INGERSOLL-RAND IR TOOL S12880

IR UH-100-M

IR UF-50-M

IR TRP-311-1

IR TRP-40-1

IR UH-75-M

IR TRP-580

IR VDA-723

IR VPAD-6

6" Vacuum Ready Vinyl Pad for Ingersoll Rand Sander

• For Use With: 4151
• For Use With: 4151-2
• For Use With: 4152
• For Use With: R036C-C1
• For Use With: R036C-C2
• For Use With: R036C-C3
• For Use With: R036C-S1
• For Use With: R036C-S2
• For Use With: R036C-S3

IR VSM-6183

IR W1110

IR W1120

IR W1A1

Air Chipping Hammer, 1" Stroke, 2300 BPM, Hex Shank Round Collar

Description: As the strongest chipping hammers in the Ingersoll Rand lineup, the W Series chipping hammers are ready to take on even the toughest of jobs.

Features And Benefits:

• Power: With a die cast aluminum housing and a swan neck handle, these tools are as ergonomic as they are powerful and have an excellent power-to-weight ratio, making handling a breeze.
• Durability: These hammers have a heavy duty front end featuring a threaded barrel and rubber buffered retainer for increased steel and retainer life, to last you a long time. Comes with a 1-year warranty.

Product Application and Uses:

These Air Percussive Chipping Hammers are designed for chipping, cutting, chiseling and breaking of hardened materials through repetitive application of linear impacts of a tool steel that is retained and driven by the chipper.

• Actuation/Throttle Type/Switch Type: Outside Trigger
• Air Consumption @ Load (cfm): 28
• Air Consumption @ Load (l/min): 793
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Blows per Min: 2500
• Bore Diameter (in): 1.13

• Collar Type: Round
• Color: Beige
• Configuration/Handle Type: Swan Neck
• Duty Rating: Industrial Duty

• Exhaust Location: Side - Adjustable

• Housing Material: Aluminum

• Max Pressure (bar): 6.2
• Min Hose Size (in): 1/2
• Muffler: No

• Power Source: Air Powered
• Product Length (in): 15.88

• Product Weight (lb): 14.75
• Retainer Type: Threaded barrel with rubber buffered

• Shank SIze (in): 0.58
• Shank Type: Hex

• Stroke Length (in): 1

• Warranty: 1-year

• Accessories: H3R-214-12
• Accessories: H3R-214-18
• Accessories: H3R-214B-12
• Accessories: H3R-214B-18
• Accessories: H3R-214D-12
• Accessories: H3R-214F-12
• Accessories: H3R-214F-18
• Accessories: H3R-214F-24
• Accessories: H3R-214F-36
• Accessories: H3R-214F-72
• Accessories: H3R-214F-9
• Accessories: H3R-214M-12
• Accessories: H3R-214M-18
• Accessories: H3R-214M-24
• Accessories: H3R-214M-36
• Accessories: H3R-214T-9
• Accessories: H3R-424-12
• Accessories: H3R-424-18
• Accessories: H3R-424-24

• Lubrication: 10P

IR W1A2

Air Chipping Hammer, 1" Stroke, 2300 BPM, Round Shank, Round Collar

Description: As the strongest chipping hammers in the Ingersoll Rand lineup, the W Series chipping hammers are ready to take on even the toughest of jobs.

Features And Benefits:

• Power: With a die cast aluminum housing and a swan neck handle, these tools are as ergonomic as they are powerful and have an excellent power-to-weight ratio, making handling a breeze.
• Durability: These hammers have a heavy duty front end featuring a threaded barrel and rubber buffered retainer for increased steel and retainer life, to last you a long time. Comes with a 1-year warranty.

Product Application and Uses:

These Air Percussive Chipping Hammers are designed for chipping, cutting, chiseling and breaking of hardened materials through repetitive application of linear impacts of a tool steel that is retained and driven by the chipper.

• Actuation/Throttle Type/Switch Type: Outside Trigger
• Air Consumption @ Load (cfm): 28
• Air Consumption @ Load (l/min): 793
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Blows per Min: 2500
• Bore Diameter (in): 1.13

• Collar Type: Round
• Color: Beige
• Configuration/Handle Type: Swan Neck
• Duty Rating: Industrial Duty

• Exhaust Location: Side - Adjustable

• Housing Material: Aluminum

• Max Pressure (bar): 6.2
• Min Hose Size (in): 1/2
• Muffler: No

• Power Source: Air Powered
• Product Length (in): 15.88

• Product Weight (lb): 14.75
• Retainer Type: Threaded barrel with rubber buffered

• Shank SIze (in): 0.68
• Shank Type: Round

• Stroke Length (in): 1

• Warranty: 1-year

• Accessories: H3R-215-12
• Accessories: H3R-215-36
• Accessories: H3R-215B-12
• Accessories: H3R-215B-18
• Accessories: H3R-215F-12
• Accessories: H3R-215F-18
• Accessories: H3R-215F-24
• Accessories: H3R-215F-36
• Accessories: H3R-215F-9
• Accessories: H3R-215J-12
• Accessories: H3R-215M-12
• Accessories: H3R-215M-18
• Accessories: H3R-215M-24
• Accessories: H3R-215M-9
• Accessories: H3R-215S-12
• Accessories: H3R-215T-9
• Accessories: H3R-423-12
• Accessories: H3R-423-36
• Accessories: H3R-423-48
• Accessories: H3R-423-60
• Accessories: H3R-423-9

• Lubrication: 10P

IR W22-118

IR W22-654

IR W3111

1/4 inch 20V Hex Cordless Impact Driver, 265 ft-lb Torque, Quick Change Retainer, Compact, Pistol, Bare Tool

Features And Benefits:

• PERFORMANCE: Powerful brushless motor delivers 3,180 In-lbs. fastening torque and 2800 rpm.
• COMPACT: Short 5.2inch tip-to-tail length enables working in enclosed spaces.
• VERSATILE: 3 speed modes with variable speed trigger to fine-tune for application.
• DURABLE: Impact-resistant design with comfortable over molded handle grip.
• LIGHT WEIGHT: Light 2.3 lbs. weight provides excellent control and maneuverability of tool.
• VISIBILITY: 360 degree shadowless LED light ring to fully eliminate shadows.
• COMPATIBLE: Cordless Impact Driver works with all IQV 20 batteries.

Product Application and Uses:

Cordless Impact Wrenches are designed to remove and install threaded fasteners.

• Includes: Bare tool only, batteries and charger sold separately or with other kits.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Blows per Min: 4200 (BL2022)
• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/4
• Drive Type: Hex
• Duty Rating: General Duty

• Forward Torque setting 1 (ft-lb): 70
• Forward Torque setting 1 (in-lb): 841
• Forward Torque setting 1 (nm): 95
• Forward Torque setting 2 (ft-lb): 140
• Forward Torque setting 2 (in-lb): 1682
• Forward Torque setting 2 (nm): 190
• Forward Torque setting 3 (ft-lb): 266
• Forward Torque setting 3 (in-lb): 3186
• Forward Torque setting 3 (nm): 360

• Hammer Case: Metal
• Housing Material: Impact and chemical-resistant composite housing
• Impact Mechanism: Ball and Cam

• Lumens: 34
• Max Free Speed (rpm): 2800
• Max Torque (ft-lb): 266
• Max Torque (in-lb): 3186
• Max Torque (nm): 360
• Motor: Brushless Motor

• Number of Batteries Required: 1
• Number of Power Settings: 3
• Power Source: Battery Powered
• Product Length (in): 5.2

• Product Width (in): 2.56
• Product Height (in): 8.31
• Product Height (in) (with Battery): 10.2
• Product Weight (lb): 2.26
• Product Weight (lb) (with Battery): 3.19 (BL2012)
• Product Weight (lb) (with Battery): 3.77 (BL2022)
• Recommended Forward Torque Range (ft-lb): 266
• Recommended Forward Torque Range (in-lb): 3186
• Recommended Forward Torque Range (nm): 360
• Retainer Type: Quick Change
• RPM Setting 1: 725

• RPM Setting 2: 1600
• Side to Center Distance (in): 1.28
• Side to Center Distance (mm): 33

• Sound Pressure/Power Db(A): 90 / 101
• Speed Setting: Variable Speed
• Standards/Certifications: UL/CSA/EN/IEC 62841-1, UL/CSA/EN/IEC 62841-2-3

• Tool Type: Mid-torque
• Tool Type: Compact
• Vibration Level (m/s2): 18.1
• Vibration Uncertainy K* (m/s2): 5.8
• Voltage DC: 20
• Warranty: 3-year tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: No Wireless Functionality

• Accessories: BC1124
• Accessories: BC1221

• Complete Tool Kits: W3111-K22
• Complete Tool Kits: W3111-K12-AR
• Complete Tool Kits: W3111-K12-BR
• Complete Tool Kits: W3111-K22-CN

IR W3111-K22

1/4 inch 20V Hex Cordless Impact Driver 2 Battery Kit, 265 ft-lb Torque, Quick Change Retainer, Pistol

Features And Benefits:

• PERFORMANCE: Powerful brushless motor delivers 3,180 In-lbs. fastening torque.
• COMPACT: Short 5.2inch tip-to-tail length enables working in enclosed spaces.
• VERSATILE: 3 speed modes with variable speed trigger to fine-tune for application.
• DURABLE: Impact-resistant design with comfortable over molded handle grip.
• LIGHT WEIGHT: Light 2.3 lbs. weight provides excellent control and maneuverability of tool.
• VISIBILITY: 360 degree shadowless LED light ring to fully eliminate shadows.
• COMPATIBLE: Cordless impact Driver works with all IQV 20 batteries.
• KIT INCLUDES: 1/4 inch Impact Driver, (1) 2.5 Ah Battery (1) 5.0Ah Battery, 20V Battery Charger.

Product Application and Uses:

Cordless Impact Wrenches are designed to remove and install threaded fasteners.

• Includes: W3111 1/4 inch Impact Driver, (1) 2.5 Ah Battery, (1) 5.0Ah Battery, 20V Battery Charger, Charger Cord, Manuals
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Blows per Min: 4200 (BL2022)
• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/4
• Drive Type: Hex
• Duty Rating: General Duty

• Forward Torque setting 1 (ft-lb): 70
• Forward Torque setting 1 (in-lb): 841
• Forward Torque setting 1 (nm): 95
• Forward Torque setting 2 (ft-lb): 140
• Forward Torque setting 2 (in-lb): 1682
• Forward Torque setting 2 (nm): 190
• Forward Torque setting 3 (ft-lb): 266
• Forward Torque setting 3 (in-lb): 3186
• Forward Torque setting 3 (nm): 360

• Hammer Case: Metal
• Housing Material: Impact and chemical-resistant composite housing
• Impact Mechanism: Ball and Cam

• Lumens: 34
• Max Free Speed (rpm): 2800
• Max Torque (ft-lb): 266
• Max Torque (in-lb): 3186
• Max Torque (nm): 360
• Motor: Brushless Motor

• Number of Batteries Required: 1
• Number of Power Settings: 3
• Power Source: Battery Powered
• Product Length (in): 5.2

• Product Width (in): 2.56
• Product Height (in): 8.31
• Product Height (in) (with Battery): 10.2
• Product Weight (lb): 2.26
• Product Weight (lb) (with Battery): 3.19 (BL2012)
• Product Weight (lb) (with Battery): 3.77 (BL2022)
• Recommended Forward Torque Range (ft-lb): 266
• Recommended Forward Torque Range (in-lb): 3186
• Recommended Forward Torque Range (nm): 360
• Retainer Type: Quick Change
• RPM Setting 1: 725

• RPM Setting 2: 1600
• Side to Center Distance (in): 1.28
• Side to Center Distance (mm): 33

• Sound Pressure/Power Db(A): 90 / 101
• Speed Setting: Variable Speed
• Standards/Certifications: UL/CSA/EN/IEC 62841-1, UL/CSA/EN/IEC 62841-2-3

• Tool Type: Mid-torque
• Tool Type: Compact
• Vibration Level (m/s2): 18.1
• Vibration Uncertainy K* (m/s2): 5.8
• Voltage DC: 20
• Warranty: 3-year tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: No Wireless Functionality

• Accessories: BC1124
• Accessories: BC1221
• Accessories: BL2022

• Bundle Kit: W3111:1<

IR W3131-K22

3/8in 20V Cordless Impact Wrench 2 Battery Kit, 400 ft-lb Torque, Compact, Friction Ring Retainer, Pistol

Features And Benefits:

• PERFORMANCE: Powerful brushless motor delivers up to 400 ft-lbs of breakaway torque.
• COMPACT: Short 5.2" tip-to-tail Length enables working in enclosed spaces.
• VERSATILE: 3 speed modes with variable speed trigger to fine-tune for application.
• DURABLE: Impact-resistant design with comfortable over molded handle grip.
• LIGHT WEIGHT: Light 2.3 lbs. weight provides excellent control and maneuverability of tool.
• VISIBILITY: 360 degree shadowless LED light ring to fully eliminate shadows.
• COMPATIBLE: Cordless impact wrench works with all IQV 20 batteries.
• KIT INCLUDES: 3/8in Impact Wrench, (1) 2.5 Ah Battery (1) 5.0Ah Battery, 20V Battery Charger.

Product Application and Uses:

Cordless Impact Wrenches are designed to remove and install threaded fasteners.

• Includes: W3131 3/8in Impact Wrench, (1) 2.5 Ah Battery (1) 5.0Ah Battery, 20V Battery Charger, Charger Cord, Manuals
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Blows per Min: 4200 (BL2022)
• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/8
• Drive Type: Square
• Duty Rating: General Duty

• Forward Torque setting 1 (ft-lb): 89
• Forward Torque setting 1 (in-lb): 1062
• Forward Torque setting 1 (nm): 120
• Forward Torque setting 2 (ft-lb): 148
• Forward Torque setting 2 (in-lb): 1770
• Forward Torque setting 2 (nm): 200
• Forward Torque setting 3 (ft-lb): 300
• Forward Torque setting 3 (in-lb): 3585
• Forward Torque setting 3 (nm): 405

• Hammer Case: Metal
• Housing Material: Impact and chemical-resistant composite housing
• Impact Mechanism: Ball and Cam

• Lumens: 34
• Max Free Speed (rpm): 2800
• Max Torque (ft-lb): 300
• Max Torque (in-lb): 3585
• Max Torque (nm): 405
• Motor: Brushless Motor

• Number of Batteries Required: 1
• Number of Power Settings: 3
• Nut-busting/Breakaway Torque (ft-lb): 402
• Nut-busting/Breakaway Torque (in-lb): 4824
• Nut-busting/Breakaway Torque (nm): 545
• Power Source: Battery Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 106.1 (BL2022)
• Product Length (in): 5.2

• Product Width (in): 2.56
• Product Height (in): 8.31
• Product Height (in) (with Battery): 10.2
• Product Weight (lb): 2.26
• Product Weight (lb) (with Battery): 3.19 (BL2012)
• Product Weight (lb) (with Battery): 3.77 (BL2022)
• Recommended Forward Torque Range (ft-lb): 300
• Recommended Forward Torque Range (in-lb): 3585
• Recommended Forward Torque Range (nm): 405
• Retainer Type: Friction Ring
• RPM Setting 1: 725

• RPM Setting 2: 1600
• Side to Center Distance (in): 1.28
• Side to Center Distance (mm): 33

• Sound Pressure/Power Db(A): 90 / 101
• Speed Setting: Variable Speed
• Standards/Certifications: UL/EN/IEC 62841-1, EN/IEC 62841-2-2

• Tool Type: Mid-torque
• Tool Type: Compact
• Vibration Level (m/s2): 18.1
• Vibration Uncertainy K* (m/s2): 5.8
• Voltage DC: 20
• Warranty: 3-year tool,

IR W3131

3/8in 20V Cordless Impact Wrench, 400 ft-lb Torque, Compact, Friction Ring Retainer, Pistol, Bare Tool

Description: From the brand you trust for precise, high-performance fastening tools - Ingersoll Rand grows its IQV 20 system with the W3131 20V 3/8in Impact Wrench. Its brushless motor delivers breakaway torque up to 400 ft-lbs. to quickly complete demanding applications. A compact form factor with 5.2" tip-to-tail length and weight under 2.3 lbs. provide excellent control and maneuverability in tight workspaces. With 3 speed modes and patented 360 degree LED light ring to fully eliminate shadows, the W3131 20V 3/8in Impact Wrench includes 3-year limited warranty and is compatible with all IQV 20 batteries.

Features And Benefits:

• PERFORMANCE: Powerful brushless motor delivers up to 400 ft-lbs of breakaway torque.
• COMPACT: Short 5.2" tip-to-tail Length enables working in enclosed spaces.
• VERSATILE: 3 speed modes with variable speed trigger to fine-tune for application.
• DURABLE: Impact-resistant design with comfortable over molded handle grip.
• LIGHT WEIGHT: Light 2.3 lbs. weight provides excellent control and maneuverability of tool.
• VISIBILITY: 360 degree shadowless LED light ring to fully eliminate shadows.
• COMPATIBLE: Cordless impact wrench works with all IQV 20 batteries.

Product Application and Uses:

Cordless Impact Wrenches are designed to remove and install threaded fasteners.

• Includes: Bare tool only, batteries and charger sold separately or with other kits.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Blows per Min: 4200 (BL2022)
• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/8
• Drive Type: Square
• Duty Rating: General Duty

• Forward Torque setting 1 (ft-lb): 89
• Forward Torque setting 1 (in-lb): 1062
• Forward Torque setting 1 (nm): 120
• Forward Torque setting 2 (ft-lb): 148
• Forward Torque setting 2 (in-lb): 1770
• Forward Torque setting 2 (nm): 200
• Forward Torque setting 3 (ft-lb): 300
• Forward Torque setting 3 (in-lb): 3585
• Forward Torque setting 3 (nm): 405

• Hammer Case: Metal
• Housing Material: Impact and chemical-resistant composite housing
• Impact Mechanism: Ball and Cam

• Lumens: 34
• Max Free Speed (rpm): 2800
• Max Torque (ft-lb): 300
• Max Torque (in-lb): 3585
• Max Torque (nm): 405
• Motor: Brushless Motor

• Number of Batteries Required: 1
• Number of Power Settings: 3
• Nut-busting/Breakaway Torque (ft-lb): 402
• Nut-busting/Breakaway Torque (in-lb): 4824
• Nut-busting/Breakaway Torque (nm): 545
• Power Source: Battery Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 106.1 (BL2022)
• Product Length (in): 5.2

• Product Width (in): 2.56
• Product Height (in): 8.31
• Product Height (in) (with Battery): 10.2
• Product Weight (lb): 2.26
• Product Weight (lb) (with Battery): 3.19 (BL2012)
• Product Weight (lb) (with Battery): 3.77 (BL2022)
• Recommended Forward Torque Range (ft-lb): 300
• Recommended Forward Torque Range (in-lb): 3585
• Recommended Forward Torque Range (nm): 405
• Retainer Type: Friction Ring
• RPM Setting 1: 725

• RPM Setting 2: 1600
• Side to Center D

IR W3151

1/2in 20V Cordless Impact Wrench, 450 ft-lb Torque, Compact, Friction Ring Retainer, Pistol, Bare Tool

Description: From the brand you trust for precise, high-performance fastening tools - Ingersoll Rand grows its IQV 20 system with the W3151 Compact Impact Wrench. Its brushless motor delivers breakaway torque up to 450 ft-lbs. to quickly complete demanding applications. A compact form factor with 5.3" tip-to-tail length and weight under 2.3 lbs. provide excellent control and maneuverability in tight workspaces. Including 3 speed modes and patented 360 degree LED light ring to fully eliminate shadows, the W3151 Compact Impact Wrench includes 3-year limited warranty and is compatible with all IQV 20 batteries.

Features And Benefits:

• PERFORMANCE: Powerful Brushless Motor Delivers up to 450 ft-lbs. of Breakaway Torque.
• COMPACT: Short 5.3" tip-to-tail length enables working in enclosed spaces.
• VERSATILE: 3 Speed modes with Variable Speed Trigger to Fine-Tune for Application.
• DURABLE: Impact-resistant design with comfortable over molded handle grip.
• LIGHT WEIGHT: Light 2.3 lbs. weight provides excellent control and maneuverability of tool.
• VISIBILITY: 360 degree shadowless LED light ring to fully eliminate shadows.
• COMPATIBLE: Cordless Impact wrench works with all IQV 20 batteries.

Product Application and Uses:

Cordless Impact Wrenches are designed to remove and install threaded fasteners.

• Includes: Bare tool only, batteries and charger sold separately or with other kits.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Blows per Min: 4200 (BL2022)
• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/2
• Drive Type: Square
• Duty Rating: General Duty

• Forward Torque setting 1 (ft-lb): 100
• Forward Torque setting 1 (in-lb): 1195
• Forward Torque setting 1 (nm): 135
• Forward Torque setting 2 (ft-lb): 181
• Forward Torque setting 2 (in-lb): 2168
• Forward Torque setting 2 (nm): 245
• Forward Torque setting 3 (ft-lb): 321
• Forward Torque setting 3 (in-lb): 3850
• Forward Torque setting 3 (nm): 435

• Hammer Case: Metal
• Housing Material: Impact and chemical-resistant composite housing
• Impact Mechanism: Ball and Cam

• Lumens: 34
• Max Free Speed (rpm): 2800
• Max Torque (ft-lb): 321
• Max Torque (in-lb): 3850
• Max Torque (nm): 435
• Motor: Brushless Motor

• Number of Batteries Required: 1
• Number of Power Settings: 3
• Nut-busting/Breakaway Torque (ft-lb): 450
• Nut-busting/Breakaway Torque (in-lb): 5400
• Nut-busting/Breakaway Torque (nm): 610
• Power Source: Battery Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 119.4 (BL2022)
• Product Length (in): 5.3

• Product Width (in): 2.56
• Product Height (in): 8.31
• Product Height (in) (with Battery): 10.2
• Product Weight (lb): 2.26
• Product Weight (lb) (with Battery): 3.19 (BL2012)
• Product Weight (lb) (with Battery): 3.77 (BL2022)
• Recommended Forward Torque Range (ft-lb): 321
• Recommended Forward Torque Range (in-lb): 3850
• Recommended Forward Torque Range (nm): 435
• Retainer Type: Friction Ring
• RPM Setting 1: 725

• RPM Setting 2: 1600
• Side to Cente

IR W3151-K22

1/2in 20V Cordless Impact Wrench 2 Battery Kit, 450 ft-lb Torque, Friction Ring Retainer, Pistol

Features And Benefits:

• PERFORMANCE: Powerful Brushless Motor Delivers up to 450 ft-lbs. of Breakaway Torque
• COMPACT: Short 5.3" tip-to-tail length enables working in enclosed spaces.
• VERSATILE: 3 Speed modes with Variable Speed Trigger to Fine-Tune for Application.
• DURABLE: Impact-resistant design with comfortable over molded handle grip.
• LIGHT WEIGHT: Light 2.3 lbs. weight provides excellent control and maneuverability of tool.
• VISIBILITY: 360 degree shadowless LED light ring to fully eliminate shadows.
• COMPATIBLE: Cordless Impact wrench works with all IQV 20 batteries.
• KIT INCLUDES: 1/2in Impact Wrench, (1) 2.5 Ah (1) 5.0Ah Batteries, 20V Battery Charger.

Product Application and Uses:

Cordless Impact Wrenches are designed to remove and install threaded fasteners.

• Includes: W3151 1/2in Impact Wrench, (1) 2.5 Ah (1) 5.0Ah Batteries, 20V Battery Charger, Charger Cord, Manuals
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Blows per Min: 4200
• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/2
• Drive Type: Square
• Duty Rating: General Duty

• Forward Torque setting 1 (ft-lb): 100
• Forward Torque setting 1 (in-lb): 1195
• Forward Torque setting 1 (nm): 135
• Forward Torque setting 2 (ft-lb): 181
• Forward Torque setting 2 (in-lb): 2168
• Forward Torque setting 2 (nm): 245
• Forward Torque setting 3 (ft-lb): 321
• Forward Torque setting 3 (in-lb): 3850
• Forward Torque setting 3 (nm): 435

• Hammer Case: Metal
• Housing Material: Impact and chemical-resistant composite housing
• Impact Mechanism: Ball and Cam

• Lumens: 34
• Max Free Speed (rpm): 2800
• Max Torque (ft-lb): 321
• Max Torque (in-lb): 3850
• Max Torque (nm): 435
• Motor: Brushless Motor

• Number of Batteries Required: 1
• Number of Power Settings: 3
• Nut-busting/Breakaway Torque (ft-lb): 450
• Nut-busting/Breakaway Torque (in-lb): 5400
• Nut-busting/Breakaway Torque (nm): 610
• Power Source: Battery Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 119.4 (BL2022)
• Product Length (in): 5.3

• Product Width (in): 2.56
• Product Height (in): 8.31
• Product Height (in) (with Battery): 10.2
• Product Weight (lb): 2.26
• Product Weight (lb) (with Battery): 3.19 (BL2012)
• Product Weight (lb) (with Battery): 3.77 (BL2022)
• Recommended Forward Torque Range (ft-lb): 321
• Recommended Forward Torque Range (in-lb): 3850
• Recommended Forward Torque Range (nm): 435
• Retainer Type: Friction Ring
• RPM Setting 1: 725

• RPM Setting 2: 1600
• Side to Center Distance (in): 1.28
• Side to Center Distance (mm): 33

• Sound Pressure/Power Db(A): 90 / 101
• Speed Setting: Variable Speed
• Standards/Certifications: UL/EN/IEC 62841-1, EN/IEC 62841-2-2

• Tool Type: Mid-torque
• Tool Type: Compact
• Vibration Level (m/s2): 18.1
• Vibration Uncertainy K* (m/s2): 5.8
• Voltage DC: 20
• Warranty: 3-year tool, 2-year Battery, 3-year Charg

IR W5111-54BK

IR W5111-K37

IR W5111-K40

IR W5111-K626

IR W5111-K54

IR W5111-K724

IR W5111-K727

IR W5130-K626

IR W5130-K727

IR W5130-K93

IR W5132-K105

IR W5133-K54

IR W5132-K75

IR W5132-KLED

IR W5133

3/8" 20V Cordless Impact Wrench, 550 ft-lb Torque, Friction Ring Retainer, Pistol, Bare Tool

Description: The Ingersoll Rand W5133 impact wrench enhances the features you demanded: increased durability with stronger internal parts, and increased access with its tapered front end. This next generation compact impact wrench packs 365 ft.-lbs. of MAX torque in a cordless compact unit that weighs only 5.3 lbs. (with a BL2022 battery). Tested by real technicians, ready to tackle real work.

Features And Benefits:

• Power: The brushless motor and impact mechanism are finely tuned to unleash a high power-to-weight ratio, with 550 ft.-lbs. of nut busting torque and 365 ft.-lbs. of MAX torque at 5.3 lbs (with BL2022 battery). The all-metal drivetrain and hammer mechanism are designed to provide technicians the power they need without adding extra weight to the tool and increases safety-release trigger.
• Control: With 4 power modes (MAX Power, Half Power, Wrench Tight, and Hand Tight), you can adjust a dial instead of changing tools to deliver the right amount of torque when you need it and eliminate rework. From brake calipers to valve covers and everything in between, there's no need to switch tools. The variable-speed switch with electronic brake provides MAX control of the tool.
• Durable: Protected by a chemical-resistant composite housing and a patented steel-reinforced frame, the W5133 is built to withstand repeated drops onto concrete and exposure to shop fluids. The IQV spark-free brushless technology and sealed, enhanced, lubricated reinforced bushing provide a longer-life motor you can rely on.
• Access: 6.5" tip-to-tail ergonomic design and lightweight build, the W5133 can easily access tight spaces, giving you access no matter where your work may be hiding. A built-in 360 degree LED light ring with task light mode and 4 dimmable settings casts a wide beam to give you excellent visibility with no shadows.
• Tapered hammer case / Front End
• Compatible with IQV 20 Series Battery System

Product Application and Uses:

Cordless impact wrenches are designed to remove and install threaded fasteners. Applications include brake calipers, valve covers, cylinder head cover removal, brake repairs, shock replacement, industrial and Mro.

• Includes: Bare tool only, batteries and charger sold separately or with other kits.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Blows per Min: 3300
• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/8
• Drive Type: Square
• Duty Rating: General Duty

• Forward Torque setting 1 (ft-lb): 2.2-8.9
• Forward Torque setting 1 (in-lb): 27-106
• Forward Torque setting 1 (nm): 3-12
• Forward Torque setting 2 (ft-lb): 9.6-24
• Forward Torque setting 2 (in-lb): 115-292
• Forward Torque setting 2 (nm): 13-33
• Forward Torque setting 3 (ft-lb): 240
• Forward Torque setting 3 (in-lb): 2876
• Forward Torque setting 3 (nm): 325
• Forward Torque setting 4 (ft-lb): 339
• Forward Torque setting 4 (in-lb): 4071
• Forward Torque setting 4 (nm): 460
• Free Speed Sound Pressure/Power Db(A): 85

• Hammer Case: Steel-lined Aluminum
• Head Width (in): 2.3
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Ball and Cam

• Lumens: 32
• Max Bolt Diameter (in): 7/16
• Max Free Speed (rpm): 2100
• Max Torque (ft-lb): 369
• Ma

IR W5133P-K626

Anvil Kit for Ingersoll Rand W5133P 3/8" Pin Style Drive

Product Application and Uses:

For use with Ingersoll Rand W5133P 3/8" Pin Style Drive

• For Use With: W5133P
• For Use With: W5133P-C1D2
• For Use With: W5133P-C1D2-K22
• For Use With: W5133P-K22

IR W5133-K93

IR W5133P-K22

3/8" 20V Cordless Impact Wrench 2 Battery Kit, 550 ft-lb Torque, Pin Retainer, Pistol

Description: The Ingersoll Rand W5133P impact wrench enhances the features you demanded: increased durability with stronger internal parts, and increased access with its tapered front end.

Features And Benefits:

• POWER: The brushless motor and impact mechanism are finely tuned to unleash a high power-to-weight ratio, with 550 ft.-lbs. of nut busting torque and 365 ft.-lbs. of MAX torque at 5.3 lbs (with BL2022 battery). The all-metal drivetrain and hammer mechanism are designed to provide technicians the power they need without adding extra weight to the tool.
• CONTROL: With 4 power modes (MAX Power, Half Power, Wrench Tight, and Hand Tight), you can adjust a dial instead of changing tools to deliver the right amount of torque when you need it and eliminate rework. From brake calipers to valve covers and everything in between, there's no need to switch tools. The variable-speed switch with electronic brake provides MAX control of the tool.
• DURABLE: Protected by a chemical-resistant composite housing and a patented steel-reinforced frame, the W5133P is built to withstand repeated drops onto concrete and exposure to shop fluids. The IQV spark-free brushless technology and sealed, enhanced, lubricated reinforced bushing provide a longer-life motor you can rely on.
• ACCESS: Thanks to its 6.5" tip-to-tail compact ergonomic design and lightweight build, the W5133P can easily access tight spaces, giving you access no matter where your work may be hiding. A built-in 360 degree LED light ring with task light mode and 4 dimmable settings casts a wide beam to give you excellent visibility with no shadows.
• Tapered hammer case / Front End
• Compatible with IQV 20 Series Battery System
• Pin anvil ensures positive socket retention
• Kit includes: 3/8" Compact Cordless Impact Wrench, 1 BL2022 5.0Ah Battery, 1 BL2012 2.5Ah Battery, 20V Battery Charger & Bag

Product Application and Uses:

Cordless impact wrenches are designed to remove and install threaded fasteners. Applications include industrial and MRO.

• Includes: W5133P 3/8" Cordless Impact Wrench, (2) BL2022 5.0Ah Batteries, 20V Battery Charger & Bag
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Blows per Min: 3300
• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/8
• Drive Type: Square
• Duty Rating: Industrial Duty

• Forward Torque setting 1 (ft-lb): 2.2-8.9
• Forward Torque setting 1 (in-lb): 27-106
• Forward Torque setting 1 (nm): 3-12
• Forward Torque setting 2 (ft-lb): 9.6-24
• Forward Torque setting 2 (in-lb): 115-292
• Forward Torque setting 2 (nm): 13-33
• Forward Torque setting 3 (ft-lb): 240
• Forward Torque setting 3 (in-lb): 2876
• Forward Torque setting 3 (nm): 325
• Forward Torque setting 4 (ft-lb): 339
• Forward Torque setting 4 (in-lb): 4071
• Forward Torque setting 4 (nm): 460

• Hammer Case: Steel-lined Aluminum
• Head Width (in): 2.3
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Ball and Cam

• Lumens: 32
• Max Bolt Diameter (in): 7/16
• Max Free Speed (rpm): 2100
• Max Torque (ft-lb): 369
• Max Torque (in-lb): 4425
• Max Torque (nm): 500
• Motor: Brushless Motor

• Number of Batteries Required: 1
• N

IR W5132-K40

IR W5133P

3/8" 20V Cordless Impact Wrench, 550 ft-lb Torque, Pin Retainer, Pistol

Description: The Ingersoll Rand W5133P impact wrench enhances the features you demanded: increased durability with stronger internal parts, and increased access with its tapered front end. This next generation compact impact wrench packs 365 ft.-lbs. of MAX torque in a cordless compact unit that weighs only 5.3 lbs. (with a BL2022 battery). Tested by real technicians, ready to tackle real work.

Features And Benefits:

• Power: The brushless motor and impact mechanism are finely tuned to unleash a high power-to-weight ratio, with 550 ft.-lbs. of nut busting torque and 365 ft.-lbs. of MAX torque at 5.3 lbs (with BL2022 battery). The all-metal drivetrain and hammer mechanism are designed to provide technicians the power they need without adding extra weight to the tool.
• Control: With 4 power modes (MAX Power, Half Power, Wrench Tight, and Hand Tight), you can adjust a dial instead of changing tools to deliver the right amount of torque when you need it and eliminate rework. From brake calipers to valve covers and everything in between, there's no need to switch tools. The variable-speed switch with electronic brake provides MAX control of the tool.
• Durable: Protected by a chemical-resistant composite housing and a patented steel-reinforced frame, the W5133P is built to withstand repeated drops onto concrete and exposure to shop fluids. The IQV spark-free brushless technology and sealed, enhanced, lubricated reinforced bushing provide a longer-life motor you can rely on.
• Access: Thanks to its 6.5" tip-to-tail compact ergonomic design and lightweight build, the W5133P can easily access tight spaces, giving you access no matter where your work may be hiding. A built-in 360 degree LED light ring with task light mode and 4 dimmable settings casts a wide beam to give you excellent visibility with no shadows.
• Tapered hammer case / Front End
• Compatible with IQV 20 Series Battery System
• Pin anvil ensures positive socket retention

Product Application and Uses:

Cordless impact wrenches are designed to remove and install threaded fasteners. Applications include industrial and MRO.

• Includes: Bare tool only, batteries and charger sold separately or with other kits.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Blows per Min: 3300
• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/8
• Drive Type: Square
• Duty Rating: Industrial Duty

• Forward Torque setting 1 (ft-lb): 2.2-8.9
• Forward Torque setting 1 (in-lb): 27-106
• Forward Torque setting 1 (nm): 3-12
• Forward Torque setting 2 (ft-lb): 9.6-24
• Forward Torque setting 2 (in-lb): 115-292
• Forward Torque setting 2 (nm): 13-33
• Forward Torque setting 3 (ft-lb): 240
• Forward Torque setting 3 (in-lb): 2876
• Forward Torque setting 3 (nm): 325
• Forward Torque setting 4 (ft-lb): 339
• Forward Torque setting 4 (in-lb): 4071
• Forward Torque setting 4 (nm): 460

• Hammer Case: Steel-lined Aluminum
• Head Width (in): 2.3
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Ball and Cam

• Lumens: 32
• Max Bolt Diameter (in): 7/16
• Max Free Speed (rpm): 2100
• Max Torque (ft-lb): 369
• Max Torque (in-lb): 4425
• Max Torque (nm): 500
• Motor: Brushless Motor

• Number

IR W5133-K365

Hanger Assembly Kit Replacement Part for Ingersoll Rand W5133 and W5153 Series Cordless Impact Wrenches

Product Application and Uses:

For use with Ingersoll Rand W5133, W5133P, W5153, W5153P cordless impact wrenches

• For Use With: IQV20-K201
• For Use With: W5133
• For Use With: W5133-K12
• For Use With: W5133-K22
• For Use With: W5133-K22-CN
• For Use With: W5133-K22-EU
• For Use With: W5133-K22-KR
• For Use With: W5133P
• For Use With: W5133P-C1D2
• For Use With: W5133P-C1D2-K22
• For Use With: W5133P-K22
• For Use With: W5153
• For Use With: W5153-K12
• For Use With: W5153-K22
• For Use With: W5153-K22-AUNZ
• For Use With: W5153-K22-CN
• For Use With: W5153-K22-EU
• For Use With: W5153-K22-JP
• For Use With: W5153-K22-KR
• For Use With: W5153-K22-SGHK
• For Use With: W5153-K22A-EU

• For Use With: W5153P
• For Use With: W5153P-C1D2
• For Use With: W5153P-C1D2-K22
• For Use With: W5153P-K22

IR W5133-K22

3/8" 20V Cordless Impact Wrench 2 Battery Kit, 550 ft-lb Torque, Friction Ring Retainer, Pistol

Features And Benefits:

• Power: The brushless motor and impact mechanism are finely tuned to unleash a high power-to-weight ratio, with 550 ft.-lbs. of nut busting torque and 365 ft.-lbs. of MAX torque at 5.3 lbs (with BL2022 battery).. The all-metal drivetrain and hammer mechanism are designed to provide technicians the power they need without adding extra weight to the tool.
• Control: With 4 power modes (MAX Power, Half Power, Wrench Tight, and Hand Tight), you can adjust a dial instead of changing tools to deliver the right amount of torque when you need it and eliminate rework. From brake calipers to valve covers and everything in between, there's no need to switch tools. The variable-speed switch with electronic brake provides MAX control of the tool.
• Durable: Protected by a chemical-resistant composite housing and a patented steel-reinforced frame, the W5133 is built to withstand repeated drops onto concrete and exposure to shop fluids. The IQV spark-free brushless technology and sealed, enhanced, lubricated reinforced bushing provide a longer-life motor you can rely on.
• Access: 6.5" tip-to-tail compact ergonomic design and lightweight build, the W5133 can easily access tight spaces, giving you access no matter where your work may be hiding. A built-in 360 degree COB LED light casts a wide beam to give you excellent visibility with no shadows.
• Tapered hammer case / Front End
• Shadowless LED light ring with task light mode and 4 dimmable settings
• 6.5" tip-to-tail design at only 5.3 lbs (with BL2022 battery)
• Compatible with IQV 20 Series Battery System
• Kit Includes: 3/8" Compact Cordless Impact Wrench, 1 BL2022 5.0Ah Battery, 1 BL2012 2.5Ah Battery, 20V Battery Charger & Bag

Product Application and Uses:

Cordless impact wrenches are designed to remove and install threaded fasteners. Applications include brake calipers, valve covers, cylinder head cover removal, brake repairs, shock replacement, industrial and Mro.

• Includes: W5133 3/8" Cordless Impact Wrench, (1) BL2022 5.0Ah Battery, (1) BL2012 2.5Ah Battery, 20V Battery Charger & Bag
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Blows per Min: 3300
• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/8
• Drive Type: Square
• Duty Rating: General Duty

• Forward Torque setting 1 (ft-lb): 2.2-8.9
• Forward Torque setting 1 (in-lb): 27-106
• Forward Torque setting 1 (nm): 3-12
• Forward Torque setting 2 (ft-lb): 9.6-24
• Forward Torque setting 2 (in-lb): 115-292
• Forward Torque setting 2 (nm): 13-33
• Forward Torque setting 3 (ft-lb): 240
• Forward Torque setting 3 (in-lb): 2876
• Forward Torque setting 3 (nm): 325
• Forward Torque setting 4 (ft-lb): 339
• Forward Torque setting 4 (in-lb): 4071
• Forward Torque setting 4 (nm): 460

• Hammer Case: Steel-lined Aluminum
• Head Width (in): 2.3
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Ball and Cam

• Lumens: 32
• Max Bolt Diameter (in): 7/16
• Max Free Speed (rpm): 2100
• Max Torque (ft-lb): 369
• Max Torque (in-lb): 4425
• Max Torque (nm): 500
• Motor: Brushless Motor

• Number of Batteries Required: 1
• Number of Power Settings: 4
• Nut-busting/Br

IR W5133-K626

Anvil Kit for Ingersoll Rand W5133 3/8" Square Drive Cordless Impact Wrench

• For Use With: IQV20-K201
• For Use With: W5133
• For Use With: W5133-AUNZ
• For Use With: W5133-K12
• For Use With: W5133-K22
• For Use With: W5133-K22-CN
• For Use With: W5133-K22-EU
• For Use With: W5133-K22-KR

IR W5132-K37

IR W5132-K249

Power Regulator Knob for Ingersoll Rand W5000 Series Impacts

Product Application and Uses:

For use with Ingersoll Rand W5133, W5133P, W5153, W5153P Impact Wrenches

• For Use With: W5133
• For Use With: W5133P
• For Use With: W5153
• For Use With: W5153P

IR W5133-K727

IR W5151P-K727

IR R3H-431

IR R3H-290A

IR R3H-14

IR R3H-24

IR R3F-7

IR R3H-402

IR R3H-22

IR R3H-11

IR R3H-401

IR R38P-606

Front Rotor Bearing Service Part for Ingersoll Rand Power Tools

IR R3H-434

IR R3H-15

IR R3H-283

IR R3H4-510

IR R3H-408

IR R3H-513

IR R3H-512

IR R3H-510

IR R3H-511

IR R3H-514

IR R3H-57

IR R3H-61

IR R3H-65

IR R3H-68A

IR R3H-98A

IR R3H-A424

IR R3SH-114

IR R4-33

IR R4-210

IR R4-157

IR R43F-104

IR R43F-70

IR R44H-3

IR R44H-210A

IR R44H-53

IR R4800-102

IR R4800-11

IR R4800-12

IR R4800-119

IR R4800-123

IR R4800-175

IR R4800-191

IR R4800-210

IR R4800-23

IR R4800-283

IR R4801-11

IR R4801-12

IR R4801-739

IR R4801U-8

IR R4H-401

IR R4H-273

IR R4H-402
