GRACO INC. S10595

GG XDL56B

XDX SERIES 20 REEL, HOSE

Graco XDL56B XDX 20, Air/Water/Antifreeze/WWS, 1/2 in (13 mm) Inlet, 3/8 in X 65 ft (10 mm X 20 m) Hose, NPT, Truck/Bench Mount, Metallic Blue

Graco's heavy-duty XDX hose reel features a heavy-gauge, robust, dual-pedestal metal frame, steel spool, sealed components and innovative swivel design for high-quality performance in the most demanding applications.

• Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Optional Adjustable Arm - Easily change the arm position for your application, order with arm (XD models) or without (XN models)
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (107-198 meters) hose capacity for a wide variety of applications

• Series: 20

• Application: Air, Water, Antifreeze, WWS

• Color: Metallic Blue

• Frame Type: Dual Pedestal

• Hose Inside Diameter (in): 3/8
• Hose Inside Diameter (mm): 9.525
• Hose Length (ft): 65
• Hose Length (m): 20

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Male
• Inlet Thread Type: NPSM

• Maximum Temperature ( degree C): 87
• Maximum Temperature ( degree F): 190

• Maximum Working Pressure (psi): 300

• Minimum Temperature ( degree C): -28
• Minimum Temperature ( degree F): -20

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male

• Overall Height (in): 25.2
• Overall Height (mm): 640
• Overall Length (in): 23.4
• Overall Length (mm): 594
• Overall Width (in): 7.5
• Overall Width (mm): 191

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Air, Water, Antifreeze, WWS

GG V25DT200BA

IQ TIP SEAL VALVE, 25, 1.0/T, 200, ADJ/SOL, AMB

Graco V25DT200BA iQ Dispense Valve, Tip-Seal, Ambient, 0.039in (1.0mm) Tip, 7.87in (200mm) Nozzle, Direct Mount Solenoid

The iQ Tip Seal Dispense Valve offers high reliability for single component sealant and adhesive dispensing applications.

• Maximize dispense time while minimizing maintenance costs and effort
• Delivers precise, consistent dispensing with clean starts and stops
• Ideal for low to high viscosity materials
• Easy repeatable mounting for robotic and automated applications.
• 200mm nozzle is compatible with 200mm focal length vision systems

• Air Inlet Size (in): 5/16
• Air Inlet Thread Type: Push-to-Connect

• Ambient/Warm Melt/Hot Melt: Ambient
• Applicator Type: Tip-Seal

• Component Type: Single Component

• Fluid Inlet Size (in): 1/4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Gun Activation: Automatic

• Maximum Air Pressure (bar): 8.3

• Maximum Air Pressure (MPa): 0.83
• Maximum Air Pressure (psi): 120

• Maximum Fluid Pressure (bar): 276
• Maximum Fluid Pressure (MPa): 28
• Maximum Fluid Pressure (psi): 4000

• Maximum Fluid Pressure (bar): 276
• Maximum Fluid Pressure (MPa): 28
• Maximum Fluid Pressure (psi): 4000

• Mount Location: Direct Mount Solenoid
• Nozzle Size (in): 0.039
• Nozzle Size (mm): 1.0

• Outlet Block Length (in): 7.9
• Outlet Block Length (mm): 200

GG XDL56F

XDX SERIES 20 REEL, HOSE

Graco XDL56F XDX 20, Air/Water/Antifreeze/WWS, 1/2 in (13 mm) Inlet, 3/8 in X 65 ft (10 mm X 20 m) Hose, NPT, Truck/Bench Mount, Yellow

Graco's heavy-duty XDX hose reel features a heavy-gauge, robust, dual-pedestal metal frame, steel spool, sealed components and innovative swivel design for high-quality performance in the most demanding applications.

• Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Optional Adjustable Arm - Easily change the arm position for your application, order with arm (XD models) or without (XN models)
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (107-198 meters) hose capacity for a wide variety of applications

• Series: 20

• Application: Air, Water, Antifreeze, WWS

• Color: Yellow

• Frame Type: Dual Pedestal

• Hose Inside Diameter (in): 3/8
• Hose Inside Diameter (mm): 9.525
• Hose Length (ft): 65
• Hose Length (m): 20

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Male
• Inlet Thread Type: NPSM

• Maximum Temperature ( degree C): 87
• Maximum Temperature ( degree F): 190

• Maximum Working Pressure (psi): 300

• Minimum Temperature ( degree C): -28
• Minimum Temperature ( degree F): -20

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male

• Overall Height (in): 25.2
• Overall Height (mm): 640
• Overall Length (in): 23.4
• Overall Length (mm): 594
• Overall Width (in): 7.5
• Overall Width (mm): 191

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Air, Water, Antifreeze, WWS

GG XDM33D

XDX SERIES 10 REEL, HOSE

Graco XDM33D XDX 10, Oil, 1/2 in (13 mm) Inlet, 1/2 in X 35 ft (13 mm X 11 m) Hose, NPT, Truck/Bench Mount, Black

Graco's heavy-duty XDX hose reel features a heavy-gauge, robust, dual-pedestal metal frame, steel spool, sealed components and innovative swivel design for high-quality performance in the most demanding applications.

• Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Optional Adjustable Arm - Easily change the arm position for your application, order with arm (XD models) or without (XN models)
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (107-198 meters) hose capacity for a wide variety of applications

• Series: 10

• Application: Oil

• Color: Black

• Frame Type: Dual Pedestal

• Hose Inside Diameter (in): 1/2
• Hose Inside Diameter (mm): 12.7
• Hose Length (ft): 35
• Hose Length (m): 11

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Male
• Inlet Thread Type: NPSM

• Maximum Temperature ( degree C): 87
• Maximum Temperature ( degree F): 190

• Maximum Working Pressure (psi): 2000

• Minimum Temperature ( degree C): -28
• Minimum Temperature ( degree F): -20

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 1/2
• Outlet Size (mm): 12.7
• Outlet Thread Gender: Male

• Overall Height (in): 25.2
• Overall Height (mm): 640
• Overall Length (in): 18.5
• Overall Length (mm): 473
• Overall Width (in): 7.5
• Overall Width (mm): 191

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Oil

GG WR1223

RAC X WIDE RAC TIP, SPRAY, 1223

Graco WR1223 RAC X Wide RAC SwitchTip, 1223

The Reverse-A-Clean (RAC) 1223 RAC X Wide RAC SwitchTip produces a 24 inch fan and has a 0.023 inch orifice. Reverse the SwitchTip to easily clear clogs.

• RAC X - Wide RAC

  The Wide RAC covers double the area in the same time - increased flow rate ensures the proper mil build

  Wide RAC tips are made for high production, new construction applications which may require larger airless sprayers

• Superior Tip Design

  Locking tab ensures tip stays securely in guard

  Snapstip in spray or reverse position

  OneSeal tip installs with no tools

  Solvent seal available when using extremely hot solvents

• Easy to Identify Tip Size

  Large raised tip size numbers are always legible - even when covered with paint

• Model: RAC X
• Series: Wide RAC SwitchTip

• For Use With: RAC X HandTite Tip Guard

• Maximum Fan Width (cm): 61.0
• Maximum Fan Width (in): 24
• Maximum Fan Width (mm): 610

• Maximum Flow Rate (GPM): 0.57
• Maximum Flow Rate (L/min): 2.16

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 24
• Minimum Fan Width (mm): 610

• Orifice Diameter (in): 0.023

• Pattern Size (in): 24
• Pattern Size (mm): 609.6

GG WMC22G2

GG XDM33B

XDX SERIES 10 REEL, HOSE

Graco XDM33B XDX 10, Oil, 1/2 in (13 mm) Inlet, 1/2 in X 35 ft (13 mm X 11 m) Hose, NPT, Truck/Bench Mount, Metallic Blue

Graco's heavy-duty XDX hose reel features a heavy-gauge, robust, dual-pedestal metal frame, steel spool, sealed components and innovative swivel design for high-quality performance in the most demanding applications.

• Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Optional Adjustable Arm - Easily change the arm position for your application, order with arm (XD models) or without (XN models)
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (107-198 meters) hose capacity for a wide variety of applications

• Series: 10

• Application: Oil

• Color: Metallic Blue

• Frame Type: Dual Pedestal

• Hose Inside Diameter (in): 1/2
• Hose Inside Diameter (mm): 12.7
• Hose Length (ft): 35
• Hose Length (m): 11

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Male
• Inlet Thread Type: NPSM

• Maximum Temperature ( degree C): 87
• Maximum Temperature ( degree F): 190

• Maximum Working Pressure (psi): 2000

• Minimum Temperature ( degree C): -28
• Minimum Temperature ( degree F): -20

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 1/2
• Outlet Size (mm): 12.7
• Outlet Thread Gender: Male

• Overall Height (in): 25.2
• Overall Height (mm): 640
• Overall Length (in): 18.5
• Overall Length (mm): 473
• Overall Width (in): 7.5
• Overall Width (mm): 191

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Oil

GG WR1225

RAC X WIDE RAC TIP, SPRAY, 1225

Graco WR1225 RAC X Wide RAC SwitchTip, 1225

The Reverse-A-Clean (RAC) 1225 RAC X Wide RAC SwitchTip produces a 24 inch fan and has a 0.025 inch orifice. Reverse the SwitchTip to easily clear clogs.

• RAC X - Wide RAC

  The Wide RAC covers double the area in the same time - increased flow rate ensures the proper mil build

  Wide RAC tips are made for high production, new construction applications which may require larger airless sprayers

• Superior Tip Design

  Locking tab ensures tip stays securely in guard

  Snapstip in spray or reverse position

  OneSeal tip installs with no tools

  Solvent seal available when using extremely hot solvents

• Easy to Identify Tip Size

  Large raised tip size numbers are always legible - even when covered with paint

• Model: RAC X
• Series: Wide RAC SwitchTip

• For Use With: RAC X HandTite Tip Guard

• Maximum Fan Width (cm): 61.0
• Maximum Fan Width (in): 24
• Maximum Fan Width (mm): 610

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 24
• Minimum Fan Width (mm): 610

• Orifice Diameter (in): 0.025

• Pattern Size (in): 24
• Pattern Size (mm): 609.6

GG V25DT060DA

IQ TIP SEAL VALVE, 25, 1.0/T, 060, ADJ/RM, AMB

Graco V25DT060DA iQ Dispense Valve, Tip-Seal, Ambient, 0.039in (1.0mm) Tip, 2.36in (60mm) Nozzle, Remote Mount Solenoid

The iQ Tip Seal Dispense Valve offers high reliability for single component sealant and adhesive dispensing applications.

• Maximize dispense time while minimizing maintenance costs and effort
• Delivers precise, consistent dispensing with clean starts and stops
• Ideal for low to high viscosity materials
• Easy repeatable mounting for robotic and automated applications.
• 60mm nozzle is compatible with 60mm focal length vision systems

• Air Inlet Size (in): 1/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Ambient/Warm Melt/Hot Melt: Ambient
• Applicator Type: Tip-Seal

• Component Type: Single Component

• Fluid Inlet Size (in): 1/4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Gun Activation: Automatic

• Maximum Air Pressure (bar): 8.3

• Maximum Air Pressure (MPa): 0.83
• Maximum Air Pressure (psi): 120

• Maximum Fluid Pressure (bar): 276
• Maximum Fluid Pressure (MPa): 28
• Maximum Fluid Pressure (psi): 4000

• Maximum Fluid Pressure (bar): 276
• Maximum Fluid Pressure (MPa): 28
• Maximum Fluid Pressure (psi): 4000

• Mount Location: Remote Mount Solenoid
• Nozzle Size (in): 0.039
• Nozzle Size (mm): 1.0

• Outlet Block Length (in): 2.4
• Outlet Block Length (mm): 60

GG XDM65B

XDX SERIES 20 REEL, HOSE

Graco XDM65B XDX 20, Oil, 1/2 in (13 mm) Inlet, 1/2 in X 50 ft (13 mm X 15 m) Hose, NPT, Truck/Bench Mount, Metallic Blue

Graco's heavy-duty XDX hose reel features a heavy-gauge, robust, dual-pedestal metal frame, steel spool, sealed components and innovative swivel design for high-quality performance in the most demanding applications.

• Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Optional Adjustable Arm - Easily change the arm position for your application, order with arm (XD models) or without (XN models)
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (107-198 meters) hose capacity for a wide variety of applications

• Series: 20

• Application: Oil

• Color: Metallic Blue

• Frame Type: Dual Pedestal

• Hose Inside Diameter (in): 1/2
• Hose Inside Diameter (mm): 12.7
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Male
• Inlet Thread Type: NPSM

• Maximum Temperature ( degree C): 87
• Maximum Temperature ( degree F): 190

• Maximum Working Pressure (psi): 2000

• Minimum Temperature ( degree C): -28
• Minimum Temperature ( degree F): -20

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 1/2
• Outlet Size (mm): 12.7
• Outlet Thread Gender: Male

• Overall Height (in): 25.2
• Overall Height (mm): 640
• Overall Length (in): 23.4
• Overall Length (mm): 594
• Overall Width (in): 7.5
• Overall Width (mm): 191

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Oil

GG XF2323

GG XF1313

GG XDL65B

XDX SERIES 20 REEL, HOSE

Graco XDL65B XDX 20, Air/Water/Antifreeze/WWS, 1/2 in (13 mm) Inlet, 1/2 in X 50 ft (13 mm X 15 m) Hose, NPT, Truck/Bench Mount, Metallic Blue

Graco's heavy-duty XDX hose reel features a heavy-gauge, robust, dual-pedestal metal frame, steel spool, sealed components and innovative swivel design for high-quality performance in the most demanding applications.

• Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Optional Adjustable Arm - Easily change the arm position for your application, order with arm (XD models) or without (XN models)
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (107-198 meters) hose capacity for a wide variety of applications

• Series: 20

• Application: Air, Water, Antifreeze, WWS

• Color: Metallic Blue

• Frame Type: Dual Pedestal

• Hose Inside Diameter (in): 1/2
• Hose Inside Diameter (mm): 12.7
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Male
• Inlet Thread Type: NPSM

• Maximum Temperature ( degree C): 87
• Maximum Temperature ( degree F): 190

• Maximum Working Pressure (psi): 300

• Minimum Temperature ( degree C): -28
• Minimum Temperature ( degree F): -20

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 1/2
• Outlet Size (mm): 12.7
• Outlet Thread Gender: Male

• Overall Height (in): 25.2
• Overall Height (mm): 640
• Overall Length (in): 23.4
• Overall Length (mm): 594
• Overall Width (in): 7.5
• Overall Width (mm): 191

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Air, Water, Antifreeze, WWS

GG XHD001

GUARD, RAC XHD

Graco XHD001 RAC XHD Guard

Designed for spraying high-solids coatings at high pressures. With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required
• Change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Heavy-duty carbide tip

• For Use With: XTR5 and XTR7 Spray Gun

GG XHD005

GG XDM65F

XDX SERIES 20 REEL, HOSE

Graco XDM65F XDX 20, Oil, 1/2 in (13 mm) Inlet, 1/2 in X 50 ft (13 mm X 15 m) Hose, NPT, Truck/Bench Mount, Yellow

Graco's heavy-duty XDX hose reel features a heavy-gauge, robust, dual-pedestal metal frame, steel spool, sealed components and innovative swivel design for high-quality performance in the most demanding applications.

• Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Optional Adjustable Arm - Easily change the arm position for your application, order with arm (XD models) or without (XN models)
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (107-198 meters) hose capacity for a wide variety of applications

• Series: 20

• Application: Oil

• Color: Yellow

• Frame Type: Dual Pedestal

• Hose Inside Diameter (in): 1/2
• Hose Inside Diameter (mm): 12.7
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Male
• Inlet Thread Type: NPSM

• Maximum Temperature ( degree C): 87
• Maximum Temperature ( degree F): 190

• Maximum Working Pressure (psi): 2000

• Minimum Temperature ( degree C): -28
• Minimum Temperature ( degree F): -20

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 1/2
• Outlet Size (mm): 12.7
• Outlet Thread Gender: Male

• Overall Height (in): 25.2
• Overall Height (mm): 640
• Overall Length (in): 23.4
• Overall Length (mm): 594
• Overall Width (in): 7.5
• Overall Width (mm): 191

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Oil

GG XHD211

XHD RAC TIP, SPRAY, CYLINDER, 211

Graco XHD211 XHD RAC SwitchTip, .211

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.12
• Maximum Flow Rate (L/min): 0.45

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.011

GG W30CAS

KIT, PUMP, 30: 1, 75CC, SS, STD

Graco W30CAS Merkur Wet Cup Pump Assembly, 30:1, 75 cc Lower, 3 UHMWPE/2 PTFE Packings with Chromex, No Data Monitoring, Low Noise, SST

GG XHD115

XHD RAC TIP, SPRAY, CYLINDER, 115

Graco XHD115 XHD RAC SwitchTip, .115

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 10.2
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 102

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 2
• Minimum Fan Width (mm): 51

• Orifice Diameter (in): 0.015

GG XHD139

XHD RAC TIP, SPRAY, CYLINDER, 139

Graco XHD139 XHD RAC SwitchTip, .139

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 10.2
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 102

• Maximum Flow Rate (GPM): 1.63
• Maximum Flow Rate (L/min): 6.17

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 2
• Minimum Fan Width (mm): 51

• Orifice Diameter (in): 0.039

GG W03EAS

GG W15BAS

GG V25GT060DA

IQ TIP SEAL VALVE, 25, 1.7/T, 060, ADJ/RM, AMB

Graco V25GT060DA iQ Dispense Valve, Tip-Seal, Ambient, 0.067in (1.7mm) Tip, 2.36in (60mm) Nozzle, Remote Mount Solenoid

The iQ Tip Seal Dispense Valve offers high reliability for single component sealant and adhesive dispensing applications.

• Maximize dispense time while minimizing maintenance costs and effort
• Delivers precise, consistent dispensing with clean starts and stops
• Ideal for low to high viscosity materials
• Easy repeatable mounting for robotic and automated applications.
• 60mm nozzle is compatible with 60mm focal length vision systems

• Air Inlet Size (in): 1/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Ambient/Warm Melt/Hot Melt: Ambient
• Applicator Type: Tip-Seal

• Component Type: Single Component

• Fluid Inlet Size (in): 1/4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Gun Activation: Automatic

• Maximum Air Pressure (bar): 8.3

• Maximum Air Pressure (MPa): 0.83
• Maximum Air Pressure (psi): 120

• Maximum Fluid Pressure (bar): 276
• Maximum Fluid Pressure (MPa): 28
• Maximum Fluid Pressure (psi): 4000

• Maximum Fluid Pressure (bar): 276
• Maximum Fluid Pressure (MPa): 28
• Maximum Fluid Pressure (psi): 4000

• Mount Location: Remote Mount Solenoid
• Nozzle Size (in): 0.067
• Nozzle Size (mm): 1.7

• Outlet Block Length (in): 2.4
• Outlet Block Length (mm): 60

GG XHD217

XHD RAC TIP, SPRAY, CYLINDER, 217

Graco XHD217 XHD RAC SwitchTip, .217

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.17

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.017

GG WR1227

RAC X WIDE RAC TIP, SPRAY, 1227

Graco WR1227 RAC X Wide RAC SwitchTip, 1227

The Reverse-A-Clean (RAC) 1227 RAC X Wide RAC SwitchTip produces a 24 inch fan and has a 0.027 inch orifice. Reverse the SwitchTip to easily clear clogs.

• RAC X - Wide RAC

  The Wide RAC covers double the area in the same time - increased flow rate ensures the proper mil build

  Wide RAC tips are made for high production, new construction applications which may require larger airless sprayers

• Superior Tip Design

  Locking tab ensures tip stays securely in guard

  Snapstip in spray or reverse position

  OneSeal tip installs with no tools

  Solvent seal available when using extremely hot solvents

• Easy to Identify Tip Size

  Large raised tip size numbers are always legible - even when covered with paint

• Model: RAC X
• Series: Wide RAC SwitchTip

• For Use With: RAC X HandTite Tip Guard

• Maximum Fan Width (cm): 61.0
• Maximum Fan Width (in): 24
• Maximum Fan Width (mm): 610

• Maximum Flow Rate (GPM): 0.77
• Maximum Flow Rate (L/min): 2.91

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 24
• Minimum Fan Width (mm): 610

• Orifice Diameter (in): 0.027

• Pattern Size (in): 24
• Pattern Size (mm): 609.6

GG WMC82G2

THERM-O-FLOW SUPPLY UNIT, 68:1HCM, D200-200H, 480V, A

Graco WMC82G2 68:1 TOFw Check-Mate MaxLife, Heated, 55 Gal (200L) D200, 16 Gal (60L) Platen, Aluminum Platen, EPDM, 480V, ADM

Designed with more heat zones, the Therm-O-Flow Bulk Warm Melt Supply Pumps deliver superior temperature control and application flexibility.

• Designed specifically for sealants or adhesives applications that require a warm applied material for process controls up 158 degree F (70 degree C).
• With an heated pump and platen, you can heat up 3 heated hoses and 3 end of hose devices.
• Primary unit with ADM can be configured as a tandem system.
• Add a second heat zone expansion kit for up to 14 heated hoses and 14 heated end of hose devices on a tandem system for a total of 32 heated zones.
• Featuring the Graco Advanced Display Module - an easy-to-use HMI with graphic-based control screens.
• Complete integration possibilities through Ethernet/IP, PROFINET, PROFIBUS and DeviceNet or simple integration through discrete I/O.

• Model: Therm-O-Flow
• Series: Warm Melt

• Air Inlet Size (in): 3/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Ambient/Warm Melt/Hot Melt: Warm Melt
• Amperage (A): 8

• Container Type: Drum
• Control Options: Advanced Display Module

• Fluid Outlet Size (in): 1
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Input Cycle Rate (Hz): 50/60

• Lower Type: Check-Mate MaxLife

• Material Container Volume (gal): 55
• Material Container Volume (l): 200

• Maximum Air Inlet Pressure (bar): 10
• Maximum Air Inlet Pressure (MPa): 1
• Maximum Air Inlet Pressure (psi): 150

• Maximum Ambient Temperature ( degree C): 49
• Maximum Ambient Temperature ( degree F): 120

• Maximum Flow Rate (GPM): 3.2
• Maximum Flow Rate (L/min): 12

• Maximum Fluid Pressure (bar): 345
• Maximum Fluid Pressure (MPa): 34.5
• Maximum Fluid Pressure (psi): 5000
• Maximum Fluid Temperature ( degree C): 70
• Maximum Fluid Temperature ( degree F): 158

• Maximum Fluid Pressure (bar): 345
• Maximum Fluid Pressure (MPa): 34.5
• Maximum Fluid Pressure (psi): 5000
• Maximum Fluid Temperature ( degree C): 70
• Maximum Fluid Temperature ( degree F): 158

• Maximum Height (in): 118
• Maximum Height (mm): 2997

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Voltage (V ac): 480

• Maximum Working Pressure (bar): 344
• Maximum Working Pressure (MPa): 34.4

• Minimum Ambient Temperature ( degree C): 0
• Minimum Ambient Temperature ( degree F): 32

• Minimum Flow Rate (cc/min): 12000

• Minimum Height (in): 88
• Minimum Height (mm): 2235

• Minimum Voltage (V ac): 200

• Number of Wipers: Double Ring

• Overall Depth (in): 25
• Overall Depth (mm): 635

• Overall Width (in): 52
• Overall Width (mm): 1321

• Phase: 1, 3
• Plate Material: Aluminum

• Power Type: Pneumatic

• Pu

GG V25GT200DA

IQ TIP SEAL VALVE, 25, 1.7/T, 200, ADJ/RM, AMB

Graco V25GT200DA iQ Dispense Valve, Tip-Seal, Ambient, 0.067in (1.7mm) Tip, 7.87in (200mm) Nozzle, Remote Mount Solenoid

The iQ Tip Seal Dispense Valve offers high reliability for single component sealant and adhesive dispensing applications.

• Maximize dispense time while minimizing maintenance costs and effort
• Delivers precise, consistent dispensing with clean starts and stops
• Ideal for low to high viscosity materials
• Easy repeatable mounting for robotic and automated applications.
• 200mm nozzle is compatible with 200mm focal length vision systems

• Air Inlet Size (in): 1/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Ambient/Warm Melt/Hot Melt: Ambient
• Applicator Type: Tip-Seal

• Component Type: Single Component

• Fluid Inlet Size (in): 1/4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Gun Activation: Automatic

• Maximum Air Pressure (bar): 8.3

• Maximum Air Pressure (MPa): 0.83
• Maximum Air Pressure (psi): 120

• Maximum Fluid Pressure (bar): 276
• Maximum Fluid Pressure (MPa): 28
• Maximum Fluid Pressure (psi): 4000

• Maximum Fluid Pressure (bar): 276
• Maximum Fluid Pressure (MPa): 28
• Maximum Fluid Pressure (psi): 4000

• Mount Location: Remote Mount Solenoid
• Nozzle Size (in): 0.067
• Nozzle Size (mm): 1.7

• Outlet Block Length (in): 7.9
• Outlet Block Length (mm): 200

GG XHD121

XHD RAC TIP, SPRAY, CYLINDER, 121

Graco XHD121 XHD RAC SwitchTip, .121

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 10.2
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 102

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 2
• Minimum Fan Width (mm): 51

• Orifice Diameter (in): 0.021

GG XHD215

XHD RAC TIP, SPRAY, CYLINDER, 215

Graco XHD215 XHD RAC SwitchTip, .215

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.015

GG XHD225

XHD RAC TIP, SPRAY, CYLINDER, 225

Graco XHD225 XHD RAC SwitchTip, .225

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.025

GG XHD219

XHD RAC TIP, SPRAY, CYLINDER, 219

Graco XHD219 XHD RAC SwitchTip, .219

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.019

GG XHD229

XHD RAC TIP, SPRAY, CYLINDER, 229

Graco XHD229 XHD RAC SwitchTip, .229

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.90
• Maximum Flow Rate (L/min): 3.41

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.029

GG XHD221

XHD RAC TIP, SPRAY, CYLINDER, 221

Graco XHD221 XHD RAC SwitchTip, .221

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.021

GG XHD307

XHD RAC TIP, SPRAY, CYLINDER, 307

Graco XHD307 XHD RAC SwitchTip, .307

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.05
• Maximum Flow Rate (L/min): 0.19

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.007

GG XHD239

XHD RAC TIP, SPRAY, CYLINDER, 239

Graco XHD239 XHD RAC SwitchTip, .239

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 1.63
• Maximum Flow Rate (L/min): 6.17

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.039

GG XHD311

XHD RAC TIP, SPRAY, CYLINDER, 311

Graco XHD311 XHD RAC SwitchTip, .311

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.12
• Maximum Flow Rate (L/min): 0.45

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.011

GG XHD231

XHD RAC TIP, SPRAY, CYLINDER, 231

Graco XHD231 XHD RAC SwitchTip, .231

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 1.03
• Maximum Flow Rate (L/min): 3.90

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.031

GG XHD235

XHD RAC TIP, SPRAY, CYLINDER, 235

Graco XHD235 XHD RAC SwitchTip, .235

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 1.31
• Maximum Flow Rate (L/min): 4.96

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.035

GG XHD313

XHD RAC TIP, SPRAY, CYLINDER, 313

Graco XHD313 XHD RAC SwitchTip, .313

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.18
• Maximum Flow Rate (L/min): 0.68

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.013

GG XHD319

XHD RAC TIP, SPRAY, CYLINDER, 319

Graco XHD319 XHD RAC SwitchTip, .319

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.019

GG XHD309

XHD RAC TIP, SPRAY, CYLINDER, 309

Graco XHD309 XHD RAC SwitchTip, .309

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.09
• Maximum Flow Rate (L/min): 0.34

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.009

GG XHD315

XHD RAC TIP, SPRAY, CYLINDER, 315

Graco XHD315 XHD RAC SwitchTip, .315

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.015

GG XHD333

XHD RAC TIP, SPRAY, CYLINDER, 333

Graco XHD333 XHD RAC SwitchTip, .333

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 1.17
• Maximum Flow Rate (L/min): 4.43

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.033

GG XHD317

XHD RAC TIP, SPRAY, CYLINDER, 317

Graco XHD317 XHD RAC SwitchTip, .317

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.17

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.017

GG XHD327

XHD RAC TIP, SPRAY, CYLINDER, 327

Graco XHD327 XHD RAC SwitchTip, .327

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.74
• Maximum Flow Rate (L/min): 2.80

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.027

GG XHD331

XHD RAC TIP, SPRAY, CYLINDER, 331

Graco XHD331 XHD RAC SwitchTip, .331

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 1.03
• Maximum Flow Rate (L/min): 3.90

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.031

GG XHD411

XHD RAC TIP, SPRAY, CYLINDER, 411

Graco XHD411 XHD RAC SwitchTip, .411

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.12
• Maximum Flow Rate (L/min): 0.45

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.011

GG XHD417

XHD RAC TIP, SPRAY, CYLINDER, 417

Graco XHD417 XHD RAC SwitchTip, .417

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.17

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.017

GG XHD337

XHD RAC TIP, SPRAY, CYLINDER, 337

Graco XHD337 XHD RAC SwitchTip, .337

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 1.47
• Maximum Flow Rate (L/min): 5.56

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.037

GG XHD325

XHD RAC TIP, SPRAY, CYLINDER, 325

Graco XHD325 XHD RAC SwitchTip, .325

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.025

GG XHD341

XHD RAC TIP, SPRAY, CYLINDER, 341

Graco XHD341 XHD RAC SwitchTip, .341

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 1.80
• Maximum Flow Rate (L/min): 6.81

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.041

GG XHD409

XHD RAC TIP, SPRAY, CYLINDER, 409

Graco XHD409 XHD RAC SwitchTip, .409

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.09
• Maximum Flow Rate (L/min): 0.34

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.009

GG XHD323

XHD RAC TIP, SPRAY, CYLINDER, 323

Graco XHD323 XHD RAC SwitchTip, .323

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solventborne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.57
• Maximum Flow Rate (L/min): 2.16

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.023

GG XHD321

XHD RAC TIP, SPRAY, CYLINDER, 321

Graco XHD321 XHD RAC SwitchTip, .321

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.021

GG XHD419

XHD RAC TIP, SPRAY, CYLINDER, 419

Graco XHD419 XHD RAC SwitchTip, .419

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.019

GG XHD415

XHD RAC TIP, SPRAY, CYLINDER, 415

Graco XHD415 XHD RAC SwitchTip, .415

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.015

GG XHD421

XHD RAC TIP, SPRAY, CYLINDER, 421

Graco XHD421 XHD RAC SwitchTip, .421

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.021

GG XHD425

XHD RAC TIP, SPRAY, CYLINDER, 425

Graco XHD425 XHD RAC SwitchTip, .425

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.025

GG XHD413

XHD RAC TIP, SPRAY, CYLINDER, 413

Graco XHD413 XHD RAC SwitchTip, .413

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.18
• Maximum Flow Rate (L/min): 0.68

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.013

GG XHD423

XHD RAC TIP, SPRAY, CYLINDER, 423

Graco XHD423 XHD RAC SwitchTip, .423

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.57
• Maximum Flow Rate (L/min): 2.16

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.023

GG XHD429

XHD RAC TIP, SPRAY, CYLINDER, 429

Graco XHD429 XHD RAC SwitchTip, .429

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.90
• Maximum Flow Rate (L/min): 3.41

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.029

GG XHD427

XHD RAC TIP, SPRAY, CYLINDER, 427

Graco XHD427 XHD RAC SwitchTip, .427

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.74
• Maximum Flow Rate (L/min): 2.80

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.027

GG XHD435

XHD RAC TIP, SPRAY, CYLINDER, 435

Graco XHD435 XHD RAC SwitchTip, .435

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 1.31
• Maximum Flow Rate (L/min): 4.96

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.035

GG XHD431

XHD RAC TIP, SPRAY, CYLINDER, 431

Graco XHD431 XHD RAC SwitchTip, .431

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 1.03
• Maximum Flow Rate (L/min): 3.90

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.031

GG XHD441

XHD RAC TIP, SPRAY, CYLINDER, 441

Graco XHD441 XHD RAC SwitchTip, .441

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 1.80
• Maximum Flow Rate (L/min): 6.81

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.041

GG XHD437

XHD RAC TIP, SPRAY, CYLINDER, 437

Graco XHD437 XHD RAC SwitchTip, .437

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 1.47
• Maximum Flow Rate (L/min): 5.56

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.037

GG XHD545

XHD RAC TIP, SPRAY, CYLINDER, 545

Graco XHD545 XHD RAC SwitchTip, .545

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns
