily transferable from container to container and adaptable to drums, totes and kettles
    Maximum Working Pressure (bar): 3
    Maximum Working Pressure (kPa): 296
    Maximum Working Pressure (psi): 43

$4,560.00

SANIFORCE DRUM PUMP, PC , 39", 115V

GG 25C420

SANIFORCE DRUM PUMP, PC , 39", 115V

115 VAC Variable Speed Progressive Cavity Drum Pump System with North American Plug Style and 39 inch Lower

Reduce maintenance and sanitization time at your facility with the SaniForce Drum Pump, designed for easy cleaning with quick tri-clamp connections, minimal moving parts and easy transferability.

Powered by variable speed electric motor Simple design to facilitate easy cleaning and reduce maintenance and downtime Flow rates up to 35 GPM (132 LPM) with a smooth output of material Easily transferable from container to container and adaptable to drums, totes and kettles

$8,020.00

SANIFORCE DRUM PUMP, PC RUM BL, FDA, 39, 3PH

GG 25C782

SANIFORCE DRUM PUMP, PC RUM BL, FDA, 39, 3PH

$9,490.00

SANIFORCE PISTON PUMP, TARY 5:1

GG 965520

SANIFORCE PISTON PUMP, TARY 5:1

5:1 Ratio Stubby Double Ball Sanitary Pump

Designed for high production applications, Monark pumps provides uniform and easily controlled delivery with its reliable Monark air motor.

Drum and stubby length models available for mounting and application flexibility Positive displacement, 2-ball piston design provides uniform and easily controlled delivery Stainless steel or carbon steel models available to handle various fluids Fluid return stanchion for circulation back to the pump Ultra High Molecular Weight Polyethylene (UHMWPE) packings for extended pump life in abrasive fluids

$13,040.00

SANIFORCE AODD PUMP, 2150FG-PA01AS13SSPTPTPT21

GG FA3111

SANIFORCE AODD PUMP, 2150FG-PA01AS13SSPTPTPT21

SaniForce 2150, 2" FG SST Pneumatic Diaphragm Pump, AL Center, SS Seats, PT Balls, PT Diaphragms Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 160 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 2 inch sanitary pump with flow rates up to 160 gpm (568 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process 316 stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.25 in. (6.3 mm)

$9,530.00

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSPTPTPT21

GG FD1111

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSPTPTPT21

Graco FD1111 SaniForce 1040 S/S AODD Pump with Flange Connection, 316 S/S Seats, PTFE O-Rings, Balls & Diaphragms

Graco’s SaniForce 1040 air-operated double diaphragm sanitary pumps have one of the best, most durable, lube-free air valves in the industry. Ideal for applications requiring high flow rates and portability, Graco’s dependable diaphragm pumps offer a wide range of food-grade elastomers including Santoprene, PTFE and overmolded EPDM/PTFE.

1.5 in (38 mm) Tri-clamp connection
All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)
High volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from original container to smaller receptacles - up to 10,000 cps
Suitable to pump such products as: concentrated fruit juices, sauces, pastes, starches, wine, food-grade oil, jams and jellies

Model: SaniForce
Series: 1040

Air Exhaust Port Size (in): 3/4
Air Exhaust Port Thread Gender: Female
Air Exhaust Port Thread Type: NPT
Air Inlet Size (in): 1/2
Air Inlet Thread Gender: Female
Air Inlet Thread Type: NPT
Application: Sanitary
Ball Material: PTFE
Center Section Material: Stainless Steel
Compatible Material: Edible Oil, Food and Personal Care
Connection Type: Tri-Clamp
Diaphragm Compatible Material: PTFE
Diaphragm Material: PTFE
Fluid Inlet Size (cm): 3.81
Fluid Inlet Size (in): 1
Fluid Inlet Size (mm): 38.1
Fluid Outlet Size (cm): 3.81
Fluid Outlet Size (in): 1
Fluid Outlet Size (mm): 38.1
Fluid Section Material: 316L Stainless Steel
For Use With: Food and Personal Care
Manifold Configuration: End Port
Manifold O-Ring Material: PTFE
Material: Stainless Steel
Maximum Air Consumption (SCFM): 50
Maximum Air Pressure (bar): 8
Maximum Air Pressure (kPa): 800
Maximum Air Pressure (MPa): 0.8
Maximum Air Pressure (psi): 120
Maximum Cycle Rate (CPM): 256
Maximum Flow Rate (GPM): 41
Maximum Flow Rate (L/min): 151
Maximum Fluid Pressure (bar): 8
Maximum Fluid Pressure (kPa): 800
Maximum Fluid Pressure (MPa): 0.8
Maximum Fluid Pressure (psi): 120
Maximum Fluid Pressure (bar): 8
Maximum Fluid Pressure (kPa): 800
Maximum Fluid Pressure (MPa): 0.8
Maximum Fluid Pressure (psi): 120
Maximum Operating Temperature (°C): 104
Maximum Operating Temperature (°F): 220
Maximum Solid Size (cm): 0.3175
Maximum Solid Size (in): 0.125
Maximum Solid Size (mm): 3.175
Overall Height (in): 16.1
Power Source: Pneumatic
Pump Ratio: 1:1

$5,370.00

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSPTPOPT21

GG FD1113

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSPTPOPT21

Graco FD1113 SaniForce 1040 Diaphragm Pump for Barrel-to-Barrel Transfer and Pump-Over

1.5 in (38 mm) Tri-clamp connection
All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)
High volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from original container to smaller receptacles - up to 10,000 cps
Suitable to pump such products as: concentrated fruit juices, sauces, pastes, starches, wine, food-grade oil, jams and jellies

Model: SaniForce
Series: 1040

Air Exhaust Port Size (in): 3/4
Air Exhaust Port Thread Gender: Female
Air Exhaust Port Thread Type: NPT
Air Inlet Size (in): 1/2
Air Inlet Thread Gender: Female
Air Inlet Thread Type: NPT
Application: Sanitary
Ball Material: PTFE
Center Section Material: Stainless Steel
Compatible Material: Edible Oil, Food and Personal Care
Connection Type: Tri-Clamp
Diaphragm Compatible Material: PTFE
Diaphragm Material: PTFE Overmold
Fluid Inlet Size (cm): 3.81
Fluid Inlet Size (in): 1
Fluid Inlet Size (mm): 38.1
Fluid Outlet Size (cm): 3.81
Fluid Outlet Size (in): 1
Fluid Outlet Size (mm): 38.1
Fluid Section Material: 316L Stainless Steel
For Use With: Food and Personal Care
Manifold Configuration: End Port
Manifold O-Ring Material: PTFE
Material: Stainless Steel
Maximum Air Consumption (SCFM): 50
Maximum Air Pressure (bar): 8
Maximum Air Pressure (kPa): 800
Maximum Air Pressure (MPa): 0.8
Maximum Air Pressure (psi): 120
Maximum Cycle Rate (CPM): 256
Maximum Flow Rate (GPM): 41
Maximum Flow Rate (L/min): 151
Maximum Fluid Pressure (bar): 8
Maximum Fluid Pressure (kPa): 800
Maximum Fluid Pressure (MPa): 0.8
Maximum Fluid Pressure (psi): 120
Maximum Fluid Pressure (bar): 8
Maximum Fluid Pressure (kPa): 800
Maximum Fluid Pressure (MPa): 0.8
Maximum Fluid Pressure (psi): 120
Maximum Operating Temperature (°C): 104
Maximum Operating Temperature (°F): 220
Maximum Solid Size (cm): 0.3175
Maximum Solid Size (in): 0.125
Maximum Solid Size (mm): 3.175
Overall Height (in): 16.1
Power Source: Pneumatic
Pump Ratio: 1:1

$6,420.00

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSCWPOPT21

GG FD1133

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSCWPOPT21

SaniForce 1040, 1" FG SST Pneumatic Diaphragm Pump, SS Center, SS Seats, CW Balls, PO Diaphragms Graco's SaniForce 1040, 1-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 41 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 1 inch sanitary pump with flow rates up to 41 gpm (155 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process PTFE/EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side 316 stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.125 in. (3.2 mm)

$7,020.00

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSPTPOEP21

GG FD1213

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSPTPOEP21

SaniForce 1040, 1" FG SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PO Diaphragms Graco's SaniForce 1040, 1-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 41 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 1 inch sanitary pump with flow rates up to 41 gpm (155 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process PTFE/EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side 316 stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.125 in. (3.2 mm)

$6,660.00

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSSPSPEP21

GG FD1222

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSSPSPEP21

Graco FD1222 SaniForce 1040 S/S AODD Pump with Flange Connection, 316 S/S Seats, EPDM O-Rings, Santoprene Balls & Diaphragms

1.5 in (38 mm) Tri-clamp connection
All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)
High volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from original container to smaller receptacles - up to 10,000 cps
Suitable to pump such products as: concentrated fruit juices, sauces, pastes, starches, wine, food-grade oil, jams and jellies

Model: SaniForce
Series: 1040

Air Exhaust Port Size (in): 3/4
Air Exhaust Port Thread Gender: Female
Air Exhaust Port Thread Type: NPT
Air Inlet Size (in): 1/2
Air Inlet Thread Gender: Female
Air Inlet Thread Type: NPT
Application: Sanitary
Ball Material: Santoprene
Center Section Material: Stainless Steel
Compatible Material: Edible Oil, Food and Personal Care
Connection Type: Tri-Clamp
Diaphragm Compatible Material: Santoprene
Diaphragm Material: Santoprene
Fluid Inlet Size (cm): 3.81
Fluid Inlet Size (in): 1
Fluid Inlet Size (mm): 38.1
Fluid Outlet Size (cm): 3.81
Fluid Outlet Size (in): 1
Fluid Outlet Size (mm): 38.1
Fluid Section Material: 316L Stainless Steel
For Use With: Food and Personal Care
Manifold Configuration: End Port
Manifold O-Ring Material: EPDM
Material: Stainless Steel
Maximum Air Consumption (SCFM): 50
Maximum Air Pressure (bar): 8
Maximum Air Pressure (kPa): 800
Maximum Air Pressure (MPa): 0.8
Maximum Air Pressure (psi): 120
Maximum Cycle Rate (CPM): 256
Maximum Flow Rate (GPM): 41
Maximum Flow Rate (L/min): 151
Maximum Fluid Pressure (bar): 8
Maximum Fluid Pressure (kPa): 800
Maximum Fluid Pressure (MPa): 0.8
Maximum Fluid Pressure (psi): 120
Maximum Fluid Pressure (bar): 8
Maximum Fluid Pressure (kPa): 800
Maximum Fluid Pressure (MPa): 0.8
Maximum Fluid Pressure (psi): 120
Maximum Solid Size (cm): 0.3175
Maximum Solid Size (in): 0.125
Maximum Solid Size (mm): 3.175
Power Source: Pneumatic
Pump Ratio: 1:1

$5,390.00

SANIFORCE AODD PUMP, 1590FG-PS01AS13SSPTPTPT21

GG FD2111

SANIFORCE AODD PUMP, 1590FG-PS01AS13SSPTPTPT21

Graco FD2111 SaniForce 1590 S/S AODD Pump with Sanitary Clamp Connection, S/S Center Section & Seats, PTFE O-Rings, Balls & Diaphragms

Graco’s SaniForce 1590 air-operated double diaphragm sanitary pumps have one of the best, most durable, lube-free air valves in the industry. Ideal for applications requiring high flow rates and portability, Graco’s dependable diaphragm pumps offer a wide range of food-grade elastomers including Santoprene, PTFE and overmolded EPDM/PTFE.

Application: 1-1/2 inch (38 mm) air-operated double diaphragm sanitary pump with flow rates up to 90 gpm (341 lpm) - ideal for food-related applications

SaniForce 1590 Double Diaphragm Pump
- Patented, lube-free air valve
  - PTFE/EPDM Overmolded Diaphragms
    Air Exhaust Port Size (in): 3/4
    Air Exhaust Port Thread Gender: Female
    Air Exhaust Port Thread Type: NPT
    Air Inlet Size (in): 1/2
    Air Inlet Thread Gender: Female
    Air Inlet Thread Type: NPT
    Application: Sanitary
    Ball Material: PTFE
    Center Section Material: Stainless Steel
    Compatible Material: Edible Oil, Food and Personal Care
    Connection Type: Tri-Clamp
    Diaphragm Compatible Material: PTFE
    Diaphragm Material: PTFE
    Fluid Inlet Size (cm): 5.08
    Fluid Inlet Size (in): 1-1/2
    Fluid Inlet Size (mm): 50.8
    Fluid Outlet Size (cm): 5.08
    Fluid Outlet Size (in): 1-1/2
    Fluid Outlet Size (mm): 50.8
    Fluid Section Material: 316L Stainless Steel
    For Use With: Food and Personal Care
    Manifold Configuration: End Port
    Manifold O-Ring Material: PTFE
    Material: Stainless Steel
    Maximum Air Consumption (SCFM): 130
    Maximum Air Pressure (bar): 8
    Maximum Air Pressure (kPa): 800
    Maximum Air Pressure (MPa): 0.8
    Maximum Air Pressure (psi): 120
    Maximum Cycle Rate (CPM): 200

$7,890.00

SANIFORCE AODD PUMP, 1590FG-PS01AS13SSSPSPPT21

GG FD2122

SANIFORCE AODD PUMP, 1590FG-PS01AS13SSSPSPPT21

Graco FD2122 SaniForce 1590 AODD Pump with Sanitary Clamp Connection, S/S Seats, PTFE O-Rings, Santoprene Balls & Diaphragms

Application: 1-1/2 inch (38 mm) air-operated double diaphragm sanitary pump with flow rates up to 90 gpm (341 lpm) - ideal for food-related applications

SaniForce 1590 Double Diaphragm Pump
- Patented, lube-free air valve
  - PTFE/EPDM Overmolded Diaphragms
    Air Exhaust Port Size (in): 3/4
    Air Exhaust Port Thread Gender: Female
    Air Exhaust Port Thread Type: NPT
    Air Inlet Size (in): 1/2
    Air Inlet Thread Gender: Female
    Air Inlet Thread Type: NPT
    Application: Sanitary
    Ball Material: Santoprene
    Center Section Material: Stainless Steel
    Compatible Material: Edible Oil, Food and Personal Care
    Connection Type: Tri-Clamp
    Diaphragm Compatible Material: Santoprene
    Diaphragm Material: Santoprene
    Fluid Inlet Size (cm): 5.08
    Fluid Inlet Size (in): 1-1/2
    Fluid Inlet Size (mm): 50.8
    Fluid Outlet Size (cm): 5.08
    Fluid Outlet Size (in): 1-1/2
    Fluid Outlet Size (mm): 50.8
    Fluid Section Material: 316L Stainless Steel
    For Use With: Food and Personal Care
    Manifold Configuration: End Port
    Manifold O-Ring Material: PTFE
    Material: Stainless Steel
    Maximum Air Consumption (SCFM): 130
    Maximum Air Pressure (bar): 8
    Maximum Air Pressure (kPa): 800
    Maximum Air Pressure (MPa): 0.8
    Maximum Air Pressure (psi): 120
    Maximum Cycle Rate (CPM): 200

$7,810.00

SANIFORCE AODD PUMP, 1590FG-PS01AS13SSCWPOPT21

GG FD2133

SANIFORCE AODD PUMP, 1590FG-PS01AS13SSCWPOPT21

Graco FD2133 SaniForce 1590 S/S AODD Pump with Sanitary Clamp Conn, S/S Center & Seats, PTFE O-Rings, Weighted CR Balls & Overmold PTFE Diaphragm

Application: 1-1/2 inch (38 mm) air-operated double diaphragm sanitary pump with flow rates up to 90 gpm (341 lpm) - ideal for food-related applications

SaniForce 1590 Double Diaphragm Pump
- Patented, lube-free air valve
  - PTFE/EPDM Overmolded Diaphragms
    Air Exhaust Port Size (in): 3/4
    Air Exhaust Port Thread Gender: Female
    Air Exhaust Port Thread Type: NPT
    Air Inlet Size (in): 1/2
    Air Inlet Thread Gender: Female
    Air Inlet Thread Type: NPT
    Application: Sanitary
    Ball Material: Polychloroprene Weighted
    Center Section Material: Stainless Steel
    Compatible Material: Edible Oil, Food and Personal Care
    Connection Type: Tri-Clamp
    Diaphragm Compatible Material: PTFE
    Diaphragm Material: PTFE Overmold
    Fluid Inlet Size (cm): 5.08
    Fluid Inlet Size (in): 1-1/2
    Fluid Inlet Size (mm): 50.8
    Fluid Outlet Size (cm): 5.08
    Fluid Outlet Size (in): 1-1/2
    Fluid Outlet Size (mm): 50.8
    Fluid Section Material: 316L Stainless Steel
    For Use With: Food and Personal Care
    Manifold Configuration: End Port
    Manifold O-Ring Material: PTFE
    Material: Stainless Steel
    Maximum Air Consumption (SCFM): 130
    Maximum Air Pressure (bar): 8
    Maximum Air Pressure (kPa): 800
    Maximum Air Pressure (MPa): 0.8
    Maximum Air Pressure (psi): 120
    Maximum Cycle Rate (CPM)

$9,570.00

Refine

Sanitary

GG 16D246

GG 19C726

SOLOTECH ST25 PUMP, H25-MPM-FG-SS-A1-A1-0

GG 24E837

SANIFORCE PISTON PUMP, 6:1 DB ST

GG 24E840

SANIFORCE PISTON PUMP, 6:1 DB DL

Graco 24E840 6:1 Ratio SaniForce Drum Length Double Ball Piston Pump with Bun-N, Nylon, Nitrile & Polychloroprene Packings

GG 24F195

SANIFORCE PISTON PUMP, 5:1 DB DL

Graco 24F195 5:1 Ratio SaniForce Double Ball Stubby Piston Pump with 4 in Inlet

GG 24F625

SANIFORCE PISTON PUMP, 12:1 PP ST

Graco 24F625 SaniForce 12:1 Stubby Piston Pump

GG 24F626

SANIFORCE PISTON PUMP, 12:1 PPC ST

Graco 24F626 SaniForce 12:1 Stubby Piston Pump for Sticky Viscous Material

GG 24F942

SANIFORCE PISTON PUMP, 6:1 DB BL

Graco 24F942 6:1 Ratio SaniForce Bin Length Double Ball Piston Pump

GG 24G740

SANIFORCE PISTON PUMP, 6:1 DB DLF

Graco 24G740 6:1 Ratio SaniForce Drum Length RAM Double Ball Piston Pump

GG 24R046

SANIFORCE PISTON PUMP, 2:1, STD LGTH, UHMW

GG 24R047

SANIFORCE PISTON PUMP, 2:1, STD LGTH, PTFE

GG 24V312

ELEVATOR, SANITARY, MOBILE, 6:1

Graco 24V312 6:1 Ratio SaniForce Elevator with Cart & Handle

GG 25C418

SANIFORCE DRUM PUMP, 3A, 47", 115V

Graco 25C418 Sanitary Progressive Cavity Drum Pump System with 115 Volt Variable Speed Motor and 47 inch Lower

GG 25C420

SANIFORCE DRUM PUMP, PC , 39", 115V

GG 25C782

GG 965520

SANIFORCE PISTON PUMP, TARY 5:1

GG FA3111

SANIFORCE AODD PUMP, 2150FG-PA01AS13SSPTPTPT21

GG FD1111

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSPTPTPT21

Graco FD1111 SaniForce 1040 S/S AODD Pump with Flange Connection, 316 S/S Seats, PTFE O-Rings, Balls & Diaphragms

GG FD1113

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSPTPOPT21

Graco FD1113 SaniForce 1040 Diaphragm Pump for Barrel-to-Barrel Transfer and Pump-Over

GG FD1133

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSCWPOPT21

GG FD1213

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSPTPOEP21

GG FD1222

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSSPSPEP21

Graco FD1222 SaniForce 1040 S/S AODD Pump with Flange Connection, 316 S/S Seats, EPDM O-Rings, Santoprene Balls & Diaphragms

GG FD2111

SANIFORCE AODD PUMP, 1590FG-PS01AS13SSPTPTPT21

Graco FD2111 SaniForce 1590 S/S AODD Pump with Sanitary Clamp Connection, S/S Center Section & Seats, PTFE O-Rings, Balls & Diaphragms

GG FD2122

SANIFORCE AODD PUMP, 1590FG-PS01AS13SSSPSPPT21

Graco FD2122 SaniForce 1590 AODD Pump with Sanitary Clamp Connection, S/S Seats, PTFE O-Rings, Santoprene Balls & Diaphragms

GG FD2133

SANIFORCE AODD PUMP, 1590FG-PS01AS13SSCWPOPT21

Graco FD2133 SaniForce 1590 S/S AODD Pump with Sanitary Clamp Conn, S/S Center & Seats, PTFE O-Rings, Weighted CR Balls & Overmold PTFE Diaphragm

Payment options
